Transmit Coax Data Source (DIP Switch S1, Positions 6 & 7)
These switches select the transmit mode used by the iMcV-DS3/E3-LineTerm
module. The transmit modes that can be selected include the following:
•
Standard data
•
Unframed All Ones (diagnostic)
•
Alternating Ones and Zeros (diagnostic)
•
Pseudorandom Bit Sequence (diagnostic 2
These standard Telco transmission pattern modes are provided to help diagnose
transmission errors in the line.
By default this feature is set to STANDARD DATA.
This feature can be controlled by SNMP-management software (iView
HOST iMcV-DS3/E3-LineTerm module is installed in a managed chassis.
DS3, E3 and STS-1 Selection (DIP Switch S1, Position 8)
This switch selects the data rate to use on the coax line. The data rate selections
available include the following:
•
DS3 (44.736 Mbps +/- 20 ppm)
•
E3 (34.368 Mbps +/- 20 ppm)
•
STS-1 (51.840 Mbps +/- 20 ppm)
By default this feature is set to DS3.
This feature can be selected only by setting the DIP switches manually.
Remote Management (DIP Switch S1, Position 10)
This switch enables or disables the Remote Management mode. Enabling Remote
Management on the Remote module allows all SNMP configurable features for the
Remote modules to be configured from the Host module.
The Remote Management feature must be enabled on the Remote module.
The Remote module cannot be managed by the management chassis it is
located in. The local management can read the card settings but cannot make
changes to them.
By default this feature is Disabled. The module acts as a HOST device in this default
setting.
This feature can be selected only by setting the DIP switches manually.
