Connecting the Handset Cord

A 10-foot modular coil handset cord is
provided. ( Be sure that the wall/desk
elevation stand
attached). To i nstall the co rd, simply
plug the short straight end o f the
handset cord into the modular jack on
the handset. The long straight end of
the hands et c ord pl ugs i nto the jac k
labeled "Hands et" l ocated on the b ot-
tom of the SpectrumPLUS
Place t he l ine co rd i nto t he h andset
coil c ord channel lo cated d irectly
below the jack.
NOTE: Be sure that all line cord connections are made prior to installing the Wall Mount Wedge.
An optional direct connect coaxial power supply can be used or the provided power supply can be used.
Wall Mounting the Spectrum PLUS
The S pectrum P LUS
conveniently w all mou nted w ithout r equiring
additional hardware.
Follow these easy steps:
1.The handset r etaining c lip mu st be in th e
correct p osition t o se cure t he h andset i nto
the handset cradle. Engage the clip with your
fingers a nd pu ll th e c lip f orward ( towards
you), rotate th e c lip 180º an d s nap th e c lip
back in to pla ce ( figure 1) . Th e r etaining c lip
cannot be removed.
has not been
TM
base unit.
TM
was design ed to be
TM Telephone
1. UNS NA P
2. RO TATE 1 80 .
3. SN AP I NTO P LA CE.
1.LIFT CLIP OUT WITH
FINGERS. IT CANNOT BE
REMOVED BECAUSE IT IS
SPRING LOADED.
2. ROTATE THE CLIP 180
AND IT WILL SMAP BACK
INTO THE OPPOSITE
POSITION. AN
EXTENDED PLAS-
TIC BUMP WILL
BE FACE-UP FOR WALL
MOUNTING
13
RETAINER CLIP
NOTE: CLIP IS
SPRING LOADED
0
figure 1
