System Information Tab
Software/Firmware Version and RAID Status Information
The area directly beneath the AMX logo contains read-only information regarding the current
software and firmware versions in use, as well as RAID status and copyright information (see
FIG. 57):
Web Update
Click the Web Update button to open the Application Files page of www.amx.com in your web
browser, to check for any available updates for WinMAX. When the page is opened, scroll to the
bottom of the list of applications, and check to see the latest version of WinMAX. To download and
install a new version, click on the WinMAX Installation link and follow the instruction on your
screen. Your PC must be connected to the Internet to use this feature.
Application Settings
Click the Application Settings button to open the Application Settings dialog (FIG. 59). This
dialog is for making various application-level settings for WinMAX.
FIG. 59 Application Settings dialog
The items that are accessible via this dialog are intended only for use by AMX Technical Support.
The only exception is the DriveNum Key/Value setting which determines which CD-ROM drive
on your PC will be used by WinMAX for recording:
Refer to the Specify a Local CD/DVD-ROM Drive To Use section on page 44 for
details.
56
• WinMAX version:
Displays the version of the WinMAX software currently in use.
• MAX Server Version: Displays the version of the firmware currently loaded in the MAX server.
• Raid Status:
Displays the current status of the MAX server's Raid disk drive system.
0 = The first CD-ROM drive on your PC (default setting)
1 = The second CD-ROM drive on your PC
WinMAX MAX Server Control Software
