• To test McBasic TX/FX by itself, you must have an appropriate fiber
patch cable. First, connect McBasic TX/FX to the twisted pair device
with a twisted pair cable. Next, loop a single strand of fiber from the
transmit port to the receive port of your media converter. Finally, ver-
ify that you have both twisted pair and fiber link on your media con-
verter.
• If attempting to use a high powered device (which is designed for long
distance installations) for a short distance installation, the fiber trans-
mitters may overdrive the receivers and cause data loss. If this is the
case, you may need to add an optical attenuator to your connection.
Please visit our Web site at www.imcnetworks.com/adocs/fcs.asp for
fiber specifications, or contact IMC Networks for more information.

LED Indicators

McBasic TX/FX features four diagnostic LEDs. The functions are:
FX RCV
TX LNK
FA
FX LNK
General Information
I M C N
E T W O R K S
TEL:
FAX:
E-M M ail:
Web:
S
P E C I F I C A T I O N S
Environmental
Operating Temperature: 32° - 104° F (0° - 40° C)
Storage Temperature: 0° - 160° F (-20° - 70° C)
Humidity: 5 - 95% (non-condensing)
Power
AC Input Load: 100/240V±10% ~ 50/60 Hz, 0.1/0.05A
Heat generated: 25 BTU/hr.
Dimensions
1.50"H x 4.65"W x 4.43"D (3.8 cm x 11.8 cm x 11.3 cm)
1.3 lbs. (0.6 kg)
Fiber Optic Specifications
For fiber optic specifications, please visit our Web site at:
http://www.imcnetworks.com/adocs/fcs.asp
Glows yellow when module is receiving data.
Glows green when a twisted pair link is established.
Glows green when FiberAlert is enabled.
Glows green when a fiber link is established.
T
E C H N I C A L
(949) 465-3000; (800) 624-1070 (in the U.S and Canada);
+32-16-550880 (Europe)
(949) 465-3020
techsupport@imcnetworks.com
www.imcnetworks.com
S
U P P O R T
6
