Introducing the CyberSerial Dual PCI
The CyberSerial Dual PCI high-speed serial I/O card
provides two additional 9-pin serial ports. Depending
on the model purchased, this board will fit into either a
Full or Low Profile chassis.
Features and Benefits
•
Conforms to PCI v2.2 Plug and Play
•
Reduces CPU load and improves system
performance dramatically
•
IRQ sharing feature reduces IRQ conflicts
•
High-speed serial port (9-pin) works with 56K V.90
external modems, ISDN terminal adapters, PDAs,
digital cameras, label printers and other serial port
devices
•
Built-in FIFO buffers dramatically increase data
transmit/receive speed, especially under Windows'
multitasking environment
•
Each serial port can be configured for either 5V or
12V output, for serial devices that require power
System Requirements
•
Pentium or equivalent computer with an available
PCI slot
•
DOS, Windows 95/98/98SE/ME/NT 4.0/2000/
XP/Server 2003
•
Linux Kernel 2.4.x or later
04-0376A
CyberSerial Dual PCI

Quick Installation Guide

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JJ-P02012 and is the answer not in the manual?

Questions and answers

Related Manuals for SIIG JJ-P02012

Summary of Contents for SIIG JJ-P02012

  • Page 1: Quick Installation Guide

    CyberSerial Dual PCI Quick Installation Guide Introducing the CyberSerial Dual PCI The CyberSerial Dual PCI high-speed serial I/O card provides two additional 9-pin serial ports. Depending on the model purchased, this board will fit into either a Full or Low Profile chassis. Features and Benefits •...

  • Page 2: Package Contents

    Package Contents • CyberSerial Dual PCI board • 2-port fan-out cable • Low profile bracket (Dual Profile board only) • Driver CD • Quick installation guide Layout Full profile JP2 (Serial port 2) bracket* Fan-out cable connector (25-pin) JP1 (Serial port 1) * Note: Depending on the model purchased, the bracket size will be either Full or Low profile.

  • Page 3: Hardware Installation

    Fan-out Cable 25-pin connector Hardware Installation General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed. Static Electricity Discharge may permanently damage your system.

  • Page 4: Driver Installation

    Change JP1 and JP2 jumper settings to the desired voltage only if your serial device needs additional power from the serial port. However, most serial devices do not require additional power. For more information see Figure 1 on page 2. The jumpers can be removed if power output is not required.
  • Page 5 Windows 95 At the Update Device Driver Wizard, click Next. Insert the driver CD, click Other Locations. Type in D:\9x, click OK, then click Finish. (Change D: to match your CD-ROM drive letter) From the Insert Disk window, click OK. When the Copying Files dialog box pops up, type in D:\9x, then click OK.
  • Page 6 Right click My Computer, click Properties, then click Device Manager. Double click Ports (COM & LPT), CyberSerial PCI 16Cxxx... should be displayed two times. Double click Multi-function adapters, SIIG CyberPro 2S PCI board and PCI Function should be displayed. Windows NT 4.0 From the desktop click Start, then Run.
  • Page 7 Windows 2000 At the Found New Hardware Wizard, click Next. Select Search for a suitable driver for my device (recommended), then click Next. Check Specify a location, uncheck the other boxes, then click Next. Insert the driver CD, type in D:\2000, then click OK. (Change D: to match your CD-ROM drive letter) Click Next and Finish.
  • Page 8 Linux Kernel 2.4.x or later Open the terminal. Type setserial -bg /dev/ttyS* and hit <enter> to show the current serial ports installed. SIIG board will be set up at the next available address. For example, if your system comes with /dev/ttyS0 and /dev/ttyS1, set up SIIG board as /dev/tty2 and /dev/ttyS3.
  • Page 9 - 02:0b.0 Serial controller: Oxford Semiconductor Ltd EXSYS EX-41092 Dual 16950 Serial ... - Subsystem: SIIG Inc: ... - Flags: medium devsel, IRQ 9 - I/O ports at a000 [size=32] - Memory at ed800000 (32-bit, ...) ...
  • Page 10 Changing COM Port Address Some serial devices need a specific COM port in order to work. If your serial device works properly, do not change this setting. Windows 95/98/98SE/ME From the Device Manager window double click Ports (COM & LPT), then double click the CyberSerial PCI serial port you want to change.

  • Page 11: Technical Support And Warranty

    SIIG will refuse to accept any shipping package, and will not be responsible for a product returned without an RMA number posted on the outside of the shipping carton. You are responsible for the cost of shipping the product to SIIG • at the following address: SIIG, Inc.
  • Page 12 Fremont, CA 94538-3152 CyberSerial Dual PCI is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation. Other names used in publication are for identification only and may be trademarks of their respective companies.
