Figure 19 Source Phone Number Manipulation Table for Tel IP Calls
2
In the 'Table Index' drop-down list, select the range of entries that you want to edit (up to
20 entries can be configured for Source Number Manipulation and 50 entries for
Destination Number Manipulation).
3
Configure the Number Manipulation table according to
4 Click the Submit button to save your changes.
5
To save the changes so they are available after a power fail see
page 88.
Table 15 Number Manipulation Parameters
Parameter
Destination Prefix
Source Prefix
Source IP
48
Description
Each entry in the Destination Prefix fields represents a destination
telephone number prefix.
Each entry in the Source Prefix fields represents a source telephone
number prefix.
Each entry in the Source IP fields represents the source IP address of the
call.
This column only applies to the 'Destination Phone Number Manipulation
Table for IP to Tel'.
Note: The source IP address can include the "x" wildcard to represent
single digits. For example: 10.8.8.xx represents all the addresses between
10.8.8.10 to 10.8.8.99.
3Com VCX V7122 SIP VoIP Gateway User Manual
Table 15.
Save Configuration on
