- Page 1 ______________ Introduction SIMATIC DP/PAink and Y Link bus links IM 153-2 Interface Module ______________ Description ______________ Technical specifications SIMATIC DP/PA Link and Y Link bus links IM 153-2 Interface Module Product Information 08/2007 A5E01208363-01...
- Page 2 Trademarks All names identified by ® are registered trademarks of the Siemens AG. The remaining trademarks in this publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
-
Page 3: Table Of Contents
Table of contents Introduction..............................5 Introduction ............................5 Compatibilities..........................6 Description..............................7 Routing of frames of the slave initiative ..................7 Improved link behavior during commissioning................7 Which devices can be operated behind the Y Link?..............8 Operation of the link on an S5 H System..................8 Technical specifications.......................... - Page 4 Table of contents IM 153-2 Interface Module Product Information, 08/2007, A5E01208363-01...
-
Page 5: Introduction
● Routing of frames of the slave initiative ● The link behavior for commissioning has been improved. Additional documentation You will find the following supplementary documentation online at: http://support.automation.siemens.com/WW/view/en/ with the corresponding entry ID Name of manual Description Operating Instructions Bus Links Description;... -
Page 6: Compatibilities
Introduction 1.2 Compatibilities Compatibilities Compatibility with predecessor versions With regard to properties and features, the IM 153-2BAx2 interface module is fully compatible with its predecessor versions. In addition, the new features indicated above are available. IM 153-2 Interface Module Product Information, 08/2007, A5E01208363-01... -
Page 7: Description
Description Routing of frames of the slave initiative The IM 153-2BAx2 support routing of frames of the slave initiative. In so doing, the frames of devices are passed behind the link to the higher-level controller. This routing can be used, for example, to operate SINAMICS drives behind the Y Link if the trace function is being used with the STARTER commissioning tool. -
Page 8: Which Devices Can Be Operated Behind The Y Link
Description 2.3 Which devices can be operated behind the Y Link? Which devices can be operated behind the Y Link? Slaves at the lower-level DP master system cannot be operated in DPV1 mode unless they have been integrated and configured with GSD rev. ≥ 5. The GSD must contain the following entries: ●... -
Page 9: Technical Specifications
Technical specifications Technical specifications of the IM 153-2 (6ES7153-2BAx2-0XB0) Dimensions and weight Dimension W x H x D (mm) 40 x 125 x 117 Weight Approx. 360 g Module-specific data Transmission speed for the higher level DP 9.6; 19.2; 45.45; 93.75; 187.5; 500 kBaud master system 1.5;... - Page 10 Technical specifications 3.1 Technical specifications of the IM 153-2 (6ES7153-2BAx2-0XB0) Status, interrupts, diagnostics Status display Interrupts Diagnostics function Group error • Red LED "SF" Bus error on higher level DP master system • Red LED "BF 1" Bus error on underlying bus system •...
