High End Residential
In-Ground Basketball System

Owners Manual

Customer Service Center
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
Adult Assembly Required.
This manual, accompanied by sales receipt, should be saved and kept on hand as a convenient reference, as it contains
important information about your model.
Write Model Number
WARNING!
From Box Here:
READ AND UNDERSTAND OPERATOR'S
MANUAL BEFORE USING THIS UNIT.
FAILURE TO FOLLOW OPERATING
INSTRUCTIONS COULD RESULT IN
INJURY OR DAMAGE TO PROPERTY.
Toll-Free Customer Service Number for U.S: 1-800-334-9111
Spalding Internet Address: http://www.spalding.com
1
08/06
ID# M88724C1
