High End Residential
In-Ground Basketball System
Owners Manual
Customer Service Center
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
Write Model Number
WARNING!
From Box Here:
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING INSTRUCTIONS
COULD RESULT IN INJURY
OR DAMAGE TO PROPERTY.
Toll-Free Customer Service Number for U.S: 1-800-334-9111
Hydra-Rib Internet Address: http://www.hydra-rib.com
Spalding Internet Address: http://www.spalding.com
1
10/05
ID# M88724C
Advertisement
Table of Contents
Related Manuals for SPALDING M88724C
Summary of Contents for SPALDING M88724C
-
Page 1: Owners Manual
READ AND UNDERSTAND OPERATOR'S MANUAL BEFORE USING THIS UNIT. FAILURE TO FOLLOW OPERATING INSTRUCTIONS COULD RESULT IN INJURY OR DAMAGE TO PROPERTY. Toll-Free Customer Service Number for U.S: 1-800-334-9111 Hydra-Rib Internet Address: http://www.hydra-rib.com Spalding Internet Address: http://www.spalding.com 10/05 ID# M88724C... -
Page 2: Safety Instructions
• (2 each) Wrenches and/or Socket Wrenches and Sockets (Deep-Well Sockets are Recommended). • Shovel & Post Hole Digger 1/2" 9/16" 3/4" 15/16" • Optional: Large & Small Adjustable Wrenches • Wood Board (scrap) 1/2" 9/16" 3/4" 15/16" ID# M88724C 10/05... -
Page 3: Parts List
Spacer, .52 I.D. x .75 O.D. x .5” Long, Plastic 205254 Bolt, Hex, 1/2-13 x 2.5, Black Zinc 204921 Washer, Barrel 204922 Pin, Hitch 204923 Pin, Cotter, #8 204670A Bushing, Plastic 204670B Bushing, Plastic 204670C Bushing, Plastic * You May Have Extra Parts With This Model. 10/05 ID# M88724C... - Page 4 Item #24 (9) Item #5 (4) Item #22 (10) Item #26 (1) Item #25 (12) HARDWARE IDENTIFIER (OTHER—NOT ACTUAL SIZE) Item #35 (1) Item #38 (14) Item #39 (4) Item #40 (8) Item #37 (1) Item #36 (1) ID# M88724C 10/05...
- Page 5 Install threaded ends of J-bolts (19) through holes in mounting plate (2) and secure as shown. NOTE: Make sure J-bolts (19) are in the illustrated position. Nuts on the top of plate are used for leveling the pole after system is fully assembled. 10/05 ID# M88724C...
-
Page 6: Side View
Front of mounting plate (2) must be parallel with playing surface. PLAYING SURFACE IMPORTANT!: WAIT A MINIMUM OF 72 HOURS BEFORE GOING ON TO NEXT STEP. CONCRETE MUST CURE. ALLOW ADDITIONAL TIME FOR COLD, WET OR HUMID WEATHER. ID# M88724C 10/05... - Page 7 Insert bushings (38, 39, 40) into areas shown. IMPORTANT! Bushing types are identified with a letter. 10/05 ID# M88724C...
- Page 8 SCRAP WOOD REQUIRED FOR THIS (NOT INCLUDED) PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. PLAYING SURFACE Insert bolt (28) through holes in plate and pole and secure with nut (22). ID# M88724C 10/05...
-
Page 9: Completed Assembly
Slide barrel washer (35) onto other end of DAMAGE. rod (14) and secure with washer (24) and nut (26). Tighten nut (26) until it is positioned 3-3/4” from the end of the rod (14) as shown (Figure A). Completed Assembly FIGURE 10/05 ID# M88724C... - Page 10 While still in forward position, attach both upper and lower yokes (17 & 18) to pole as shown. WARNING! THREE PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. ID# M88724C 10/05...
- Page 11 Attach elevator adjustment (12) to lower yoke (18). WARNING! THREE PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. 10/05 ID# M88724C...
- Page 12 Attach elevator adjustment (12) to pole bracket. WARNING! THREE PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. ID# M88724C 10/05...
- Page 13 ONE person to attach hardware (FIG. A). Use hardware as shown in FIG. B. WARNING! THREE PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. FIG. C FIG. A FIG. D FIG. B 10/05 ID# M88724C...
- Page 14 (16). ** For rim assembly, see instructions included with rim. IMPORTANT! Carefully cut and peel protective film away from board prior to attaching rim. FIGURE Rim Assembly Refer To Instructions Included With Rim Hardware For Rim Assembly. ID# M88724C 10/05...
- Page 15 (29) into place with a rubber mallet. Apply name plate sticker (27) to lower yoke as shown. Install net (4) to rim as shown. 10/05 ID# M88724C 7 8 9 10 7 8 9 10...
- Page 16 • Chec r play top cove • Neve pole • Keep 2/99 5234 20125 1-800 -558- THREE PEOPLE REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. ID# M88724C 10/05...
- Page 17 WARNING! ONLY AFTER THE ANCHOR PLATE HAS BEEN FULLY TIGHTENED: Remove cotter pin (37) and pin (36) to remove threaded assembly rod (14) from anchor plate (2). 10/05 ID# M88724C...
- Page 18 Adjust system by turning crank until desired height is reached per height indicator (30). WARNING! 10 feet (3.05 m) READ AND UNDERSTAND WARNING & HEIGHT ADJUSTMENT LABELS BEFORE USING THIS UNIT. FAILURE TO FOLLOW OPERATING INSTRUCTIONS COULD RESULT IN INJURY OR DAMAGE TO PROPERTY. ID# M88724C 10/05...
-
Page 19: What Is Not Covered By This Warranty
HANGING ON THE RIM WILL VOID YOUR WARRANTY. RIms are not warranted for any defects other than workmanship. Torn back plates, damaged springs, bent rings, damaged eye bolts, and torn or distorted rim supports result from hanging on the rim and are not warranted. 10/05 ID# M88724C...
