Wall Mounting the Spectrum PLUS
2. T he S pectrum PLUS
mounting w edge th at mu st be correctly
positioned. T his w edge allow s th e tel ephone t o
be viewed at a c orrect angle w hen the p hone is
wall mo unted. Remo ve t he w edge f rom t he
phone base (figure 2).
3. Secure the line cord, coil cord and any wiring
in place prior to installing the wall mount wedge.
The w all mou nt bas e has ex tra large w iring
channels a nd s train r elief poles f or c ontaining
the wi res i n a n eat an d orderly way. Wrap t he
wires around the strain relief poles and then se-
cure the wires through the channel.
4. T o w all mou nt, plac e th e n arrow edge at th e
top edge of the phone base an d slide th e wedge
upward into place (figure 3).
5. Loc k th e w all mou nt i nto pos ition by s liding
the locking button to the right (figure 4).
Note: A 6-inch line cord is provided for when
the telephone is to be wall mounted. Connect
one end of the line cord to the phone jack and
the other end to the wall jack. Be sure to con-
nect the power cord and line cords before plac-
!
ing mounting wedge on the bottom base. An
optional coaxial power supply can be used in
place of the supplied power supply. See your
local distributor for information.
Desk Mounting
To in stall th e w edge f or d esk mou nting, be s ure the loc k mec hanism is pos itioned to th e
left, clear of the locking arm. Place the wedge in the slots, wide end toward top of phone
base unit, and slide the wedge upward into position. Lock the wedge into place.
TM
h as pr ovisions f or a
14
TM Telephone (continued)
Replace Mounting Wedge
Replace Mounting Wedge
Lock Mounting Wedge
figure 2
Figure 3
figure 4
