Introducing the Low Profile PCI-2S
The Low Profile PCI-2S high-speed serial card provides
two additional 9-pin serial ports.
Features and Benefits
•
Conforms to PCI v2.2 Plug and Play
•
Full support for Windows-based software
•
Supports 32-/64-bit, 3.3V/5V PCI and PCI-X slots
•
Two high-speed 16550 UART serial ports (9-pin)
supports data rate up to 230 Kbps
•
Built-in 32-byte FIFO buffer dramatically increase
data transmit/receive speed, especially under
Windows' multitasking environment
•
Each serial port can be configured for either 5V or
12V, for serial devices that require power
System Requirements
•
Pentium
PCI slot
•
Windows
/64-bit)/Server 2003 (32-/64-bit)/Vista (32-/64-bit)
Package Contents
•
Low Profile PCI-2S board
•
Connector bracket with 9-pin serial port (for the 2nd
serial port)
•
Driver CD
•
This quick installation guide
04-0367B
Low Profile PCI-2S
Quick Installation Guide
or equivalent computer with an available
®
95/98/98SE/ME/NT 4.0/2000/XP (32-
®
1
Advertisement
Related Manuals for SIIG Low Profile PCI-2S
Summary of Contents for SIIG Low Profile PCI-2S
-
Page 1: Quick Installation Guide
Low Profile PCI-2S Quick Installation Guide Introducing the Low Profile PCI-2S The Low Profile PCI-2S high-speed serial card provides two additional 9-pin serial ports. Features and Benefits • Conforms to PCI v2.2 Plug and Play • Full support for Windows-based software •... - Page 2 Layout Stripe Connector bracket with 9-pin serial port JP2 (serial port 2) Pin1 Pin header for serial port 2 JP1 (serial port 1) Serial port 1 Pin 9 Figure 1. Layout Jumper Settings (JP1, JP2) Open = 0 volts (default) Short 1-2 = 5V @ pin 9 Short 2-3 = 12V @ pin 9 Note: Most serial devices do not require additional...
-
Page 3: Hardware Installation
Hardware Installation General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed. Static Electricity Discharge may permanently damage your system. Discharge any static electricity build up in your body by touching your computer case for a few seconds. -
Page 4: Software Installation
Replace the computer cover and reconnect the power cord. Software Installation This section provides information on how to install the Low Profile PCI-2S drivers. Windows 95 At the Update Device Driver Wizard, click Next. Insert the driver CD, and click Other Locations. - Page 5 Right click My Computer, click Properties, then click Device Manager. Double click Ports (COM & LPT), CyberSerial PCI 16Cxxx... should be displayed two times. Double click Multi-function adapters, SIIG CyberPro 2S PCI board and PCI Function should be displayed. Windows NT 4.0 From the desktop click Start, then Run.
- Page 6 To Verify Windows NT 4.0 Installation Click Start, Settings, Control Panel, double click Ports icon. Two new COM ports will be assigned. Windows 2000 At the Found New Hardware Wizard, click Next. Select Search for a suitable driver for my device (recommended), and click Next.
- Page 7 Device Manager. Click on the + (plus sign) in front of Ports (COM & LPT), CyberSerial PCI 16Cxxx... should be displayed two times. Double click Multifunction adapters, SIIG CyberPro 2S PCI board should be displayed. ™ Windows Vista At the Found New Hardware window, insert the driver CD, click Locate and install driver software (recommended), then click Continue.
- Page 8 Click on the + (plus sign) in front of Ports (COM & LPT), CyberSerial 16Cxxx... should be displayed two times. Double click Multifunction adapters, SIIG CyberPro 2S PCI board should be displayed. Changing COM Port Address Some serial devices need a specific COM port in order to work.
- Page 9 Blank Page...
- Page 10 Blank Page...
-
Page 11: Technical Support And Warranty
Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. Step 2: After obtaining an RMA number, ship the product. - Page 12 Fremont, CA 94538-3152 USA Ph: 510-657-8688 Low Profile PCI 2S is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries. Pentium is a registered trademark of Intel Corporation in the U.S.
