General Information - IMC Networks iMcV-DS3/E3-LineTerm Operation Manual

General Information

IMC Networks Technical Support
Tel: (949) 465-3000 or (800) 624-1070 (in the U.S. and Canada);
+32-16-550880 (Europe)
Fax: (949) 465-3020
E-Mail: techsupport@imcnetworks.com
Web: www.imcnetworks.com
Specifications
Standards Compliance (DS3, E3, STS-1):
ANSI T1.102-1993
ANSI T1.107.1995
GR-820-CORE
DS3, E3, STS-1 Interface:
BNC coax 75 +/- 5% ohms
DS3 (44.736 Mbps +/- 20 ppm)
E3 (34.368 Mbps +/- 20 ppm)
STS-1 (51.840 Mbps +/- 20 ppm)
Power Consumption (Typical):
0.550 Amps @ 5 V
Operating Temperature:
32° to 122° F (0° to 50° C)
Storage Temperature:
0° to 160°F (-20° to 70° C)
Humidity:
5 to 95% (non-condensing); 0 to 10,000 ft. altitude
Dimensions:
Single Slot iMcV module
11
