Parts List - SPALDING M88724C Owner's Manual

Item Qty. Part No.
1 1 968880
2 1 998880
3 1
4 1
5 4 203017
6 4 203300
7 2 250001
8 2* 250002
9 1 203457
10 1
11 1 516000
12 1 204940
13 2 220563
14 1 80854501
15 4 203309
16 1
17 1 978880
18 1 988883
19 4 200573
20 1 203630
21 16 203635
22 10 203637
23 1* 203641
24 9 204046
25 12 204057
26 1 205008
27 2 202666
204521
28 3 204728
29 4 204733
30 2 204735
31 1 204741
32 1 204742
33 2* 206311
34 4 205254
35 1 204921
36 1 204922
37 1 204923
38 14 204670A
39 4 204670B
40 8 204670C
* You May Have Extra Parts With This Model.

PARTS LIST

Description
Pole
Plate, Anchor, Black
Rim Assembly
Net
Nut, Hex, 3/8-16
Washer, 3/8 Locking, .380 I.D., .63 O.D.
Bolt, Hex, Tap, 3/8-16 x 4" Long
Bolt, Hex, Tap, 3/8-16 x 2" Long
Label, Logo, Vinyl, 2.3" x 2.7"
Backboard
Label, Height Adjustment
Screw Jack
Screw, 1/4-20 x 1/2" Long, Rim Cover
Rod, Threaded Assembly, 5/8-11 x 19.8", Zinc
Washer, Flat, 3/8"
Cover, Rim
Yoke, Upper, Center, Pole
Yoke, Lower, Center, Pole
Bolt, J, 5/8-11 x 24, 3" Thread
Bolt, Hex, 1/2-13 x 5, Black Oxide
Washer, Flat, .053 I.D., 1.08 O.D., Black Oxide
Nut, Lock, Nylon Insert, 1/2-13, Black Oxide
Bolt, Hex Head, 1/2"-13 x 6"
Washer, 5/8 Flat, .656 I.D., 1.313 O.D., Black Oxide
Nut, Hex, 5/8-11, Black Oxide
Nut, Hex, 5/8-11, Grade 8
Name Plate, Hydra-Rib or
Name Plate, Spalding
Bolt, Hex, 1/2-13 x 9.25, Black Oxide
Screw, #8, .50 Long
Height Indicator, Plastic
Label, Height Indicator, Right
Label, Height Indicator, Left
Spacer, .52 I.D. x .75 O.D. x .5" Long, Plastic
Bolt, Hex, 1/2-13 x 2.5, Black Zinc
Washer, Barrel
Pin, Hitch
Pin, Cotter, #8
Bushing, Plastic
Bushing, Plastic
Bushing, Plastic
ID# 516000
3
06/05
11
10/05 ID# M88724C
