To ensure prompt and correct handling of any problems, or to answer any questions, please
© COPYRIGHT 2006 by SPALDING
Display System
Owners Manual
• N53 W24700 South Corporate Circle • Sussex, WI 53089 • U.S.A.
WARNING!
READ AND UNDERSTAND
OPERATOR'S MANUAL
BEFORE USING THIS UNIT.
FAILURE TO FOLLOW
OPERATING INSTRUCTIONS
COULD RESULT IN INJURY
OR DAMAGE TO PROPERTY.
contact the Sample and Display Technician at 1-800-558-5234.
Customer Service Center
REQUIRED TOOLS AND MATERIALS:
• 2 Capable Adults
• 2 Stepladders
• Phillips Screwdriver
IMPORTANT!
1
Model
89226
• (2 each) Wrenches and/or
Socket Wrenches and
Sockets.
7/16"
1/2"
9/16"
AND/OR
7/16"
1/2"
9/16"
09/06
ID# M890001

Advertisement

loading
Need help?

Need help?

Do you have a question about the M890001 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SPALDING M890001

  • Page 1 Owners Manual Customer Service Center REQUIRED TOOLS AND MATERIALS: • 2 Capable Adults • 2 Stepladders • Phillips Screwdriver IMPORTANT! Model 89226 • (2 each) Wrenches and/or Socket Wrenches and Sockets. 7/16" 1/2" 9/16" AND/OR 7/16" 1/2" 9/16" 09/06 ID# M890001...
  • Page 2: Safety Instructions

    • Display recommended for 3” (7.6 cm) or 3-1/2” (9 cm) Round or 4” (10 cm) Square poles only. • All instructions and warnings MUST accompany any display item that is sold. ID# M890001 09/06 NOTICE TO ASSEMBLERS IMPORTANT! Remove all contents from boxes.
  • Page 3 909602FR Board, 44", Fan, Zone Attack 912006 Extension Arm 979235FR Board, 48", SFA, Titanium II 902319 Bracket, Reinforcement, No Tools Item #3 (2) Item #19 (1) Item #10 (1) Item #9 (12) Item #14 (4) Item #15 (2) 09/06 ID# M890001...
  • Page 4 Height = 8”, O.D. = 3 3/8”, I.D. = 3 1/8” (arrows indicate direction the board is facing). Display boards will be mounted as follows: Corner Location 1: Corner Location 2: Corner Location 3: Corner Location 4: ID# M890001 09/06 Display Stand - Top View 3-1/2" Corner “4” Corner “3” 80602 Corner “2”...
  • Page 5 (27) into position as shown. To lock the display pole in place, tighten the hex-bolt (19). At corner location 1, 2 and 4 slide the 3-1/2" diameter end of the display pole (5) outside the mounting stubs. 09/06 ID# M890001...
  • Page 6 (4) assemblies to backboard using bolt (7 ) and nut (11) as shown. Attach board assembly to pole. TWO CAPABLE ADULTS REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. ID# M890001 09/06 61259 73256 WARNING!
  • Page 7 Attach cover (2) to rim using screws (3). Apply logo label (8) to rim cover (2). NOTE: Tighten nut (17) until flush with end of "T" bolt (18) as shown here. 09/06 ID# M890001...
  • Page 8 (31) to backboard using bolt (7) and nut (11) as shown. Tighten completely. Attach board assembly to pole. WARNING! TWO CAPABLE ADULTS REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. ID# M890001 09/06 61259 73256...
  • Page 9 • Install spring (16) onto “T” bolt (18) as shown. • Install special nut (17) and washer (15) onto “T” bolt (18). NOTE: Tighten nut (17) until flush with end of "T" bolt (18) as shown here. 09/06 ID# M890001...
  • Page 10 Attach board assembly to pole with carriage bolts (12) and knobs (6) as shown. Install pole cap (21) as shown. ID# M890001 09/06 Pole bracket will need to be lightly pressed into backboard ribbing. Be sure to press completely into place.
  • Page 11 (31) with bolts (7), washers (14) and nuts (11). Tighten completely. Attach board assembly to pole. WARNING! TWO CAPABLE ADULTS REQUIRED FOR THIS PROCEDURE. FAILURE TO FOLLOW THIS WARNING COULD RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. 09/06 ID# M890001...
