Technical data
5.2

Technical data for IP-Module CVVA-IP

Electrical supply
Power requirement
Operating temperature range
Storage temperature range
Dimensions (H x Ø)
Weight
Material
IP rating
System requirements
Protocols
Installation
Network connection
Image formats
Image transmission
Security
Hardware
10
Siemens Building Technologies
Fire Safety & Security Products
12 V DC/24 V AC
max. 6.0 W
-10 – +50 °C, max. relative humidity 90%
-20 – +60 °C, max. relative humidity 70%
48 x 135 mm
620 g
Aluminum
IP66
All systems, which feature TCP/IP network functions and provide an
http browser (Microsoft Internet Explorer from version 5.5 with Java
plug-in or Mozilla or Netscape from version 7.0).
ARP, BOOTP/DHCP, TCP/IP, HTTP, ICMP, SNMP, FTP and DNS
IP address configurable via ARP, BOOTP/DHCP, connection to twisted-
pair RJ45 Ethernet.
10BaseT Ethernet or 100BaseTX Fast Ethernet, auto-sensing, full/half
duplex
QCIF (176x144),
CIF (352x288),
4CIF (704x576) (interlaced).
Motion JPEG (multipart/x-mixed-replace content type), user
configurable JPEG single image frame quality, streaming up to 25
images per second with QCIF and CIF or up to 10 images per second
with 4CIF.
Separate passwords for image access and system configuration.
8 MB RAM, 16 MB flash ROM
