Installing The Wall Power Adapter
(Optional Component)
This component is best used when wall
mounting the telephone. To install,
simply plug the power adapter into a
standard 120V AC power outlet. A
mounting hole is provided to secure
the power pack to the AC wall outlet.
Plug the AC power pack directly into
the wall outlet and then plug the coax-
ial connector into
marked "POWER" located on the back
of the telephone.
Completing the Power Installation
If the

installation

information shown at the right will be
displayed on the LCD.
If the LCD does not display words and
n u m b e r s , c h e c k
connections.
the receptacle
is correct, the
y o u r p o w e r
13
120V AC POWER
02/27
-00-
NEW
POWE R
ORDER SEPERATELY
pm12:26
-00-
TOTAL
