To perform the Color Deadband Alignments
Depress the "Menu" key on the control panel to begin the main
menu subroutine.
Using the "Up Arrow", Down Arrow" and "Select" keys on the
control panel select:
Utility Menu
Db Calib
Select "Color Db Test" to run the color deadband test.
The test consists of 12 default calibration settings. When the test is
run it will print out a pattern of 5 calibration lines for each of
the 12 settings. It will print this pattern in black first, followed
by cyan, magenta and then yellow. Also printed will be the
current settings for each of the four colors as well as the slow
deadband setting.
When the plot is complete, select "K Fast DB=XX".
Observe the plot and using either "Up Arrow" or "Down Arrow",
rotate through the selections until one that seems closest to the
correct value is selected. Press "Select" to accept the selection.
Continue performing these steps until the all color deadband
adjustments are correct.
