120V AC Outlet Recovery Power Adapter (provided)
The 120 VOL T A C OUTLET ADAP TER i s a p roprietary TeleMatrix pr oduct. It p ro-
vides both the telephone lines and the power source in one cable (6P6C line cord)
and is designed to recover the use of the AC power outlet.
Connector Configuration
The 120V O utlet Recovery Power Adapter ha s two (2) mo dular jac ks. One jac k i s
labeled "LINE INPUT" and the other jack is labeled "TO PHONE". These jacks allow
for a fully modular installation.
Power Adapter "LINE" Connection
The power adapter s "L INE INPUT" c onnec-
tion is us ed to c onnect the te lephone l ine
from the wal l jac k to the po wer adapter .
Using o ne o f the 15-f oot mo dular te lephone
line co rds, connect on e en d o f t he c ord t o
the RJ14 te lephone jack on the wall or base
board. The remaining end o f the l ine c ord
plugs i nto the "L INE " s ide of the p ower
adapter.
Power Adapter "PHONE" Connection
The p ower adapter " TO PH ONE" c onnector i s
used to p rovide bo th the te lephone l ine and
the po wer s ource to ope rate the te lephone.
Using o ne of the 15-f oot m odular te lephone
line cords, pl ug one end of the l ine cord i nto
the back of the telephone. Plug the remaining
end to the po wer ada pter jac k l abeled "T O
PHONE".
Troubleshooting Note: If there is no power to the telephone
after c onnecting the line c ords, c heck to s ee if the line cords
were inserted in the opposite sides of the adapter.
12
