Introducing the Low Profile PCI-1P
The Low Profile PCI-1P conforms to the new PCI card form
factor standard made for space constrained system
designs. It provides 1 ECP/EPP parallel port which
supports data transfer rates up to 1.5 MB/sec.
Features and Benefits
•
Conforms to PCI v2.2 Plug and Play
•
Can be installed in 32-/64-bit, 3.3v/5v PCI and
PCI-X slots
•
Full support for DOS and Windows based software
•
PCI IRQ sharing feature reduces IRQ conflicts
•
Compliant with IEEE 1284-1994 parallel port
standard
•
Supports ECP/EPP, Bi-directional (PS2) and
Standard Parallel Port (SPP) modes
•
Works with various types of parallel devices
including printers, removable drives, scanners,
CD-R/RWs, and more...
•
Dimensions:
- PCB: 119.91mm (L) x 64.41mm (H)
- Bracket: 18.42mm (W) x 79.20mm (H)
System Requirements
•
Pentium or equivalent computer with an available
PCI slot
•
DOS, Windows 95/98/98 SE/ME/NT 4.0/2000/
XP/Server 2003
04-0332A
Low Profile PCI-1P
Quick Installation Guide
1
Advertisement
Related Manuals for SIIG Low Profile PCI-1P
Summary of Contents for SIIG Low Profile PCI-1P
- Page 1 Low Profile PCI-1P Quick Installation Guide Introducing the Low Profile PCI-1P The Low Profile PCI-1P conforms to the new PCI card form factor standard made for space constrained system designs. It provides 1 ECP/EPP parallel port which supports data transfer rates up to 1.5 MB/sec.
-
Page 2: Hardware Installation
(1) Driver CD • This quick installation guide Layout Parallel Port Figure 1. Low Profile PCI-1P Layout Hardware Installation General instructions for installing the card are provided below, since the design of computer cases and motherboards vary. Refer to your computer’s reference manual for further information, if needed. - Page 3 • During the installation, avoid any contact with internal parts. Handle cards only by their external edges. Turn OFF the power to your computer. Unplug the power cord and remove your computer's cover. Remove the slot bracket from an available PCI slot. Carefully align the card to the selected PCI slot push the board down firmly, but gently, until it is well seated.
-
Page 4: Software Installation
Software Installation This section provides the steps on how to install the Low Profile PCI-1P drivers. Please make sure the board is installed before proceeding with the driver installation. Windows 95 Driver Installation At the Update Device Driver Wizard, click Next. - Page 5 Check Specify a location, uncheck the other box, insert the driver CD, type in X:\1P\ME, then click Next. (Change X: to match your CD-ROM drive letter) Click Next, then Finish. Restart Windows to complete the driver installation. Windows NT 4.0 Driver Installation From the desktop, click Start, then Run.
- Page 6 Windows XP Driver Installation At the Found New Hardware Wizard, choose Install from a list or specific location (Advanced), then click Next. Insert the driver CD, check Include this location in the search, uncheck the other box, type in X:\1P\XP, then click Next.
- Page 7 DOS Driver Installation Insert the driver CD. From the C:\> prompt, type copy X:\1P\dos\*.*, and press <Enter>. (Change X: to match your CD-ROM drive letter) Type edit autoexec.bat, and press <Enter>. Add C:\nmdosin.exe -a at the bottom of the autoexec.bat file. Go to File, save the changes and exit.
-
Page 8: Troubleshooting
Troubleshooting Problem: I am installing a parallel port(s) and my system freezes up when Windows tries to install the driver for my printer port. Solution: Enter your system bios, set the onboard parallel port I/O address to 278h, save and exit. In certain systems, the address 278h is reserved for ISA boards. -
Page 9: Technical Support
The 5-year manufacturer warranty supplied with this product is offered by SIIG, Inc. If you should happen to encounter any problems with this product, please follow the procedures below. - Page 10 Fremont, CA 94538-3152 Low Profile PCI-1P is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. DOS, Windows and Windows NT are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation.
