Firmware File Transfers
NXI Master Controllers use Kit files for firmware upgrades. A Kit file (.KIT) is a package of several files, all
of which are required to upgrade the firmware, and are available online via www.amx.com.
The Online Device Tree displays information about each online device, including the current firmware
version.
Before attempting to upgrade the firmware, you must have the appropriate Kit file for your NetLinx Master.
Warning! If for any reason your Kit file transfer should fail, continue to retry the
transfer until you are successful. DO NOT reboot the Master, or change connections
until the transfer is complete. Failure to complete this operation successfully may
result in a factory repair of the Master.
Firmware File Transfer dialog
Select Options > Advanced > Firmware File Transfer to open the Firmware File Transfer dialog (FIG. 41):
FIG. 41
Firmware File Transfer dialog
Use the options in this dialog to select a KIT (firmware) file, and target NetLinx device for the transfer:
Firmware File Transfer dialog options
Location
Files
Target
Device / Port / System Enter the D:P:S information for the target device.
System
Reboot Device
Send
RPMLoader
Specify the source directory for the desired KIT file(s). Click the browse button to nav-
igate to the desired folder in the Browse For Folder dialog.
Contains a list of KIT files that reside in the specified source directory. Use the scroll
arrows to view the entire list. Select a file from the list to view detailed file information
in the lower portion of the field (including a general description of the file, and the
firmware type and version).
Note: If the selected KIT file is intended for a Master, the device field should be set to
zero.
Enter the system number of the target system.
Select this option to automatically reboot the target device after the transfer is com-
plete (default = disabled).
Click to send the selected KIT files to the specified device.
Using RPMLoader
21
