5

Technical data

5.1

Technical data for IP-Module CFVA-IP

Electrical supply
Power requirement
Operating temperature range
Storage temperature range
Dimensions (H x Ø)
Weight
Material
System requirements
Protocols
Installation
Network connection
Image formats
Image transmission
Security
Hardware
Siemens Building Technologies
Fire Safety & Security Products
12 V DC/24 V AC
max. 6.0 W
-10 – +45 °C, max. relative humidity 90%
-20 – +60 °C
35.5 x 140 mm
400 g
Aluminum
All systems, which feature TCP/IP network functions and
provide an http browser (Microsoft Internet Explorer from
version 5.5 with Java plug-in or Mozilla or Netscape from
version 7.0).
ARP, BOOTP/DHCP, TCP/IP, HTTP, ICMP, SNMP, FTP
and DNS
IP address configurable via ARP, BOOTP/DHCP,
connection to twisted-pair RJ45 Ethernet.
10BaseT Ethernet or 100BaseTX Fast Ethernet, auto-
sensing, full/half duplex
QCIF (176x144),
CIF (352x288),
4CIF (704x576) (interlaced).
Motion JPEG (multipart/x-mixed-replace content type),
user configurable JPEG single image frame quality,
streaming up to 25 images per second with QCIF and
CIF or up to 10 images per second with 4CIF.
Separate passwords for image access and system
configuration.
8 MB RAM, 16 MB flash ROM
Technical data
9
