SPALDING M88604C1 Owner's Manual

High end residential in-ground basketball system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
High End Residential
In-Ground Basketball System

Owners Manual

Customer Service Center
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
Adult Assembly Required.
This manual, accompanied by sales receipt, should be saved and kept on hand as a convenient reference, as it contains
important information about your model.
Write Model Number
WARNING!
From Box Here:
READ AND UNDERSTAND OPERATOR'S
MANUAL BEFORE USING THIS UNIT.
FAILURE TO FOLLOW OPERATING
INSTRUCTIONS COULD RESULT IN
INJURY OR DAMAGE TO PROPERTY.
Toll-Free Customer Service Number for U.S: 1-800-334-9111
Spalding Internet Address: http://www.spalding.com
1
08/06
ID# M88604C1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M88604C1 and is the answer not in the manual?

Questions and answers

Related Manuals for SPALDING M88604C1

Summary of Contents for SPALDING M88604C1

  • Page 1: Owners Manual

    WARNING! From Box Here: READ AND UNDERSTAND OPERATOR'S MANUAL BEFORE USING THIS UNIT. FAILURE TO FOLLOW OPERATING INSTRUCTIONS COULD RESULT IN INJURY OR DAMAGE TO PROPERTY. Toll-Free Customer Service Number for U.S: 1-800-334-9111 Spalding Internet Address: http://www.spalding.com 08/06 ID# M88604C1...

  • Page 2: Required Tools And Materials

    • (2 each) Wrenches and/or Socket Wrenches and • Container to Mix Sockets (Deep-Well Sockets are Recommended). • Shovel & Post Hole • Optional: Large & 1/2" 9/16" 3/4" 15/16" Digger Small Adjustable Wrenches • Wood Board (scrap) 1/2" 9/16" 3/4" 15/16" ID# M88604C1 08/06...

  • Page 3: Parts List

    204741 Label, Height Indicator, Right 204742 Label, Height Indicator, Left 206311 Spacer, .52 I.D. x .75 I.D. x .5” Long, Plastic 205830 Bolt, Hex, 1/2-13 x 2.5, Zinc * You May Have Extra Parts With This Model. 08/06 ID# M88604C1...
  • Page 4 Item #27 (4)* Item #21 (16) Item #24 (9) Item #5 (4) Item #22 (9)* Item #25 (4) Item #26 (1) HARDWARE IDENTIFIER (OTHER-NOT ACTUAL SIZE) Item #9 (1) Item #15 (1) Item #19 (26) Item #8 (1) ID# M88604C1 08/06...
  • Page 5 PLAYING SURFACE 48" (121.9 cm) CONTACT UTILITIES BEFORE DIGGING. Install nuts (25) onto the ground tube bolts as shown. NOTE: Nuts on the top of the plate are used for leveling the pole after system is fully assembled. 08/06 ID# M88604C1...

  • Page 6: Side View

    Fill hole with concrete. Tamp down concrete to release air pockets and build drainage hill. DRAINAGE HILL 1" (2.54 cm) PLAYING SURFACE SIDE VIEW Insert rebar (10) through holes in ground tube assembly (2) as shown. ID# M88604C1 08/06...
  • Page 7 Check leveling of mounting plate several times with carpenter’s level while concrete is curing. IMPORTANT!: WAIT A MINIMUM OF 72 HOURS BEFORE GOING ON TO NEXT STEP. CONCRETE MUST CURE. ALLOW ADDITIONAL TIME FOR COLD, WET OR HUMID WEATHER. 08/06 ID# M88604C1...
  • Page 8 Insert bushings (19) into areas shown. ID# M88604C1 08/06...
  • Page 9 SCRAP WOOD REQUIRED FOR THIS (NOT INCLUDED) PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. PLAYING SURFACE Insert bolt (23) through holes in plate and pole and secure with nut (22). 08/06 ID# M88604C1...

  • Page 10: Completed Assembly

    Slide barrel washer (15) onto other end of rod (14) and secure with washer (24) and nut (26). Tighten nut (26) until it is positioned at 3-3/4” from the end of the rod (14) as shown (Figure A) Completed Assembly FIGURE ID# M88604C1 08/06...
  • Page 11 While still in forward position, attach both upper and lower yokes (17 & 18) to pole as shown. WARNING! THREE CAPABLE ADULTS REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. 08/06 ID# M88604C1...
  • Page 12 Attach elevator adjustment (12) to lower yoke (18). WARNING! THREE CAPABLE ADULTS REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. ID# M88604C1 08/06...
  • Page 13 Attach elevator adjustment (12) to pole bracket. WARNING! THREE CAPABLE ADULTS REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. 08/06 ID# M88604C1...
  • Page 14 ONE person to attach hardware (FIG. A). Use hardware as shown in FIG. B. WARNING! THREE CAPABLE ADULTS REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. FIG. A FIG. C FIG. D FIG. B ID# M88604C1 08/06...
  • Page 15 (16). ** For rim assembly, see instructions included with rim. IMPORTANT! Carefully cut and peel protective film away from board prior to attaching rim. FIGURE Rim Assembly Refer To Instructions Included With Rim Hardware For Rim Assembly. 08/06 ID# M88604C1...
  • Page 16 NOTE ORIENTATION OF HEIGHT INDICATORS: 10’ MARK SHOULD FACE AWAY FROM BACKBOARD. Attach height indicators to lower yoke in area shown by turning screws (29) into place with a phillips-head screwdriver. Install net (4) to rim as shown. ID# M88604C1 08/06...
  • Page 17 • Chec r play top cove • Neve pole • Keep 2/99 5234 20125 1-800 -558- THREE CAPABLE ADULTS REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. 08/06 ID# M88604C1...
  • Page 18 (14) which is no longer necessary for the remainder of the assembly and installation of system. WARNING! ONLY AFTER THE ANCHOR PLATE HAS BEEN FULLY TIGHTENED: Remove cotter pin (9) and pin (8) to remove threaded assembly rod (14) from anchor plate (2). ID# M88604C1 08/06...
  • Page 19 Adjust system by turning crank until desired height is reached per height indicator (30). WARNING! 10 feet (3.05 m) READ AND UNDERSTAND WARNING & HEIGHT ADJUSTMENT LABELS BEFORE USING THIS UNIT. FAILURE TO FOLLOW OPERATING INSTRUCTIONS COULD RESULT IN INJURY OR DAMAGE TO PROPERTY. 08/06 ID# M88604C1...

  • Page 20: Limited Lifetime Warranty

    HANGING ON THE RIM WILL VOID YOUR WARRANTY. Rims are not warranted for any defects other than workmanship. Torn back plates, damaged springs, bent rings, damaged eye bolts, and torn or distorted rim supports result from hanging on the rim and are not warranted. ID# M88604C1 08/06...
