Page 3 HIROSHIMA, JAPAN Important Notes About This Manual Keep this manual in the glove box as a handy reference for the safe and enjoyable use of your Mazda. Should you resell the vehicle, leave this manual with it for the next owner.
Page 4: How To Use This Manual
Mazda. By reading your manual, you can Please refer to the manual for a detailed find out about the features, important explanation.
Page 5: Table Of Contents
Tuesday, September 4 2012 1:22 PM Black plate (5,1) Table of Contents Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Essential Safety Equipment Use of safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags.
Page 6 Mazda5_8CN3-EA-12I_Edition1 Page6 Tuesday, September 4 2012 1:22 PM Black plate (6,1) Form No.8CN3-EA-12I...
Page 7: Your Vehicle At A Glance
Mazda5_8CN3-EA-12I_Edition1 Page7 Tuesday, September 4 2012 1:22 PM Black plate (7,1) Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Interior Overview ................1-2 Interior Equipment (View A) ............ 1-2 Interior Equipment (View B) ............ 1-3 Interior Equipment (View C) ............
Page 8: Interior Overview
Power door lock switch ..................page 3-11 DSC OFF switch ....................page 5-25 Lighting control ....................page 5-56 Turn and lane-change signal ................page 5-60 Dashboard illumination knob ................page 5-40 Instrument cluster ....................page 5-37 Wiper and washer lever ..................page 5-61 Lock release lever ....................
Page 9: Interior Equipment (View B)
Glove compartment ..................page 6-106 Accessory socket ..................... page 6-111 MT shift lever ....................page 5-10 AT shift lever (Sport AT) ................... page 5-12 Ignition switch ..................... page 5-2 Hood release handle ..................page 3-20 The equipment and installation position varies by vehicle...
Page 10: Interior Equipment (View C)
Vanity mirror ...................... page 6-95 Overhead light ....................page 6-96 Rearview mirror ....................page 3-32 Sunvisor ......................page 6-95 Parking brake ....................... page 5-6 Seat warmer switches ..................page 2-16 Front seat ......................page 2-2 Cup holders ...................... page 6-102 Rear ventilation system ..................
Page 11: Exterior Overview
Mazda5_8CN3-EA-12I_Edition1 Page11 Tuesday, September 4 2012 1:22 PM Black plate (11,1) Your Vehicle at a Glance Exterior Overview Front Hood ........................page 3-20 Windshield wiper blades ..................page 8-28 Moonroof ......................page 3-22 Outside mirror ....................page 3-31 Child safety locks ....................page 3-13 Tires ........................
Page 12: Rear
Mazda5_8CN3-EA-12I_Edition1 Page12 Tuesday, September 4 2012 1:22 PM Black plate (12,1) Your Vehicle at a Glance Exterior Overview Rear Rear wiper blade ....................page 8-29 Liftgate ......................page 3-13 Antenna ......................page 6-11 Sliding doors ...................... page 3-11 Door lock ......................page 3-9 Tires ........................
Page 13 Essential Safety Equipment Use of safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Seats ....................2-2 Front Seats ................2-2 Second-Row Seats ..............2-5 Third-Row Seat ............... 2-10 Seat Arrangements ..............2-12 Head Restraints ............... 2-14 í...
Page 14: Seats
Slide result in serious injury. Consult an Authorized Mazda Dealer if there is To move a seat forward or backward, raise any need to remove or reinstall the the lever and slide the seat to the desired front seats.
Page 15 Mazda5_8CN3-EA-12I_Edition1 Page15 Tuesday, September 4 2012 1:22 PM Black plate (15,1) Essential Safety Equipment Seats qSeat Recline Do not drive with the seatback unlocked: WARNING All of the seatbacks play an important role in your protection in a Do not drive with either front seat vehicle.
Page 16 Mazda5_8CN3-EA-12I_Edition1 Page16 Tuesday, September 4 2012 1:22 PM Black plate (16,1) Essential Safety Equipment Seats qArmrest CAUTION The armrest can be used or placed upright. When returning a rear-reclined seatback to its upright position, make sure you hold onto the seatback with your other hand while operating the lever.
Page 17: Second-Row Seats
Mazda5_8CN3-EA-12I_Edition1 Page17 Tuesday, September 4 2012 1:22 PM Black plate (17,1) Essential Safety Equipment Seats Do not drive with the seatback Second-Row Seats unlocked: All of the seatbacks play an WARNING important role in your protection in a Do not stack cargo higher than the vehicle.
Page 18 Mazda5_8CN3-EA-12I_Edition1 Page18 Tuesday, September 4 2012 1:22 PM Black plate (18,1) Essential Safety Equipment Seats qSeat Slide qSeat Recline WARNING To move the seat forward or backward, raise the lever and slide the seat to the Do not drive with the seats reclined: desired position and release the lever.
Page 19 Mazda5_8CN3-EA-12I_Edition1 Page19 Tuesday, September 4 2012 1:22 PM Black plate (19,1) Essential Safety Equipment Seats qThird-Row Seat Access CAUTION After folding the second-row seat When returning a rear-reclined seatback and sliding the seat forward, you seatback to its upright position, can access the third-row seat easily.
Page 20 Otherwise, it could move unexpectedly and cause injury. qFolding the Second-Row Seats 5. If the armrest and storage box are in the position for use, store them. To create a flat luggage compartment Refer to Storage Box on page 6-107.
Page 21 Mazda5_8CN3-EA-12I_Edition1 Page21 Tuesday, September 4 2012 1:22 PM Black plate (21,1) Essential Safety Equipment Seats Returning seatbacks to their original CAUTION positions Ø When folding a seatback, always 1. Return the seatback to its original hold onto the seatback with your position while raising its lever.
Page 22: Third-Row Seat
Mazda5_8CN3-EA-12I_Edition1 Page22 Tuesday, September 4 2012 1:22 PM Black plate (22,1) Essential Safety Equipment Seats Never allow a passenger to sit or stand Third-Row Seat on the folded seatback while the vehicle is moving: WARNING Driving with a passenger on the Do not stack cargo higher than the folded seatback is dangerous.
Page 23 4. Pull the strap and fold the seatback forward. 5. Lock the seatback in place by pushing it down. Make sure the seatback is secured by attempting to lightly move it up and down.
Page 24: Seat Arrangements
Mazda5_8CN3-EA-12I_Edition1 Page24 Tuesday, September 4 2012 1:22 PM Black plate (24,1) Essential Safety Equipment Seats Seat Arrangements Illustrations are of representative seat arrangements. WARNING Do not arrange the seats while driving: Arranging the seats while driving is dangerous because you do not get the full protection from seat belts and you cannot keep your balance.
Page 25 Mazda5_8CN3-EA-12I_Edition1 Page25 Tuesday, September 4 2012 1:22 PM Black plate (25,1) Essential Safety Equipment Seats CAUTION Ø Be careful not to place your hands and fingers around moving parts of the seat when arranging the seat to prevent injury. Ø Do not move around in the vehicle while the seats are folded down. A foot could be injured if it becomes pinched between the seat bottom and seatback.
Page 26 Mazda5_8CN3-EA-12I_Edition1 Page26 Tuesday, September 4 2012 1:22 PM Black plate (26,1) Essential Safety Equipment Seats 2. Fold the second-row seats. Head Restraints Refer to Folding the Second-Row Seats on page 2-8. Your vehicle is equipped with head restraints on all outboard seats. The head To return the seats to their road positions, restraints are intended to help protect you reverse the procedures above.
Page 27 Mazda5_8CN3-EA-12I_Edition1 Page27 Tuesday, September 4 2012 1:22 PM Black plate (27,1) Essential Safety Equipment Seats qNormal Head Restraints Third-Row outboard seat Height adjustment To raise a head restraint, pull it up to the desired position. To lower the head restraint, press the stop- catch release, then push the head restraint down.
Page 28 Mazda5_8CN3-EA-12I_Edition1 Page28 Tuesday, September 4 2012 1:22 PM Black plate (28,1) Essential Safety Equipment Seats To fold the head restraint, pull the strap í Seat Warmer and fold the head restraint downward. To return the head restraint to its upright The front seats are electrically heated.
Page 29 Mazda5_8CN3-EA-12I_Edition1 Page29 Tuesday, September 4 2012 1:22 PM Black plate (29,1) Essential Safety Equipment Seats NOTE WARNING Use the seat warmer when the engine is Ø Be careful when using the seat running, and do not continue to use it for a warmer.
Page 30: Seat Belt Systems
Seat Belt Precautions Seat belts help to decrease the possibility of severe injury during accidents and sudden stops. Mazda recommends that the driver and all passengers always wear seat belts. Your vehicle has the following types of seat belts. With Driver and Front Passenger Occupant Classification System model...
Page 31 Using a damaged seat belt is dangerous. An accident could damage the belt webbing of the seat belt in use. A damaged seat belt cannot provide adequate protection in a collision. Have an Authorized Mazda Dealer inspect all seat belt systems in use during an accident before they are used again.
Page 32 Mazda5_8CN3-EA-12I_Edition1 Page32 Tuesday, September 4 2012 1:22 PM Black plate (32,1) Essential Safety Equipment Seat Belt Systems CAUTION Belt retraction may become difficult if the belts and rings are soiled, so try to keep them clean. For more details about cleaning the seat belts, refer to “Cleaning the Lap/Shoulder Belt Webbing”...
Page 33 Mazda5_8CN3-EA-12I_Edition1 Page33 Tuesday, September 4 2012 1:22 PM Black plate (33,1) Essential Safety Equipment Seat Belt Systems qAutomatic Locking Mode Always use the automatic locking mode to keep the child-restraint system from shifting to an unsafe position in the event of an accident. To enable seat belt automatic locking mode, pull it all the way out and connect it as instructed on the child-restraint system.
Page 34: Seat Belt
Mazda5_8CN3-EA-12I_Edition1 Page34 Tuesday, September 4 2012 1:22 PM Black plate (34,1) Essential Safety Equipment Seat Belt Systems WARNING Seat Belt Positioning the Shoulder Portion of the qFastening the Seat Belt Seat Belt: Improper positioning of the shoulder 1. Grasp the seat belt tongue. portion of the seat belt is dangerous.
Page 35 If a belt does not fully retract, inspect it for kinks and twists. If it is still not retracting WARNING properly, have it inspected at an Authorized Mazda Dealer. Positioning the Shoulder Portion of the Seat Belt: To secure the outboard-rear row seat belts...
Page 36: Front Seat Belt Pretensioner And Load Limiting Systems
Even if the pretensioners have not deployed, the load limiting function must be checked by an Authorized Mazda Dealer after any collision. 2-24 Form No.8CN3-EA-12I...
Page 37 Ask an Authorized Mazda possible. Dealer how to safely dispose of the qAir Bag/Front Seat Belt pretensioner system or how to scrap a pretensioner-equipped vehicle.
Page 38 If a malfunction is detected in the air bag/ front seat belt pretensioner systems and the warning light, a warning beep sound will be heard for about 5 seconds every minute. The air bag and seat belt pretensioner system warning beep sound will continue to be heard for approximately 35 minutes.
Page 39: Seat Belt Extender
If you sell your Mazda, do When ordering an extender, only order not leave your seat belt extender in one that provides the necessary additional the vehicle.
Page 40: Seat Belt Warning Light
Mazda5_8CN3-EA-12I_Edition1 Page40 Tuesday, September 4 2012 1:22 PM Black plate (40,1) Essential Safety Equipment Seat Belt Systems Do not leave a seat belt extender Seat Belt Warning Light connected to the buckle: Leaving a seat belt extender connected to the buckle without using the seat belt is dangerous.
Page 41: Seat Belt Reminder
20 km/h (12 that their seat belts are not fastened. For the mph), the warning light flashes and beep safety of the driver and front passenger, Mazda sound activates again. recommends not deactivating the belt Placing items on the front passenger seat reminder.
Page 42: Child Restraint
Even if the front passenger air bag is shut off, Mazda strongly recommends that children be properly restrained and child-restraint systems of all kinds are properly secured on the rear seats which are the best place for children.
Page 43 Mazda5_8CN3-EA-12I_Edition1 Page43 Tuesday, September 4 2012 1:22 PM Black plate (43,1) Essential Safety Equipment Child Restraint WARNING Use the correct size child-restraint system: For effective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size.
Page 44 Mazda5_8CN3-EA-12I_Edition1 Page44 Tuesday, September 4 2012 1:22 PM Black plate (44,1) Essential Safety Equipment Child Restraint Vehicles with a front passenger air bag have a warning label attached as shown below. The warning label reminds you not to put a rear-facing child-restraint system on the front passenger seat at any time.
Page 45 Mazda5_8CN3-EA-12I_Edition1 Page45 Tuesday, September 4 2012 1:22 PM Black plate (45,1) Essential Safety Equipment Child Restraint Seating a child in a child-restraint system on the front passenger seat is dangerous under certain conditions (With Driver and Front Passenger Occupant Classification System): Your vehicle is equipped with front passenger seat weight sensors.
Page 46 NOTE Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seats. When using these anchors to secure a child-restraint system, refer to “LATCH Child-Restraint Systems” (page 2-43).
Page 47: Child-Restraint System Installation Position
Mazda5_8CN3-EA-12I_Edition1 Page47 Tuesday, September 4 2012 1:22 PM Black plate (47,1) Essential Safety Equipment Child Restraint Child seat Child-Restraint System A child seat restrains a child's body using Installation Position the harness. In this owner's manual, explanation of child-restraint systems is provided for the following three types of popular child- restraint systems: infant seat, child seat, booster seat.
Page 48: Installing Child-Restraint Systems
Follow these instructions when using a installed on the seats that take tethers to child-restraint system, unless you are be effective. In your Mazda, tethered attaching a LATCH-equipped child- child-restraint systems can only be restraint system to the rear LATCH lower accommodated in the four positions on anchors.
Page 49 See the manufacturer's instructions on the child-restraint system for belt routing instructions. 5. To get the retractor into the automatic locking mode, pull the shoulder belt portion of the seat belt until the entire length of the belt is out of the retractor.
Page 50 Mazda5_8CN3-EA-12I_Edition1 Page50 Tuesday, September 4 2012 1:22 PM Black plate (50,1) Essential Safety Equipment Child Restraint Anchor bracket location (Second-row Tether strap position (Third-row seats) seats) Tether strap Forward WARNING Tether strap position (Second-row Use the tether and tether anchor only seats) for a child-restraint system: Tether strap...
Page 51 To check if your front seats have side air not deploy based on the fact that the bags: front passenger air bag deactivation Mazda vehicles equipped with side air bag indicator light illuminates, you will have a “SRS AIRBAG” tag on the should not use a rear-facing child- outboard shoulder of the front seats.
Page 52 Mazda5_8CN3-EA-12I_Edition1 Page52 Tuesday, September 4 2012 1:22 PM Black plate (52,1) Essential Safety Equipment Child Restraint Do not allow a child to lean over or Do not allow a child or anyone to lean against the side window of a vehicle over or against the side window of a with side air bags: vehicle with side and curtain air bags:...
Page 53 ACC, and then re-install the child- restraint system. 5. Push the child-restraint system firmly into the vehicle seat. Be sure the belt retracts as snugly as possible. A clicking noise from the retractor will be heard during retraction if the system is in automatic locking mode.
Page 54 Authorized Mazda Dealer as soon as possible. 2-42 Form No.8CN3-EA-12I...
Page 55: Latch Child-Restraint Systems
Child Restraint LATCH Child-Restraint Systems Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems the second-row seats. Both anchors must be used, otherwise the seat will bounce around and put the child in danger. Most LATCH child- restraint systems must also be used in conjunction with a tether to be effective.
Page 56 Tuesday, September 4 2012 1:22 PM Black plate (56,1) Essential Safety Equipment Child Restraint qLATCH Child-Restraint System 5. If your child-restraint system came equipped with a tether, that means it is Installation Procedure (Second- very important to properly secure the Row Seats) tether for child safety.
Page 57 Mazda5_8CN3-EA-12I_Edition1 Page57 Tuesday, September 4 2012 1:22 PM Black plate (57,1) Essential Safety Equipment Child Restraint WARNING Use the tether and tether anchor only for a child-restraint system: Using the tether or tether anchor to secure anything but a child-restraint system is dangerous.
Page 58: Srs Air Bags
Mazda5_8CN3-EA-12I_Edition1 Page58 Tuesday, September 4 2012 1:22 PM Black plate (58,1) Essential Safety Equipment SRS Air Bags Supplemental Restraint System (SRS) Precautions The front and side supplemental restraint systems (SRS) include 6 air bags. Please verify the air bags equipped on your vehicle by locating the “SRS AIRBAG” location indicators.
Page 59 Mazda5_8CN3-EA-12I_Edition1 Page59 Tuesday, September 4 2012 1:22 PM Black plate (59,1) Essential Safety Equipment SRS Air Bags If your vehicle is also equipped with a driver and front passenger occupant classification system, refer to the Driver and Front Passenger Occupant Classification System (page 2-59) for details.
Page 60 Mazda5_8CN3-EA-12I_Edition1 Page60 Tuesday, September 4 2012 1:22 PM Black plate (60,1) Essential Safety Equipment SRS Air Bags Never use a rear-facing child-restraint system in the front seat with an air bag that could deploy: Rear-facing child-restraint systems on the front seat are particularly dangerous even though you may feel assured that a front passenger air bag will not deploy based on the fact that the front passenger air bag deactivation indicator light illuminates.
Page 61 Mazda5_8CN3-EA-12I_Edition1 Page61 Tuesday, September 4 2012 1:22 PM Black plate (61,1) Essential Safety Equipment SRS Air Bags Do not attach objects on or around the area where a side air bag deploys: Attaching objects to the front seat in such a way as to cover the outboard side of the seat in any way is dangerous.
Page 62 Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and that familiarization with all instructions about them, from the Owner's Manual, is important.
Page 63: Supplemental Restraint System Components
Mazda5_8CN3-EA-12I_Edition1 Page63 Tuesday, September 4 2012 1:22 PM Black plate (63,1) Essential Safety Equipment SRS Air Bags Supplemental Restraint System Components Driver/Front passenger inflators and air bags Crash sensor, and diagnostic module (SAS unit) Front seat belt pretensioner and load limiting systems (page 2-24) Front air bag sensor Side crash sensors Air bag/front seat belt pretensioner system warning light (page 2-54)
Page 64: How The Srs Air Bags Work
SRS Air Bags How the SRS Air Bags Work Your Mazda is equipped with the following types of SRS air bags. SRS air bags are designed to work together with the seat belts to help to reduce injuries during an accident.
Page 65 Mazda5_8CN3-EA-12I_Edition1 Page65 Tuesday, September 4 2012 1:22 PM Black plate (65,1) Essential Safety Equipment SRS Air Bags (With Driver and Front Passenger Occupant Classification System) In addition, the front passenger air bag is designed to only deploy in accordance with the total seated weight on the front passenger seat.
Page 66 A system malfunction is indicated if the warning light constantly flashes, constantly illuminates or does not illuminate at all when the ignition is switched ON. If any of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not operate in an accident.
Page 67 If a malfunction is detected in the air bag/front seat belt pretensioner systems and the warning light, a warning beep sound will be heard for about 5 seconds every minute. The air bag and seat belt pretensioner system warning beep sound will continue to be heard for approximately 35 minutes.
Page 68: Srs Air Bag Deployment Criteria
Mazda5_8CN3-EA-12I_Edition1 Page68 Tuesday, September 4 2012 1:22 PM Black plate (68,1) Essential Safety Equipment SRS Air Bags SRS Air Bag Deployment Criteria This chart indicates the applicable SRS equipment that will deploy depending on the type of collision. (The illustrations are the representative cases of collisions.) Types of collision A severe frontal/near frontal collision A severe side collision...
Page 69: Limitations To Srs Air Bag
Mazda5_8CN3-EA-12I_Edition1 Page69 Tuesday, September 4 2012 1:22 PM Black plate (69,1) Essential Safety Equipment SRS Air Bags Limitations to SRS Air Bag In severe collisions such as those described previously in SRS Air Bag Deployment Criteria , the applicable SRS air bag equipment will deploy. However, in some accidents, the equipment may not deploy depending on the type of collision and its severity.
Page 70 Mazda5_8CN3-EA-12I_Edition1 Page70 Tuesday, September 4 2012 1:22 PM Black plate (70,1) Essential Safety Equipment SRS Air Bags Roll-over 2-58 Form No.8CN3-EA-12I...
Page 71 Mazda5_8CN3-EA-12I_Edition1 Page71 Tuesday, September 4 2012 1:22 PM Black plate (71,1) Essential Safety Equipment SRS Air Bags í Driver and Front Passenger Occupant Classification System First, please read Supplemental Restraint System (SRS) Precautions (page 2-46) carefully. qDriver Seat Slide Position Sensor Your vehicle is equipped with a driver seat slide position sensor as a part of the supplemental restraint system.
Page 72 ON and does not illuminate as indicated in the above chart, do not allow a child to sit in the front passenger seat and consult an Authorized Mazda Dealer as soon as possible. The system may not work properly in an accident.
Page 73 Mazda5_8CN3-EA-12I_Edition1 Page73 Tuesday, September 4 2012 1:22 PM Black plate (73,1) Essential Safety Equipment SRS Air Bags WARNING Do not decrease the total seated weight on the front passenger seat: When an adult or large child sits on the front passenger seat, decreasing the total seated weight on the front passenger seat required for air bag deployment is dangerous.
Page 74 Mazda5_8CN3-EA-12I_Edition1 Page74 Tuesday, September 4 2012 1:22 PM Black plate (74,1) Essential Safety Equipment SRS Air Bags Do not increase the total seated weight on the front passenger seat: When an infant or small child sits on the front passenger seat, increasing the total seated weight on the front passenger seat is dangerous.
Page 75 If the front passenger air bag deactivation indicator light still illuminates, move the passenger to the rear seat. If sitting in the rear seat is not possible, slide the front passenger seat as far back as possible. Consult an Authorized Mazda Dealer as soon as possible.
Page 76: Monitoring And Maintenance
The air bag systems do not require regular maintenance. But if any of the following occurs, take your vehicle to an Authorized Mazda Dealer as soon as possible: The air bag system warning light flashes. The air bag system warning light remains illuminated.
Page 77 Improper disposal of an air bag or a vehicle with live air bags in it can be extremely dangerous. Unless all safety procedures are followed, injury can result. Ask an Authorized Mazda Dealer how to safely dispose of an air bag or how to scrap an air bag equipped vehicle.
Page 78 Mazda5_8CN3-EA-12I_Edition1 Page78 Tuesday, September 4 2012 1:22 PM Black plate (78,1) 2-66 Form No.8CN3-EA-12I...
Page 79: Knowing Your Mazda
Mazda5_8CN3-EA-12I_Edition1 Page79 Tuesday, September 4 2012 1:22 PM Black plate (79,1) Knowing Your Mazda Explanation of basic operations and controls; opening/closing and adjustment of various parts. Doors and Locks ................3-2 Keys ..................3-2 Keyless Entry System ............... 3-3 Door Locks ................3-9 Liftgate ..................
Page 80: Doors And Locks
This could result in If your key is lost, consult your Authorized someone being badly injured or even Mazda Dealer and have your code number killed. Children may find these new ready. kinds of keys to be an interesting toy...
Page 81: Keyless Entry System
NOTE The keyless entry system is designed to operate up to about 2.5 m (8 ft) from the center of the vehicle, but this may vary due to local conditions. The system does not operate when the key is in the ignition switch.
Page 82 Doors and Locks qTransmitter To confirm that all doors and the liftgate have been locked, press the lock button again within 5 seconds. If they are closed Lock button and locked, the horn will sound and the Unlock button hazard warning lights will flash once.
Page 83 To unlock all doors and the liftgate, press NOTE the unlock button again within 5 seconds The panic button will work whether any door and the hazard warning lights will flash or the liftgate is open or closed.
Page 84 Mazda5_8CN3-EA-12I_Edition1 Page84 Tuesday, September 4 2012 1:22 PM Black plate (84,1) Knowing Your Mazda Doors and Locks Declaration of Conformity Keyless entry system Form No.8CN3-EA-12I...
Page 85 Mazda5_8CN3-EA-12I_Edition1 Page85 Tuesday, September 4 2012 1:22 PM Black plate (85,1) Knowing Your Mazda Doors and Locks qTransmitter Maintenance 2. Insert a screwdriver into the slot and push the tab to remove the key from If the buttons on the transmitter are the transmitter.
Page 86 Tuesday, September 4 2012 1:22 PM Black plate (86,1) Knowing Your Mazda Doors and Locks qService 5. Put in the new battery (CR1620 or equivalent) with the positive pole ( If you have a problem with the keyless facing down. entry system, consult an Authorized Mazda Dealer.
Page 87: Door Locks
Mazda5_8CN3-EA-12I_Edition1 Page87 Tuesday, September 4 2012 1:22 PM Black plate (87,1) Knowing Your Mazda Doors and Locks After closing the doors, always verify Door Locks that they are securely closed: Doors not securely closed are WARNING dangerous, if the vehicle is driven...
Page 88 Mazda5_8CN3-EA-12I_Edition1 Page88 Tuesday, September 4 2012 1:22 PM Black plate (88,1) Knowing Your Mazda Doors and Locks qLocking, Unlocking with Door- Sliding doors Lock Knob To lock a sliding door from the inside, slide the door-lock knob toward the front.
Page 89 Mazda5_8CN3-EA-12I_Edition1 Page89 Tuesday, September 4 2012 1:22 PM Black plate (89,1) Knowing Your Mazda Doors and Locks qPower Door Locks Locking, unlocking with door-lock switch Vehicle lock-out prevention All doors and the liftgate lock The vehicle lock-out prevention feature automatically when LOCK is pressed.
Page 90 Mazda5_8CN3-EA-12I_Edition1 Page90 Tuesday, September 4 2012 1:22 PM Black plate (90,1) Knowing Your Mazda Doors and Locks Opening/closing from inside CAUTION To open, pull the inner door handle When opening/closing a sliding door, toward the back. follow the cautions below. If the...
Page 91: Liftgate
Mazda5_8CN3-EA-12I_Edition1 Page91 Tuesday, September 4 2012 1:22 PM Black plate (91,1) Knowing Your Mazda Doors and Locks NOTE Liftgate When closing the sliding door from the fully- opened position and from outside the vehicle, WARNING pull the outside door handle outward to...
Page 92 Mazda5_8CN3-EA-12I_Edition1 Page92 Tuesday, September 4 2012 1:22 PM Black plate (92,1) Knowing Your Mazda Doors and Locks qLocking, Unlocking with Door- CAUTION Lock Switch Ø When loading or unloading The liftgate can be locked/unlocked by luggage in the luggage operating the door-lock switch, refer to compartment, turn off the engine.
Page 93 The door-ajar warning light will illuminate have the vehicle inspected at an if the liftgate is not fully closed. Authorized Mazda Dealer as soon as The sound of the latch may be heard for a possible. few seconds after the electric liftgate...
Page 94: Power Windows
Mazda5_8CN3-EA-12I_Edition1 Page94 Tuesday, September 4 2012 1:22 PM Black plate (94,1) Knowing Your Mazda Doors and Locks qOperating the Driver's Side Power Windows Power Window The ignition must be switched ON for the Normal opening/closing power windows to operate. To open the window to the desired WARNING position, lightly hold down the switch.
Page 95 Mazda5_8CN3-EA-12I_Edition1 Page95 Tuesday, September 4 2012 1:22 PM Black plate (95,1) Knowing Your Mazda Doors and Locks Power window system initialization WARNING procedure Make sure nothing blocks the window If the battery was disconnected during just before it reaches the fully closed...
Page 96 Mazda5_8CN3-EA-12I_Edition1 Page96 Tuesday, September 4 2012 1:22 PM Black plate (96,1) Knowing Your Mazda Doors and Locks qOperating the Passenger Power qPower Window Lock Switch Windows This feature prevents all power windows from operating, except the driver's power The power windows may be operated window.
Page 97: Fuel-Filler Lid And Cap
Attach the removed cap to the inner side CAUTION of the fuel lid. Always use only a genuine Mazda To close the fuel-filler cap, turn it fuel-filler cap or an approved clockwise until a click is heard. equivalent, available at an Authorized Mazda Dealer.
Page 98: Hood
Contact an Authorized accident. Mazda Dealer as soon as possible. qOpening the Hood 1. With the vehicle parked, pull the release handle to unlock the hood. 2. Insert your hand into the hood opening, slide the hood latch lever, and lift the hood.
Page 99 Mazda5_8CN3-EA-12I_Edition1 Page99 Tuesday, September 4 2012 1:22 PM Black plate (99,1) Knowing Your Mazda Doors and Locks qClosing the Hood 3. Grasp the support rod in the padded area and secure it in the support rod 1. Check under the hood area to make...
Page 100: Moonroof Í
The moonroof can be opened or closed does not get inside the cabin area. After electrically only when the ignition is washing your Mazda or after it rains, wipe the switched ON. water off the moonroof before operating it to...
Page 101 Mazda5_8CN3-EA-12I_Edition1 Page101 Tuesday, September 4 2012 1:23 PM Black plate (101,1) Knowing Your Mazda Doors and Locks qSunshade To close to the desired position, press the front of the tilt or slide switch. The sunshade can be opened and closed by hand.
Page 102: Security System
Mazda5_8CN3-EA-12I_Edition1 Page102 Tuesday, September 4 2012 1:23 PM Black plate (102,1) Knowing Your Mazda Security System CAUTION Immobilizer System When starting the engine do not The immobilizer system allows the engine allow the following, as the engine to start only with a key the system may not start due to the electronic recognizes.
Page 103 Always keep a spare key, in case one is lost. If a key is lost, contact an Authorized Mazda Dealer as soon as possible. If you lose a key, an Authorized Mazda Dealer will reset the electronic codes of your remaining keys and immobilizer system.
Page 104 Mazda5_8CN3-EA-12I_Edition1 Page104 Tuesday, September 4 2012 1:23 PM Black plate (104,1) Knowing Your Mazda Security System Declaration of Conformity Immobilizer system 3-26 Form No.8CN3-EA-12I...
Page 105 Disarming shut off the engine. Go to an Authorized The system is disarmed when the ignition Mazda Dealer and have it checked. If you is switched ON with the correct ignition shut off the engine while the light is key.
Page 106: Theft-Deterrent System Í
Mazda5_8CN3-EA-12I_Edition1 Page106 Tuesday, September 4 2012 1:23 PM Black plate (106,1) Knowing Your Mazda Security System NOTE í Theft-Deterrent System If the battery goes dead while the theft- deterrent system is armed, the horn will If the theft deterrent system detects an...
Page 107 NOTE Unlocking the driver's door with the key. If you have any problem with the theft- The hood is opened. deterrent system, consult an Authorized Mazda The key is inserted in the ignition switch. Dealer. The ignition is switched ON.
Page 108 Security System qTheft-Deterrent Labels A label indicating that your vehicle is equipped with a Theft-Deterrent System is in the glove compartment. Mazda recommends that you affix it to the lower rear corner of a front door window. 3-30 Form No.8CN3-EA-12I...
Page 109: Steering Wheel And Mirrors
Mazda5_8CN3-EA-12I_Edition1 Page109 Tuesday, September 4 2012 1:23 PM Black plate (109,1) Knowing Your Mazda Steering Wheel and Mirrors Steering Wheel Mirrors WARNING qOutside Mirrors Never adjust the steering wheel while Check the mirror angles before driving. the vehicle is moving:...
Page 110 Mazda5_8CN3-EA-12I_Edition1 Page110 Tuesday, September 4 2012 1:23 PM Black plate (110,1) Knowing Your Mazda Steering Wheel and Mirrors qRearview Mirror 2. Depress the mirror switch in the appropriate direction. Rearview mirror adjustment Selector switch Before driving, adjust the rearview mirror to center on the scene through the rear window.
Page 111 Mazda5_8CN3-EA-12I_Edition1 Page111 Tuesday, September 4 2012 1:23 PM Black plate (111,1) Knowing Your Mazda Steering Wheel and Mirrors WARNING Do not stack cargo or objects higher than the seatbacks: Cargo stacked higher than the seatbacks is dangerous. It can block...
Page 112 Mazda5_8CN3-EA-12I_Edition1 Page112 Tuesday, September 4 2012 1:23 PM Black plate (112,1) 3-34 Form No.8CN3-EA-12I...
Page 113: Before Driving Your Mazda
Fuel and Engine Exhaust Precautions ........4-2 Fuel Requirements ..............4-2 Emission Control System ............4-3 Engine Exhaust (Carbon Monoxide) ......... 4-4 Before Starting the Engine ............4-5 Before Getting In ..............4-5 After Getting In ................. 4-5 Driving Tips ................... 4-6 Break-In Period .................
Page 114: Fuel And Engine Exhaust Precautions
Fuel Requirements Vehicles with catalytic converters or oxygen sensors must use ONLY UNLEADED FUEL, which will reduce exhaust emissions and keep spark plug fouling to a minimum. Your Mazda will perform best with fuel listed in the table. Fuel Octane Rating...
Page 115: Emission Control System
Ø Do not descend steep grades in gear with the ignition switched off. Ø Do not operate the engine at high idle for more than 5 minutes. Ø Do not tamper with the emission control system. All inspections and adjustments must be made by a qualified technician.
Page 116: Engine Exhaust (Carbon Monoxide)
When inhaled, it can cause loss of consciousness and death. If you smell exhaust gas inside your vehicle, keep all windows fully open and contact an Authorized Mazda Dealer immediately. Do not run the engine when inside an enclosed area: Running the engine inside an enclosed area, such as a garage, is dangerous.
Page 117: Before Starting The Engine
Mazda5_8CN3-EA-12I_Edition1 Page117 Tuesday, September 4 2012 1:23 PM Black plate (117,1) Before Driving Your Mazda Before Starting the Engine Before Getting In After Getting In Be sure the windows, outside mirrors, Are all doors closed and locked? and outside lights are clean.
Page 118: Driving Tips
Break-In Period Money-Saving Suggestions No special break-in is necessary, but a few How you operate your Mazda determines precautions in the first 1,000 km (600 how far it will travel on a tank of fuel. Use miles) may add to the performance, these suggestions to help save money on economy, and life of your Mazda.
Page 119: Hazardous Driving
Do not pump the brakes. Continue to press down on the brake pedal. Refer to Anti-Lock Brake System (ABS) on page 5-8. If you get stuck, select a lower gear and accelerate slowly. Do not spin the front wheels.
Page 120: Rocking The Vehicle
(35 mph), and do not allow of sand or salt. anyone to stand behind a wheel when Ask an Authorized Mazda Dealer to pushing the vehicle: perform the following precautions: When the vehicle is stuck, spinning...
Page 121 CAUTION Install the chains on the front tires. Do not use chains on the rear tires. Check local regulations before using Please consult an Authorized Mazda studded tires. Dealer. NOTE Installing the chains If your vehicle is equipped with the tire 1.
Page 122: Driving In Flooded Area
Mazda5_8CN3-EA-12I_Edition1 Page122 Tuesday, September 4 2012 1:23 PM Black plate (122,1) Before Driving Your Mazda Driving Tips Driving In Flooded Area Overloading WARNING WARNING Dry wet brakes by driving very slowly Be careful not to overload your vehicle: and applying the brakes lightly until...
Page 123: Driving On Uneven Road
Mazda5_8CN3-EA-12I_Edition1 Page123 Tuesday, September 4 2012 1:23 PM Black plate (123,1) Before Driving Your Mazda Driving Tips Driving on Uneven Road Your vehicle's suspension and underbody can be damaged if driven on rough/uneven roads or over speed bumps at excessive speeds. Use care and reduce speed when traveling on rough/uneven roads or over speed bumps.
Page 124: Towing
Mazda5_8CN3-EA-12I_Edition1 Page124 Tuesday, September 4 2012 1:23 PM Black plate (124,1) Before Driving Your Mazda Towing Trailer Towing The Mazda5 is not designed for towing. Never tow a trailer with your Mazda5. 4-12 Form No.8CN3-EA-12I...
Page 125: Driving Your Mazda
Parking Sensor System ............5-32 Instrument Cluster and Indicators ..........5-37 Meters and Gauges ..............5-37 Warning/Indicator Lights and Beep Sounds ......5-41 Warning/Indicator Lights ............5-41 Beep Sounds ................5-54 Switches and Controls ..............5-56 Lighting Control ..............5-56 Turn and Lane-Change Signals ..........
Page 126: Starting And Driving
ACC (Accessory) In this position, some electrical accessories will operate. This is the normal running position after the engine is started. Some indicator lights/warning lights should be inspected before the engine is started (page 5-41). Form No.8CN3-EA-12I...
Page 127: Starting The Engine
(Automatic transaxle) The starter will not operate if the shift lever is not in P or N. 5. Switch the ignition to START and hold (up to 10 seconds at a time) until the engine starts. CAUTION Do not try the starter for more than 10 seconds at a time.
Page 128: Turning The Engine Off
Emergency Starting. If the engine still does accident and serious injury. not start, have your vehicle inspected by an Authorized Mazda Dealer (page 7-16). 1. Stop the vehicle completely. 2. (Manual transaxle) Shift into neutral.
Page 129: Brake System
Do not coast with the engine stalled or qFoot Brake turned off, find a safe place to stop: Coasting with the engine stalled or Your Mazda has power-assisted brakes turned off is dangerous. Braking will that adjust automatically through normal require more effort, and the brake's use.
Page 130 Mazda5_8CN3-EA-12I_Edition1 Page130 Tuesday, September 4 2012 1:23 PM Black plate (130,1) Driving Your Mazda Starting and Driving qParking Brake CAUTION WARNING Ø Do not drive with your foot held on the clutch pedal or brake pedal, Before leaving the driver's seat, always...
Page 131 Have it towed to an Authorized Mazda Dealer. Even if the light turns off, have your brake system inspected as soon as possible by an Authorized Mazda Dealer. Form No.8CN3-EA-12I...
Page 132 Do not rely on ABS as a substitute for indicator of leakage. Consult an Authorized safe driving: Mazda Dealer as soon as possible even if the The ABS cannot compensate for brake light is no longer illuminated. unsafe and reckless driving, excessive...
Page 133 Have the vehicle towed to as if the vehicle had no ABS. an Authorized Mazda Dealer to have Should this happen, consult an Authorized the brakes inspected as soon as Mazda Dealer as soon as possible.
Page 134: Manual Transaxle Operation
Mazda5_8CN3-EA-12I_Edition1 Page134 Tuesday, September 4 2012 1:23 PM Black plate (134,1) Driving Your Mazda Starting and Driving WARNING Manual Transaxle Operation Do not use sudden engine braking on qManual Transaxle Shift Pattern slippery road surfaces or at high speeds: Shifting down while driving on wet,...
Page 135 1 to 2 25 km/h (15 mph) 2 to 3 42 km/h (26 mph) 3 to 4 60 km/h (37 mph) 4 to 5 75 km/h (46 mph) 5 to 6 79 km/h (49 mph) For cruising Gear Vehicle speed...
Page 136: Automatic Transaxle Controls
If you notice the engine speed going higher or hear the engine racing, confirm you have not accidentally slipped into manual shift mode (page 5-14). 5-12...
Page 137 Gears can be shifted up or down by locked. The vehicle will roll freely even operating the shift lever. on the slightest incline unless the parking Refer to Manual Shift Mode (page 5-14). brake or brakes are on. 5-13 Form No.8CN3-EA-12I...
Page 138 3. Move the shift lever. qShift-Lock System 4. Take the vehicle to an Authorized Mazda Dealer to have the system The shift-lock system prevents shifting checked. out of P unless the brake pedal is depressed.
Page 139 Mazda5_8CN3-EA-12I_Edition1 Page139 Tuesday, September 4 2012 1:23 PM Black plate (139,1) Driving Your Mazda Starting and Driving Gear position indicator The numeral for the selected gear illuminates. Shift position indicator To return to automatic shift mode, shift the lever from M to D.
Page 140 Mazda5_8CN3-EA-12I_Edition1 Page140 Tuesday, September 4 2012 1:23 PM Black plate (140,1) Driving Your Mazda Starting and Driving Shifting Manually Shifting down (M5 → M4 → M3 → M2 → M1) Manually Shifting up To shift down to a lower gear, tap the shift (M1 →...
Page 141 When the shift lever is tapped back ( the following: while the vehicle is stopped or driven at about 12 km/h (7.5 mph) or less, the Gear Vehicle speed transaxle is set in the second gear fixed M5 or M4 →...
Page 142: Power Steering
Never hold the steering wheel to the extreme left or right for more than 5 Passing seconds with the engine running. For extra power when passing another...
Page 143: Cruise Control Í
Mazda5_8CN3-EA-12I_Edition1 Page143 Tuesday, September 4 2012 1:23 PM Black plate (143,1) Driving Your Mazda Starting and Driving If the light remains illuminated after the í Cruise Control engine is started, or illuminates while driving, turn off the engine after parking...
Page 144 Mazda5_8CN3-EA-12I_Edition1 Page144 Tuesday, September 4 2012 1:23 PM Black plate (144,1) Driving Your Mazda Starting and Driving qActivation/Deactivation 3. Set the cruise control by pressing the cruise control SET /SET - switch up To activate the system, press the ON or down at the desired speed.
Page 145 Mazda5_8CN3-EA-12I_Edition1 Page145 Tuesday, September 4 2012 1:23 PM Black plate (145,1) Driving Your Mazda Starting and Driving qTo Increase Cruising Speed To increase speed using accelerator pedal Follow either of these procedures. Depress the accelerator pedal to accelerate To increase speed using cruise control to the desired speed.
Page 146 Mazda5_8CN3-EA-12I_Edition1 Page146 Tuesday, September 4 2012 1:23 PM Black plate (146,1) Driving Your Mazda Starting and Driving Your vehicle has a tap-down feature that Press the CANCEL switch. allows you to decrease your current speed in decrements of 1.6 km/h (1 mph) by a momentary tap of the cruise control SET - switch.
Page 147: Traction Control System (Tcs)
Mazda5_8CN3-EA-12I_Edition1 Page147 Tuesday, September 4 2012 1:23 PM Black plate (147,1) Driving Your Mazda Starting and Driving qTCS/DSC Indicator Light Traction Control System (TCS) The Traction Control System (TCS) enhances traction and safety by controlling engine torque and braking. When the TCS detects driving wheel...
Page 148: Dynamic Stability Control (Dsc)
Ø Do not mix worn tires. Ø The DSC may not operate correctly Refer to ABS (page 5-8) and TCS (page when tire chains are used or a 5-23). temporary spare tire is installed because the tire diameter changes.
Page 149 It also illuminates when the DSC OFF best stability. switch is pressed and TCS/DSC is switched off (page 5-25). If the light stays on when the TCS/DSC is not switched off, take your vehicle to an Authorized Mazda Dealer. The dynamic stability control may have a malfunction.
Page 150: Tire Pressure Monitoring System Í
Mazda5_8CN3-EA-12I_Edition1 Page150 Tuesday, September 4 2012 1:23 PM Black plate (150,1) Driving Your Mazda Starting and Driving í Tire Pressure Monitoring System The tire pressure monitoring system (TPMS) monitors the pressure for each tire. If tire pressure is too low in one or more tires, the system will inform the driver via the warning light in the instrument panel and by the warning beep sound.
Page 151 Mazda5_8CN3-EA-12I_Edition1 Page151 Tuesday, September 4 2012 1:23 PM Black plate (151,1) Driving Your Mazda Starting and Driving CAUTION Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label.
Page 152 Authorized Mazda Dealer or a tire repair station. Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated.
Page 153 Leaks need to be addressed by more than simply refilling the trouble tire as leaks are dangerous - take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order the best replacement tire for your vehicle.
Page 154 Consult an The easiest way to do it is to have an Authorized Mazda Dealer. Authorized Mazda Dealer change your tire and A system error activation may occur in complete ID signal code registration. the following cases:...
Page 155 Replacing tires and wheels CAUTION Ø When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. Ø The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors.
Page 156: Parking Sensor System Í
Mazda5_8CN3-EA-12I_Edition1 Page156 Tuesday, September 4 2012 1:23 PM Black plate (156,1) Driving Your Mazda Starting and Driving í Parking Sensor System The parking sensor system uses ultrasonic sensors to detect obstructions around the vehicle while parking the vehicle in a garage or during parallel parking when the vehicle is driven at a speed of about 10 km/h (6 mph) or less.
Page 157 Very tall objects, and those which are wide at the top Small, short objects Always have the system inspected at an Authorized Mazda Dealer if any shock is applied to the bumpers, even in a minor accident. If the sensors are deviated, they cannot detect obstructions.
Page 158 Mazda5_8CN3-EA-12I_Edition1 Page158 Tuesday, September 4 2012 1:23 PM Black plate (158,1) Driving Your Mazda Starting and Driving qSensor Detection Range The sensors detect obstructions within the following range. Unit: cm (in) A: About 50 (About 20) Rear corner sensor detection range B: About 150 (About 59.1)
Page 159 Mazda5_8CN3-EA-12I_Edition1 Page159 Tuesday, September 4 2012 1:23 PM Black plate (159,1) Driving Your Mazda Starting and Driving Operation Conditions The system can be used when the ignition is switched ON. The sensors detect obstructions under the following conditions: Sensor Condition Rear Sensor The shift lever is in reverse (R).
Page 160 Authorized Mazda Dealer as soon as possible. reverse (R). The intermittent sound of the Remove any foreign material from the sensor area. If the system does not buzzer is heard five times. recover, have the vehicle inspected at an Authorized Mazda Dealer. 5-36 Form No.8CN3-EA-12I...
Page 161: Instrument Cluster And Indicators
Black plate (161,1) Driving Your Mazda Instrument Cluster and Indicators Meters and Gauges Speedometer ...................... page 5-38 Odometer, Trip Meter and Trip Meter Selector ..........page 5-38 Tachometer ......................page 5-39 Fuel Gauge ......................page 5-39 Dashboard Illumination ..................page 5-40 5-37...
Page 162 Mazda5_8CN3-EA-12I_Edition1 Page162 Tuesday, September 4 2012 1:23 PM Black plate (162,1) Driving Your Mazda Instrument Cluster and Indicators qSpeedometer The speedometer indicates the speed of the vehicle. qOdometer, Trip Meter and Trip Meter Selector The display mode can be changed...
Page 163 Mazda5_8CN3-EA-12I_Edition1 Page163 Tuesday, September 4 2012 1:23 PM Black plate (163,1) Driving Your Mazda Instrument Cluster and Indicators qTachometer For instance, trip meter A can record the distance from the point of origin, and trip The tachometer shows engine speed in...
Page 164 Mazda5_8CN3-EA-12I_Edition1 Page164 Tuesday, September 4 2012 1:23 PM Black plate (164,1) Driving Your Mazda Instrument Cluster and Indicators If the gauge indicates that the fuel level is When driving on snowy or foggy roads, near E, refuel as soon as possible.
Page 165: Warning/Indicator Lights And Beep Sounds
Mazda5_8CN3-EA-12I_Edition1 Page165 Tuesday, September 4 2012 1:23 PM Black plate (165,1) Driving Your Mazda Warning/Indicator Lights and Beep Sounds Warning/Indicator Lights Warning/Indicator lights will appear in any of the highlighted areas Signal Warning/Indicator Lights Page Brake System Warning Light 5-43...
Page 166 Mazda5_8CN3-EA-12I_Edition1 Page166 Tuesday, September 4 2012 1:23 PM Black plate (166,1) Driving Your Mazda Warning/Indicator Lights and Beep Sounds Signal Warning/Indicator Lights Page Air Bag/Front Seat Belt Pretensioner System Warning Light 5-47 Low Fuel Warning Light 5-47 Check Fuel Cap Warning Light...
Page 167 Parking brake warning indicator of leakage. Consult an Authorized The light illuminates when the parking Mazda Dealer as soon as possible even if the brake is applied with the ignition switched brake light is no longer illuminated. to START or ON. It turns off when the WARNING parking brake is fully released.
Page 168 ABS. Should this happen, consult an Authorized Mazda Dealer as soon as possible. NOTE When the engine is jump-started to charge the When the ignition is switched ON, the...
Page 169 System Warning Light 1. Drive to the side of the road and park off the right-of-way on level ground. 2. Turn off the engine and wait 5 minutes for the oil to drain back into the oil pan. 3. Inspect the engine oil level (page 8-21).
Page 170 If the check engine light remains on or engine coolant temperature warning flashes continuously, do not drive at high light illuminated. Otherwise, it could speeds and consult an Authorized Mazda result in damage to the engine. Dealer as soon as possible. 5-46...
Page 171 ON. If any of these occur, This warning light illuminates for a few consult an Authorized Mazda Dealer as seconds when the ignition is switched soon as possible. The system may not operate in an accident.
Page 172 Close the door or liftgate securely before an electrical problem. Continuing to driving the vehicle. drive your Mazda in this condition could cause damage to your transaxle. Consult an Authorized Mazda Dealer as soon as possible.
Page 173 Authorized Mazda Dealer or a tire repair station. Do not ignore the TPMS Warning Light: Ignoring the TPMS warning light is dangerous, even if you know why it is illuminated.
Page 174 Leaks need to be addressed by more than simply refilling the trouble tire as leaks are dangerous - take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order the best replacement tire for your vehicle.
Page 175 Mazda5_8CN3-EA-12I_Edition1 Page175 Tuesday, September 4 2012 1:23 PM Black plate (175,1) Driving Your Mazda Warning/Indicator Lights and Beep Sounds qHeadlight High-Beam Indicator If the warning light illuminates again even after the tire pressures are adjusted, there Light may be a tire puncture. Replace the punctured tire with the temporary spare tire (page 7-7).
Page 176 It also illuminates when the DSC OFF Authorized Mazda Dealer. switch is pressed and TCS/DSC is switched off (page 5-25). qTCS/DSC Indicator Light If the light stays on when the TCS/DSC is not switched off, take your vehicle to an Authorized Mazda Dealer.
Page 177 ON, and turns off when the engine is started. When operating the turn signal lights, the left or right turn signal indicator light flashes to indicate which turn signal light is operating (page 5-60). 5-53 Form No.8CN3-EA-12I...
Page 178: Beep Sounds
5 seconds every minute. The air bag and seat belt pretensioner system warning beep sound will continue to be heard for approximately 35 minutes.
Page 179 Mazda5_8CN3-EA-12I_Edition1 Page179 Tuesday, September 4 2012 1:23 PM Black plate (179,1) Driving Your Mazda Warning/Indicator Lights and Beep Sounds qSeat Belt Warning Beep qLights-On Reminder If the driver's seat belt is not fastened If lights are on and the key is removed...
Page 180: Switches And Controls
Mazda5_8CN3-EA-12I_Edition1 Page180 Tuesday, September 4 2012 1:23 PM Black plate (180,1) Driving Your Mazda Switches and Controls Lighting Control qHeadlights Turn the headlight switch to turn the headlights, other exterior lights and dashboard illumination on or off. NOTE To prevent discharging the battery, do not leave the lights on while the engine is off unless safety requires them.
Page 181 Mazda5_8CN3-EA-12I_Edition1 Page181 Tuesday, September 4 2012 1:23 PM Black plate (181,1) Driving Your Mazda Switches and Controls Switch Position Headlights Taillights Parking lights Auto License lights Side-marker lights Dashboard illumination AUTO (Auto-light control) When the headlight switch is in the AUTO position and the ignition is switched ON, the light sensor senses the surrounding lightness or darkness and automatically turns the headlights, other exterior lights and dashboard illumination on or off (see chart above).
Page 182 When the headlight switch is in the AUTO position and the ignition is switched to ACC or the ignition is switched off, the headlights, other exterior lights and dashboard illumination will turn off. The sensitivity of the AUTO lights may be changed by an Authorized Mazda Dealer. Refer to Personalization Features on page 10-8. í...
Page 183 Mazda5_8CN3-EA-12I_Edition1 Page183 Tuesday, September 4 2012 1:23 PM Black plate (183,1) Driving Your Mazda Switches and Controls qLights-On Reminder qFlashing the Headlights If lights are on and the key is removed To flash the headlights, pull the lever fully from the ignition switch, a continuous...
Page 184: Turn And Lane-Change Signals
Mazda5_8CN3-EA-12I_Edition1 Page184 Tuesday, September 4 2012 1:23 PM Black plate (184,1) Driving Your Mazda Switches and Controls Select the proper headlight angle from the following Turn and Lane-Change chart. Signals Front seat Rear Switch Load seat Position Driver Passenger Turn Signals ×...
Page 185: Fog Lights Í
Mazda5_8CN3-EA-12I_Edition1 Page185 Tuesday, September 4 2012 1:23 PM Black plate (185,1) Driving Your Mazda Switches and Controls í Fog Lights Windshield Wipers and Washer The fog lights will improve visibility at night and during foggy conditions. The ignition must be switched ON.
Page 186 High speed and ice. With AUTO position After 5 minutes, turn on the switch and the blades should operate normally. If they do not resume functioning, consult an Authorized Mazda Dealer as soon as possible. Drive to the side of the road and park off the right-of- way.
Page 187 Mazda5_8CN3-EA-12I_Edition1 Page187 Tuesday, September 4 2012 1:23 PM Black plate (187,1) Driving Your Mazda Switches and Controls The sensitivity of the rain sensor can be Variable-speed intermittent wipers adjusted by turning the switch on the Set the lever to the intermittent position wiper lever.
Page 188 Mazda5_8CN3-EA-12I_Edition1 Page188 Tuesday, September 4 2012 1:23 PM Black plate (188,1) Driving Your Mazda Switches and Controls Ø When the wiper lever is in the NOTE AUTO position and the ignition is Switching the auto-wiper lever from the switched ON, the wipers may...
Page 189: Rear Window Wiper And Washer
If the washer does not work, inspect the Switch Position fluid level (page 8-26). If it's normal, Wiper operation Type Type consult an Authorized Mazda Dealer. INT Intermittent ON Normal qRear Window Washer To spray washer fluid, turn the rear wiper/ washer switch to the position.
Page 190: Rear Window Defroster
The rear window defroster clears frost, the ignition ON and press the rear window fog, and thin ice from the rear window. defroster switch (page 5-66). The ignition must be switched ON. Press the switch to turn on the rear window defroster.
Page 191: Horn
Mazda5_8CN3-EA-12I_Edition1 Page191 Tuesday, September 4 2012 1:23 PM Black plate (191,1) Driving Your Mazda Switches and Controls Horn Hazard Warning Flasher To sound the horn, press the mark on The hazard warning lights should always the steering wheel. be used when you stop on or near a roadway in an emergency.
Page 192 Mazda5_8CN3-EA-12I_Edition1 Page192 Tuesday, September 4 2012 1:23 PM Black plate (192,1) 5-68 Form No.8CN3-EA-12I...
Page 193: Interior Comfort
Convenient Use of the Hands-Free System ......6-81 Hands-Free Setting ..............6-87 When Bluetooth® Hands-Free Cannot be Used ..... 6-93 Safety Certification ..............6-94 Mazda Bluetooth® Hands-Free Customer Service ....6-94 Interior Equipment ..............6-95 Sunvisors ................. 6-95 Interior Lights ................. 6-95 Information Display ..............
Page 194 It is necessary to change the filter periodically as indicated qOutside/Recirculated Air Position in scheduled maintenance (page 8-4). Consult an Authorized Mazda Dealer for Use the outside air mode for ventilation or replacement of the cabin air filter. windshield defrosting. The recirculate...
Page 195: Climate Control System
Mazda5_8CN3-EA-12I_Edition1 Page195 Tuesday, September 4 2012 1:23 PM Black plate (195,1) Interior Comfort Climate Control System Vent Operation qAdjusting the Vents Center Vents To adjust the direction of airflow, move Directing airflow the adjustment knob. Side Vents To adjust the direction of airflow, open the Knob Dial vents and rotate them left and right.
Page 196 Mazda5_8CN3-EA-12I_Edition1 Page196 Tuesday, September 4 2012 1:24 PM Black plate (196,1) Interior Comfort Climate Control System qSelecting the Airflow Mode Dashboard Vents Defroster and Floor Vents Dashboard and Floor Vents Defroster Vents Floor Vents Form No.8CN3-EA-12I...
Page 197: Fully Automatic Type
Mazda5_8CN3-EA-12I_Edition1 Page197 Tuesday, September 4 2012 1:24 PM Black plate (197,1) Interior Comfort Climate Control System Fully Automatic Type Climate control information is displayed on the information display. Auto switch Windshield defroster switch OFF switch Temperature control dial Mode selector switch Fan control dial A/C switch Air intake selector...
Page 198 Mazda5_8CN3-EA-12I_Edition1 Page198 Tuesday, September 4 2012 1:24 PM Black plate (198,1) Interior Comfort Climate Control System OFF switch Mode selector switch Pressing the OFF switch shuts off the The desired airflow mode can be selected climate control system. (page 6-4). Temperature control dial NOTE With the airflow mode set to...
Page 199 Mazda5_8CN3-EA-12I_Edition1 Page199 Tuesday, September 4 2012 1:24 PM Black plate (199,1) Interior Comfort Climate Control System Pressing the A/C switch while the AUTO WARNING switch is turned on will turn off the air Do not use the position in cold or conditioning (cooling/dehumidifying rainy weather: functions).
Page 200 Mazda5_8CN3-EA-12I_Edition1 Page200 Tuesday, September 4 2012 1:24 PM Black plate (200,1) Interior Comfort Climate Control System qOperation of Automatic Air qWindshield Defrosting and Defogging Conditioning 1. Press the AUTO switch. Selection of the airflow mode, air intake selector and amount of airflow will be automatically controlled.
Page 201: Rear Ventilation System
Mazda5_8CN3-EA-12I_Edition1 Page201 Tuesday, September 4 2012 1:24 PM Black plate (201,1) Interior Comfort Climate Control System qTemperature Sensor Rear Ventilation System The fully automatic air conditioner uses The rear ventilation system only blows the temperature sensor to measure the cool air through the rear vents while the temperature inside the passenger front climate control system is on.
Page 202 Mazda5_8CN3-EA-12I_Edition1 Page202 Tuesday, September 4 2012 1:24 PM Black plate (202,1) Interior Comfort Climate Control System Rear vent buttons The rear vent switches adjust the airflow volume flowing from the rear vent. OFF: Fan off LO: Low speed HI: High speed NOTE Only cool or cold air (no heat) blows through the rear vents while the front climate control is...
Page 203: Audio System
Mazda5_8CN3-EA-12I_Edition1 Page203 Tuesday, September 4 2012 1:24 PM Black plate (203,1) Interior Comfort Audio System CAUTION Antenna Ø To prevent damage to the qDetachable Type antenna, remove it before entering a car wash facility or passing To remove the antenna, turn it beneath a low overhead clearance.
Page 204: Operating Tips For Audio System
Mazda5_8CN3-EA-12I_Edition1 Page204 Tuesday, September 4 2012 1:24 PM Black plate (204,1) Interior Comfort Audio System qRadio Reception Operating Tips for Audio System AM characteristics AM signals bend around such things as WARNING buildings or mountains and bounce off the ionosphere. Therefore, they can reach Do not adjust the audio control longer distances than FM signals.
Page 205 Mazda5_8CN3-EA-12I_Edition1 Page205 Tuesday, September 4 2012 1:24 PM Black plate (205,1) Interior Comfort Audio System Signals from an FM transmitter are similar Flutter/Skip noise to beams of light because they do not Signals from an FM transmitter move in bend around corners, but they do reflect. straight lines and become weak in valleys Unlike AM signals, FM signals cannot between tall buildings, mountains, and...
Page 206 Mazda5_8CN3-EA-12I_Edition1 Page206 Tuesday, September 4 2012 1:24 PM Black plate (206,1) Interior Comfort Audio System qOperating Tips for CD Player Strong signal noise This occurs very close to a transmitter Condensation phenomenon tower. The broadcast signals are Immediately after turning on the heater extremely strong, so the result is noise and when the vehicle is cold, the CD or sound breakup at the radio receiver.
Page 207 Mazda5_8CN3-EA-12I_Edition1 Page207 Tuesday, September 4 2012 1:24 PM Black plate (207,1) Interior Comfort Audio System The CD revolves at high speed within A new CD may have rough edges on the unit. Defective (cracked or badly its inner and outer perimeters. If a disc bent) CDs should never be used.
Page 208 Mazda5_8CN3-EA-12I_Edition1 Page208 Tuesday, September 4 2012 1:24 PM Black plate (208,1) Interior Comfort Audio System Use discs that have been legitimately Do not insert any disc with a peel-off produced. If illegally-copied discs such seal affixed to it. as pirated discs are used, the system This unit may not be able to play may not operate properly.
Page 209 Mazda5_8CN3-EA-12I_Edition1 Page209 Tuesday, September 4 2012 1:24 PM Black plate (209,1) Interior Comfort Audio System qOperating tips for MP3 If a disc has both music data (CD-DA) and MP3 files, playback of the two file NOTE types differs depending on how the Supply of this product only conveys a license disc was recorded.
Page 210 Mazda5_8CN3-EA-12I_Edition1 Page210 Tuesday, September 4 2012 1:24 PM Black plate (210,1) Interior Comfort Audio System The number of characters which can be : Folder : Track (File) displayed is restricted. Folder CAUTION This unit can only play MP3 files that have an MP3 file extension (.mp3) attached.
Page 211 Mazda5_8CN3-EA-12I_Edition1 Page211 Tuesday, September 4 2012 1:24 PM Black plate (211,1) Interior Comfort Audio System Multi-session A session is the complete amount of data Abbreviation for Variable Bit Rate. While recorded from the beginning to the end of CBR (Constant Bit Rate) is generally a single period of CD-ROM, CD-R/CD- used, VBR varies the bit rate for audio RW data recording.
Page 212 Mazda5_8CN3-EA-12I_Edition1 Page212 Tuesday, September 4 2012 1:24 PM Black plate (212,1) Interior Comfort Audio System WMA files written under specifications Song, artist, and album name other than the indicated specification information in the AAC file is recorded may not play normally or files or folder as data termed names may not display correctly.
Page 213 WMA files written under specifications 11.025/12/8 kHz (MPEG2.5) other than the indicated specification 32 320 kbps (MPEG1) may not play normally or files or folder Bit rate 32 160 kbps (MPEG2) 32 160 kbps (MPEG2.5) names may not display correctly. 6-21 Form No.8CN3-EA-12I...
Page 214 Connectable iPods are as follows: iPod: 5G AAC files written under specifications iPod classic other than the indicated specification iPod nano: 1/2/3/4/5/6G may not play normally or files or folder iPod touch names may not display correctly. iPhone : 3G/3GS/4...
Page 215 Ø If data in the iPod is lost while it is connected to the unit, Mazda cannot guarantee recovery of any lost data. Ø If the iPod battery is deteriorated,...
Page 216 Mazda5_8CN3-EA-12I_Edition1 Page216 Tuesday, September 4 2012 1:24 PM Black plate (216,1) MEMO 6-24 Form No.8CN3-EA-12I...
Page 217: Audio Set
Mazda5_8CN3-EA-12I_Edition1 Page217 Tuesday, September 4 2012 1:24 PM Black plate (217,1) Interior Comfort Audio System Audio Set Audio information is displayed on the information display. Power/Volume/Sound Controls ................page 6-26 Operating the Radio ....................page 6-30 Operating the Satellite Radio ................. page 6-32 Operating the Compact Disc (CD) Player ..............
Page 218 Mazda5_8CN3-EA-12I_Edition1 Page218 Tuesday, September 4 2012 1:24 PM Black plate (218,1) Interior Comfort Audio System qPower/Volume/Sound Controls Power/Volume dial Audio control dial Power ON/OFF Audio sound adjustment Switch the ignition to ACC or ON. 1. Press the audio control dial to select the function.
Page 219 Depending on the type of audio unit, the selected mode will be indicated. order in which the functions appear differs. About 5 seconds after selecting any mode, the volume function will be automatically selected. To reset bass, treble, fade, and balance, press the audio control dial for 2 seconds.
Page 220 Mazda5_8CN3-EA-12I_Edition1 Page220 Tuesday, September 4 2012 1:24 PM Black plate (220,1) Interior Comfort Audio System BEEP setting The beep-sound when operating the audio system can be set on or off. í BT SETUP mode Music and other audio such as voice data recorded on portable audio devices and mobile phones available on the market ®...
Page 221 Mazda5_8CN3-EA-12I_Edition1 Page221 Tuesday, September 4 2012 1:24 PM Black plate (221,1) MEMO 6-29 Form No.8CN3-EA-12I...
Page 222 Mazda5_8CN3-EA-12I_Edition1 Page222 Tuesday, September 4 2012 1:24 PM Black plate (222,1) Interior Comfort Audio System qOperating the Radio Band selector button Manual tuning dial/Mute button Seek tuning buttons Auto memory button Channel preset buttons Scan button Radio ON Tuning Press a band selector button ( ) to The radio has the following tuning turn the radio on.
Page 223 Press and release the auto memory button Scanning stops at each station for about 5 ) to recall stations from the auto- seconds. To hold a station, press the scan stored stations. One stored station will be button ( ) again during this interval.
Page 224 Mazda5_8CN3-EA-12I_Edition1 Page224 Tuesday, September 4 2012 1:24 PM Black plate (224,1) Interior Comfort Audio System í qOperating the Satellite Radio Seek tuning buttons Satellite button Category buttons Scan button Channel preset buttons Text button Scroll button Manual tuning dial/Instant replay button Information display All operations of the satellite radio are displayed on the Information display.
Page 225 Mazda5_8CN3-EA-12I_Edition1 Page225 Tuesday, September 4 2012 1:24 PM Black plate (225,1) Interior Comfort Audio System NOTE What is satellite radio? This equipment has been tested and found to With over 130 channels, SIRIUS Satellite comply with the limits for a Class B digital Radio brings you more of what you love.
Page 226 (in SAT equipment when it is in the initial state, mode and tuned to channel 184). when there is a change in the user's Activation typically takes only 2 5 subscription condition, or when the minutes. SIRIUS channel map is changed.
Page 227 2. Keep pressing the channel preset Turn the knob clockwise: Channel Up button for 1.5 seconds or more. Turn the knob counterclockwise: The programming process is complete Channel Down after the channel number flashes. Then,...
Page 228 Every time the category button ( ) is 2. Keep pressing the channel preset pressed, the category is changed over in button for 1.5 seconds or more. the order shown below. The programming process is complete At this time, the lowest (smallest-number) after the text (e.g.
Page 229 Mazda5_8CN3-EA-12I_Edition1 Page229 Tuesday, September 4 2012 1:24 PM Black plate (229,1) Interior Comfort Audio System Scan tuning NOTE Eight characters are displayed on one Press the scan button ( ) to screen. automatically sample stations. Scanning To display the rest of the characters of a stops at each station for about five long title, press the scroll button ( seconds.
Page 230 Mazda5_8CN3-EA-12I_Edition1 Page230 Tuesday, September 4 2012 1:24 PM Black plate (230,1) Interior Comfort Audio System If there is no channel name, Three seconds after scrolling the artist No TITLE is displayed. name, the display automatically return to display the first part of the artist's name.
Page 231 Setting condition: SAT mode When the seek tuning button ( ) is pressed for about 1.5 seconds or longer, (Master code input preparation) the program is reversed while the button is being pressed. 1. Press and hold the scan button (...
Page 232 ( ) are used for inputting 5. Determine the input code by pressing the ID code. Buttons 5 and 6 cannot be the scan button ( used. 6. If it does not match with the previously Change of ID code...
Page 233 Channel preset buttons 1, 2, 3, 4 and the returns to SR1 - - - - . scan button ( ) are used for input of the ID code. Buttons 5 and 6 cannot be 8. If it matches the registered code, used. SR1 LOCK appears for three...
Page 234 Channel preset buttons 1, 2, 3, 4 and the seconds. scan button ( ) are used for input of the ID code. Buttons 5 and 6 cannot be 3. ENTER PIN appears for three seconds which indicates that it is in used.
Page 235 Mazda5_8CN3-EA-12I_Edition1 Page235 Tuesday, September 4 2012 1:24 PM Black plate (235,1) MEMO 6-43 Form No.8CN3-EA-12I...
Page 236 Mazda5_8CN3-EA-12I_Edition1 Page236 Tuesday, September 4 2012 1:24 PM Black plate (236,1) Interior Comfort Audio System qOperating the Compact Disc (CD) Player Play/Pause button/File dial Random button Track up/Fast-forward button Folder up button Repeat button Load button CD slot CD eject button CD play button Folder down button Text button...
Page 237 Mazda5_8CN3-EA-12I_Edition1 Page237 Tuesday, September 4 2012 1:24 PM Black plate (237,1) Interior Comfort Audio System Fast-forward/Reverse Repeat playback Press and hold the fast-forward button During music CD playback ) to advance through a track at high 1. Press the repeat button ( ) during speed.
Page 238 Mazda5_8CN3-EA-12I_Edition1 Page238 Tuesday, September 4 2012 1:24 PM Black plate (238,1) Interior Comfort Audio System During MP3/WMA/AAC CD playback MP3/WMA/AAC CD (Folder random) File number/Elapsed time 1. Press the random button ( ) during playback to play the tracks in the folder randomly.
Page 239 Use a commercially-available, non- impedance (3.5 ) stereo mini plug cable. Contact an Authorized Mazda Dealer for details. In addition, audio can be played from the vehicle's audio unit by connecting USB memory or an iPod to the USB port.
Page 240 Interior Comfort Audio System qError Indications If you see an error indication on the display, find the cause in the chart. If you cannot clear the error indication, take the vehicle to an Authorized Mazda Dealer. Indication Cause Solution Depending on the...
Page 241: Audio Control Switch Operation
When the audio unit is turned on, Mazda has installed this system to prevent operation of the audio unit from the distraction while driving the vehicle and steering wheel is possible.
Page 242 Mazda5_8CN3-EA-12I_Edition1 Page242 Tuesday, September 4 2012 1:24 PM Black plate (242,1) Interior Comfort Audio System qChanging the Source NOTE CD, USB, iPod, SIRIUS digital satellite radio, Press the mode switch ( ) to change and BT audio modes cannot be selected in the the audio source (FM1 radio →...
Page 243 Mazda5_8CN3-EA-12I_Edition1 Page243 Tuesday, September 4 2012 1:24 PM Black plate (243,1) Interior Comfort Audio System With Bluetooth® Hands-Free When playing a CD, USB, iPod, or BT audio Press the seek switch up to skip to the next track. Press the seek switch down to repeat the current track.
Page 244: Aux/Usb/Ipod Mode
A commercially-available, non-impedance vehicle is dangerous as it could (3.5 ) stereo mini plug cable is required. distract your attention from the Contact an Authorized Mazda Dealer for vehicle operation which could lead to details.
Page 245 Switches portable audio device. Use a commercially-available, non- impedance (3.5 ) stereo mini plug for connecting the portable audio unit to the auxiliary jack. Before using the auxiliary jack, read the manufacturer's instructions for connecting a portable audio unit to the auxiliary jack.
Page 246 Mazda5_8CN3-EA-12I_Edition1 Page246 Tuesday, September 4 2012 1:24 PM Black plate (246,1) Interior Comfort Audio System qHow to use USB mode Random button Play/Pause button/File dial Track up/Fast-forward button Folder up button Repeat button Folder down button Text button Scan button Track down/Reverse button Source change button Scroll button...
Page 247 Mazda5_8CN3-EA-12I_Edition1 Page247 Tuesday, September 4 2012 1:24 PM Black plate (247,1) Interior Comfort Audio System Press and hold the reverse button ( ) to 2. To cancel the repeat playback, press the reverse through a track at high speed. button again after 3 seconds. Track search (Folder repeat) Press the track up button (...
Page 248 USB memory. Verify that the content recorded in the USB memory has File name MP3/WMA/AAC files and re-connect correctly. If the message reappears, have Folder name the unit checked by an Authorized Mazda Dealer. Album name Song name Artist name NOTE...
Page 249 Mazda5_8CN3-EA-12I_Edition1 Page249 Tuesday, September 4 2012 1:24 PM Black plate (249,1) MEMO 6-57 Form No.8CN3-EA-12I...
Page 250 ) of iPod: 5G the audio unit or the mode switch iPod classic ) of the audio control switches iPod nano: 1/2/3/4/5/6G on the steering wheel to switch to the iPod touch iPod mode and start playback. iPhone : 3G/3GS/4...
Page 251 Mazda5_8CN3-EA-12I_Edition1 Page251 Tuesday, September 4 2012 1:24 PM Black plate (251,1) Interior Comfort Audio System Fast-forward/Reverse Music Scan Press and hold the fast-forward button This function scans the titles in a list ) to advance through a track at high currently being played and plays ten speed.
Page 252 If you see an error indication on the title/Composer title/Podcast title) display, find the cause in the chart. If you cannot clear the error indication, take the Artist name vehicle to an Authorized Mazda Dealer. Album name Indication Cause Solution...
Page 253: Safety Certification
Ø This CD player should not be adjusted or repaired by anyone except qualified service personnel. If servicing is required, contact an Authorized Mazda Dealer. Ø Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous laser exposure. Never operate the CD player with the top case of the unit removed.
Page 254: Bluetooth® Audio
® Bluetooth unit, you can listen to music an Authorized Mazda Dealer when or audio recorded on these audio devices purchasing or changing devices. ® from the vehicle's speakers. Bluetooth ®...
Page 255 Mazda5_8CN3-EA-12I_Edition1 Page255 Tuesday, September 4 2012 1:24 PM Black plate (255,1) Interior Comfort Bluetooth® Audio Audio profile NOTE The system may not operate normally A2DP (Advanced Audio Distribution ® depending on the Bluetooth audio device. Profile) Ver. 1.0 ® To make sure that your Bluetooth audio AVRCP (Audio/Video Remote Control device is Ver.
Page 256 Mazda5_8CN3-EA-12I_Edition1 Page256 Tuesday, September 4 2012 1:24 PM Black plate (256,1) Interior Comfort Bluetooth® Audio qBluetooth® Audio Preparation Display Mode Function ® Pairing Bluetooth audio ® PAIR DEVICE Bluetooth audio device set-up program mode device programming ® Bluetooth audio programming, changes, Changing link Link change ®...
Page 257 PIN code is displayed. programming procedure differs depending PAIRING flashes on the display. on whether it has a PIN code or not. ® 5. Operate the Bluetooth audio device ® Programming a Bluetooth audio and set it to the program mode while device which has a four-digit PIN code PAIRING is flashing.
Page 258 PAIRING flashes on the display. ® 4. Operate the Bluetooth audio device and set it to the program mode while PAIRING is flashing. ® 5. As the Bluetooth audio device requires a PIN code, input 0000 . 6-66 Form No.8CN3-EA-12I...
Page 259 5. Press the audio control dial to select the device you would like to link. symbol disappears, and PAIRING flashes in the display.
Page 260 The device name displayed first is the device which is currently linked. 5. If a selection other than GO BACK ® is made and the audio control dial is Deleting the link to a Bluetooth audio pressed, SURE ? NO is displayed.
Page 261 Mazda5_8CN3-EA-12I_Edition1 Page261 Tuesday, September 4 2012 1:24 PM Black plate (261,1) Interior Comfort Bluetooth® Audio 7. Press the audio control dial to delete 4. Rotate the audio control dial to select ® the selected device. the information for the Bluetooth unit which you would like to view.
Page 262 Mazda5_8CN3-EA-12I_Edition1 Page262 Tuesday, September 4 2012 1:24 PM Black plate (262,1) Interior Comfort Bluetooth® Audio NOTE Selecting a file (track) ® Some Bluetooth audio devices need a certain Short-press the track down button ( ) or amount of time before the “ ”...
Page 263 Mazda5_8CN3-EA-12I_Edition1 Page263 Tuesday, September 4 2012 1:24 PM Black plate (263,1) Interior Comfort Bluetooth® Audio Display scroll Only 12 characters can be displayed at one time. To display the rest of the characters of a long title, short-press the scroll button ( ).
Page 264: Bluetooth® Hands-Free
Performing phonebook registration (Mobile phone) are some which will while driving the vehicle could be a not connect with your Mazda or will distraction to your driving and result have limited function. Therefore, in an accident. In addition, a mistake ®...
Page 265 Mazda5_8CN3-EA-12I_Edition1 Page265 Tuesday, September 4 2012 1:24 PM Black plate (265,1) Interior Comfort Bluetooth® Hands-Free A2DP (Advanced Audio Distribution Talk button, Pick-Up button and Hang- Profile) Ver. 1.0 Up button OPP (Object Push Profile) Ver. 1.1 ® Basic functions of Bluetooth Hands-Free can be used for such things as making NOTE...
Page 266 Mazda5_8CN3-EA-12I_Edition1 Page266 Tuesday, September 4 2012 1:24 PM Black plate (266,1) Interior Comfort Bluetooth® Hands-Free qVoice Information display When available, the information display To prevent the deterioration in voice ® shows telephone numbers, Bluetooth recognition rate and voice quality, the Hands-Free messages, and operation following points must be observed: status.
Page 267 Mazda5_8CN3-EA-12I_Edition1 Page267 Tuesday, September 4 2012 1:24 PM Black plate (267,1) Interior Comfort Bluetooth® Hands-Free ® NOTE Bluetooth Hands-Free Activation Method If the voice recognition performance is not satisfactory, refer to “Voice Recognition Press the pick-up button or talk button Learning Function (Speaker Enrollment)”...
Page 268: Basic Bluetooth® Hands-Free Operation
3. Prompt: Select one of the following: Pairing options, confirmation prompts, language, passcode, select phone or select music player. 4. Say: [Beep] Language 5. Prompt: Select a language: English, French, or Spanish. 6. Say: [Beep] French (Speak the desired language: English , French or Spanish ) 6-76 Form No.8CN3-EA-12I...
Page 269 8. Say: [Beep] Yes 4. Say: [Beep] Pairing options 9. Prompt: Please wait. Switching to French phonebook. French selected. 5. Prompt: Available options are: Pair, (Spoken in the newly selected Edit, Delete, List, or Set Pairing Code. language). 6. Say: [Beep] Set pairing code Method 2 7.
Page 270 ® a Bluetooth audio device if it has already 10. Select Mazda from the device list been programmed as a hands-free mobile searched by the device. phone. 11. Input the 4-digit pairing code to the Since the communication range of a device.
Page 271 OFF Say, XXXX (desired telephone to ACC, the system reads out a voice number), then go to Step 5. guidance, XXXXXX - - - (Ex. Stan's (Telephone number correction) device ) (Device tag) is connected .
Page 272 Mazda5_8CN3-EA-12I_Edition1 Page272 Tuesday, September 4 2012 1:24 PM Black plate (272,1) Interior Comfort Bluetooth® Hands-Free qReceiving an Incoming Call NOTE The volume can also be adjusted using the 1. Prompt: Incoming call, press the volume button on the steering wheel. pickup button to answer .
Page 273: Convenient Use Of The Hands-Free System
Go Back. The last entered numbers have been removed. . Then go back 4. Say: [Beep] New entry to Step 13. 5. Prompt: Name please. 17. Prompt: Number saved. Would you 6. Say: [Beep] XXXXX... (Ex. Mary's like to add another number for this...
Page 274 1. Press the pick-up button or talk button 4. Say: [Beep] Import contact with a short press. 5. Prompt: The hands free System is 2. Say: [Beep] Call ready to receive a contact from a 3. Prompt: Name please.
Page 275 Transferring a call from a device 066 , is this correct? (Mobile phone) to Hands-Free 4. Say: [Beep] Yes Communication between devices (Mobile 5. Prompt: Dialing ® phone) can be switched to Bluetooth Hands-Free. qRefusing an Incoming Call 1. Press the talk button with a short press.
Page 276 After receiving a new incoming call, the Say, XXXX (desired telephone previous call is placed on hold. number), then go to Step 5. (Telephone number correction) Switching calls Say, Go Back . The prompt replies, Switching back to the previous call can Go Back.
Page 277 Pick-Up button to save the number. 4. Say: [Beep] Edit 14. (Number Change) 5. Prompt: Please say the name of the Press the pick-up button, then go to entry you would like to edit or say, Step 15.
Page 278 Tuesday, September 4 2012 1:24 PM Black plate (278,1) Interior Comfort Bluetooth® Hands-Free 1. Press the pick-up button or talk button 5. Prompt: Are you sure you want to with a short press. erase everything from your Hands Free system phonebook? 2. Say: [Beep] Phonebook 6.
Page 279: Hands-Free Setting
4. Say: [Beep] Pairing options 1. Press the talk button with a short press. 5. Prompt: Available options are: Pair, 2. Say: [Beep] XXXX... send (Say Edit, Delete, List, or Set Pairing Code. DTMF code) 6. Say: [Beep] List 3.
Page 280 4. Say: [Beep] Select phone phone) when the talk button is short- pressed. 5. Prompt: Please say the name of the Select music player : Selects device device you would like to select. (Music player) when the talk button is Available devices are XXXXX...
Page 281 2. Say: [Beep] Setup 4. Say: [Beep] Pairing options 3. Prompt: Select one of the following: 5. Prompt: Available options are: Pair, Edit, Delete, List, or Set Pairing Code. Pairing options, confirmation prompts, language, passcode, select phone or 6.
Page 282 1. Press the pick-up button or talk button with a short press. 4. Say: [Beep] Passcode 2. Say: [Beep] Setup 5. Prompt: Passcode is disabled. Would you like to enable it? 3. Prompt: Select one of the following: Pairing options, confirmation prompts, 6.
Page 283 4. Say: [Beep] Confirmation prompts the vehicle is stopped. See the owner's 5. Prompt: Confirmation prompts are manual for the list of required training on/off. Would you like to turn phrases. Press and release the talk confirmation prompts off/on? button when you are ready to begin.
Page 284 Tuesday, September 4 2012 1:24 PM Black plate (284,1) Interior Comfort Bluetooth® Hands-Free 5. The voice guidance reads out the voice 7. The voice guidance reads out the voice input command number (refer to the input command number (refer to the...
Page 285: When Bluetooth® Hands-Free Cannot Be Used
The ignition is switched off. 4. Say: [Beep] Disable or Enable 5. When Disable is spoken, the voice recognition learning is turned off. When Enable is spoken, the voice recognition learning is turned on.
Page 286: Safety Certification
Mazda5_8CN3-EA-12I_Edition1 Page286 Tuesday, September 4 2012 1:24 PM Black plate (286,1) Interior Comfort Bluetooth® Hands-Free Safety Certification Mazda Bluetooth® Hands- Free Customer Service FCC ID: CB2MBLUEC09 IC:279B- MBLUEC09 U.S.A. This device complies with Part 15 of the Phone: 800-430-0153 (Toll-free) FCC Rules and with RSS-210 of Industry www.MazdaUSA.com/bluetooth...
Page 287: Interior Equipment
Mazda5_8CN3-EA-12I_Edition1 Page287 Tuesday, September 4 2012 1:24 PM Black plate (287,1) Interior Comfort Interior Equipment Sunvisors Interior Lights qIlluminated Entry System When you need a sunvisor, lower it for use in front or swing it to the side. When the illuminated entry system Sunvisor operates, the overhead light (switch is in the DOOR position) turns on for:...
Page 288 Mazda5_8CN3-EA-12I_Edition1 Page288 Tuesday, September 4 2012 1:24 PM Black plate (288,1) Interior Comfort Interior Equipment qOverhead Lights qMap Lights The map lights are switched on or off by Front pressing the switches. Switches Switch Position Front Overhead Lights qLuggage Compartment Light Light off Light is on when any door is open...
Page 289: Information Display
Mazda5_8CN3-EA-12I_Edition1 Page289 Tuesday, September 4 2012 1:24 PM Black plate (289,1) Interior Comfort Interior Equipment Information Display Clock/Ambient Trip computer Climate control display Audio display temperature display display Steering switch qInformation Display Functions The information display has the following functions: Clock Ambient Temperature Display Climate Control Display...
Page 290 The vehicle is parked. setting button ( ) is pressed. The vehicle is driven at low speeds. Press the AUTO switch(page 6-5) for 3 Time resetting seconds or more to switch the display from Fahrenheit to Centigrade or vice versa.
Page 291 Current fuel economy mode Average fuel economy mode Distance-to-empty mode Average vehicle speed mode When you've slowed to about 5 km/h (3 mph), - - - L/100 km (- - -mpg) will be If you have any problems with your trip displayed.
Page 292 When this mode is selected, AVG will be and displayed every second. displayed. U.S.A. When this mode is selected, RANGE will be displayed. U.S.A. CANADA CANADA To clear the data being displayed, press the INFO switch for more than 1.5 second. 6-100 Form No.8CN3-EA-12I...
Page 293 E or the low fuel warning light illuminates. The display won't change unless you add more than approximately 5 L (6 US qt, 5 Imp qt) of fuel. Average vehicle speed mode This mode displays the average vehicle...
Page 294: Cup Holder
Mazda5_8CN3-EA-12I_Edition1 Page294 Tuesday, September 4 2012 1:24 PM Black plate (294,1) Interior Comfort Interior Equipment qFront Cup Holder The front cup holder is in the center WARNING console. Never use a cup holder to hold hot liquids while the vehicle is moving: Using a cup holder to hold hot liquids while the vehicle is moving is dangerous.
Page 295: Bottle Holder
Mazda5_8CN3-EA-12I_Edition1 Page295 Tuesday, September 4 2012 1:24 PM Black plate (295,1) Interior Comfort Interior Equipment Third-row seat Bottle Holder Two cup holders are in the side-trim on Bottle holders are on the inside of the both the left and right sides. doors.
Page 296: Storage Compartments
Mazda5_8CN3-EA-12I_Edition1 Page296 Tuesday, September 4 2012 1:24 PM Black plate (296,1) Interior Comfort Interior Equipment Storage Compartments WARNING Keep storage boxes closed when driving: Driving with the storage boxes open is dangerous. To reduce the possibility of injury in an accident or a sudden stop, keep the storage boxes closed when driving.
Page 297 Mazda5_8CN3-EA-12I_Edition1 Page297 Tuesday, September 4 2012 1:24 PM Black plate (297,1) Interior Comfort Interior Equipment qSmall Item Storage Spaces WARNING Do not place objects in the small storage spaces which can roll around easily or stick out. Putting objects in the small item storage spaces which can roll around easily or stick out is dangerous.
Page 298 Mazda5_8CN3-EA-12I_Edition1 Page298 Tuesday, September 4 2012 1:24 PM Black plate (298,1) Interior Comfort Interior Equipment qGlove Compartment qUnderseat Storage To open the glove compartment, pull the If your vehicle has a right second-row latch toward you. storage box (page 6-107), when using the storage box, small items can be stored under the both bottoms of the second-row seats.
Page 299 Mazda5_8CN3-EA-12I_Edition1 Page299 Tuesday, September 4 2012 1:24 PM Black plate (299,1) Interior Comfort Interior Equipment CAUTION CAUTION Do not store items above the marked When returning the seat-bottom to line indicated in the illustration its upright position, make sure there below.
Page 300 Mazda5_8CN3-EA-12I_Edition1 Page300 Tuesday, September 4 2012 1:24 PM Black plate (300,1) Interior Comfort Interior Equipment 3. More items can be stowed if the cover To use the storage box is removed. 1. Pull the strap and lift the seat bottom up and forward.
Page 301 Mazda5_8CN3-EA-12I_Edition1 Page301 Tuesday, September 4 2012 1:24 PM Black plate (301,1) Interior Comfort Interior Equipment Use the loops in the luggage compartment CAUTION to secure cargo with a rope or net. The When returning the seat-bottom to tensile strength of the loops is 196 N (20 its upright position, make sure there kgf, 44 lbf).
Page 302 Mazda5_8CN3-EA-12I_Edition1 Page302 Tuesday, September 4 2012 1:25 PM Black plate (302,1) Interior Comfort Interior Equipment qRear Coat Hooks qLuggage Compartment WARNING A golf bag can be carried in the luggage compartment. Never hang heavy or sharp objects on To place a golf bag in the luggage the assist grips and coat hooks: compartment, use the following Hanging heavy or sharp-ended...
Page 303: Accessory Sockets
Accessory Sockets Ø To prevent accessory socket Switch the ignition to ACC or ON. damage or electrical failure, pay Only use genuine Mazda accessories or attention to the following: the equivalent requiring no greater than Ø Do not use accessories that 120 W (DC 12 V, 10 A).
Page 304 Mazda5_8CN3-EA-12I_Edition1 Page304 Tuesday, September 4 2012 1:25 PM Black plate (304,1) 6-112 Form No.8CN3-EA-12I...
Page 305: In Case Of An Emergency
Mazda5_8CN3-EA-12I_Edition1 Page305 Tuesday, September 4 2012 1:25 PM Black plate (305,1) In Case of an Emergency Helpful information on what to do in an emergency. Parking in an Emergency ............. 7-2 Parking in an Emergency ............7-2 Flat Tire ..................7-3 Spare Tire and Tool Storage ............
Page 306: Parking In An Emergency
Mazda5_8CN3-EA-12I_Edition1 Page306 Tuesday, September 4 2012 1:25 PM Black plate (306,1) In Case of an Emergency Parking in an Emergency Parking in an Emergency The hazard warning lights should always be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take extreme caution...
Page 307: Flat Tire
Mazda5_8CN3-EA-12I_Edition1 Page307 Tuesday, September 4 2012 1:25 PM Black plate (307,1) In Case of an Emergency Flat Tire Spare Tire and Tool Storage Spare tire and tools are stored in the locations illustrated in the diagram. Jack lever Lug wrench Towing eyelet Jack Spare tire...
Page 308 Mazda5_8CN3-EA-12I_Edition1 Page308 Tuesday, September 4 2012 1:25 PM Black plate (308,1) In Case of an Emergency Flat Tire qJack To secure the jack 1. Insert the wing bolt into the jack with To remove the jack the jack screw pointing down and turn 1.
Page 309 A tire pressure sensor is not installed to the temporary spare tire. The warning light will flash continuously while the temporary spare tire is being used (page 5-28). To remove the spare tire 1. Fold the third-row seat forward (page 2-10).
Page 310 Mazda5_8CN3-EA-12I_Edition1 Page310 Tuesday, September 4 2012 1:25 PM Black plate (310,1) In Case of an Emergency Flat Tire 2. Open and fold back the trunk board To secure the spare tire over the third-row seatback. Perform the removal procedure in reverse. Trunk board 3.
Page 311: Changing A Flat Tire
4. Have everyone get out of the vehicle changing a tire: and away from the vehicle and traffic. Changing a tire is dangerous if not 5. Remove the jack, tool, and spare tire done properly. The vehicle can slip off (page 7-3). the jack and seriously injure someone.
Page 312 Jacking position 5. Continue raising the jack head gradually by rotating the screw with 2. Place the jack on the ground. your hand until the jack head is inserted into the jack-up position.
Page 313 Mazda is firmly in position and that it under the jack is dangerous as it cannot slip or move. could deform the vehicle body or the vehicle could fall off the jack resulting in an accident.
Page 314 Starting the engine or shaking the If you lose this key, consult an Authorized vehicle while it is jacked up is Mazda Dealer or use the lock dangerous as it could cause the manufacturer's order form, which is with vehicle to fall off the jack resulting in the registration card.
Page 315 Mazda5_8CN3-EA-12I_Edition1 Page315 Tuesday, September 4 2012 1:25 PM Black plate (315,1) In Case of an Emergency Flat Tire 3. Install the lug nuts with the beveled To install the nut edge inward; tighten them by hand. 1. Place the key on top of the nut, and be sure to hold the key square to it.
Page 316 Because the wheel studs and lug nuts 10. Thread the belt through the wheel as on your Mazda have metric threads, shown in the figure, then attach the using a non-metric nut is dangerous. belt clips to the cargo securing loops On a metric stud, it would not secure on the back of the third-row seat.
Page 317 A tire pressure sensor is not installed to the temporary spare tire. The warning light will flash continuously while the temporary spare tire is being used (page 5-28). NOTE To prevent the jack and tool from rattling, store them properly.
Page 318: Overheating
4. Turn off the air conditioner. or pinging noise, the engine is probably too hot. 5. Check whether coolant or steam is WARNING escaping from under the hood or from the engine compartment.
Page 319 Carefully add coolant as required (page 8-22). CAUTION If the engine continues to overheat or frequently overheats, have the cooling system inspected. The engine could be seriously damaged unless repairs are made. Consult an Authorized Mazda Dealer. 7-15 Form No.8CN3-EA-12I...
Page 320: Emergency Starting
4. Depress the clutch pedal (Manual transaxle) or the brake pedal (Automatic transaxle). 5. Switch the ignition to START and hold it there for up to ten seconds. If the engine starts, release the key and accelerator immediately because the engine will suddenly rev up.
Page 321: Jump-Starting
Mazda5_8CN3-EA-12I_Edition1 Page321 Tuesday, September 4 2012 1:25 PM Black plate (321,1) In Case of an Emergency Emergency Starting Jump-Starting Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work.
Page 322 Mazda5_8CN3-EA-12I_Edition1 Page322 Tuesday, September 4 2012 1:25 PM Black plate (322,1) In Case of an Emergency Emergency Starting Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode.
Page 323 Mazda5_8CN3-EA-12I_Edition1 Page323 Tuesday, September 4 2012 1:25 PM Black plate (323,1) In Case of an Emergency Emergency Starting 2 Detach the clip facing the vehicle 1. Remove the battery cover from its front interior first and pull it outward side. with your finger approx.
Page 324 Connect the other end to the ground point indicated in the illustration away from the discharged battery (4). 5. Start the engine of the booster vehicle and run it a few minutes. Then start the engine of the other vehicle. 7-20...
Page 325: Push-Starting
Emergency Starting 6. When finished, carefully disconnect the Push-Starting cables in the reverse order described in the illustration. Do not push-start your Mazda. NOTE WARNING Verify that the covers are securely installed. Never tow a vehicle to start it: Towing a vehicle to start it is dangerous.
Page 326: Emergency Towing
Towing Description Do not tow the vehicle pointed We recommend that towing be done only backward with driving wheels on the by an Authorized Mazda Dealer or a ground. This may cause internal commercial tow-truck service. damage to the transaxle.
Page 327: Tiedown Hooks
Mazda5_8CN3-EA-12I_Edition1 Page327 Tuesday, September 4 2012 1:25 PM Black plate (327,1) In Case of an Emergency Emergency Towing NOTE Tiedown Hooks If it is difficult to remove the tiedown eyelet, wrap the jack lever with a cloth as shown in CAUTION the figure and press the marking on the cover Do not use the front and rear...
Page 328 Mazda5_8CN3-EA-12I_Edition1 Page328 Tuesday, September 4 2012 1:25 PM Black plate (328,1) In Case of an Emergency Emergency Towing qTiedown Hooks-Rear 4. Hook the tying rope to the tiedown eyelet. Tiedown hook CAUTION CAUTION The rear tiedown hook is designed If the tiedown eyelet is not securely only for lashing the vehicle during tightened, it may loosen or disengage overseas transport.
Page 329: Recreational Towing
Mazda5_8CN3-EA-12I_Edition1 Page329 Tuesday, September 4 2012 1:25 PM Black plate (329,1) In Case of an Emergency Emergency Towing Recreational Towing An example of recreational towing is towing your vehicle behind a motorhome. The transaxle is not designed for towing this vehicle on all 4 wheels. When doing recreational towing refer to Towing Description (page 7-22) and Tiedown Hook (page 7-23) and...
Page 330 Mazda5_8CN3-EA-12I_Edition1 Page330 Tuesday, September 4 2012 1:25 PM Black plate (330,1) 7-26 Form No.8CN3-EA-12I...
Page 331: Maintenance And Care
Mazda5_8CN3-EA-12I_Edition1 Page331 Tuesday, September 4 2012 1:25 PM Black plate (331,1) Maintenance and Care How to keep your Mazda in top condition. Introduction .................. 8-2 Introduction ................8-2 Scheduled Maintenance ..............8-4 Scheduled Maintenance (USA, Canada, and Puerto Rico) ..8-4 Scheduled Maintenance (Mexico) ..........
Page 332: Introduction
If you elect to perform maintenance yourself or have your vehicle serviced at a location other than an Authorized Mazda Dealer, Mazda requires that all fluids, parts and materials must meet Mazda standards for durability and performance as described in this manual.
Page 333 Black plate (333,1) Maintenance and Care Introduction Any auto repair shop using parts equivalent to your Mazda's original equipment may perform maintenance. But we recommend that it always be done by an Authorized Mazda Dealer using genuine Mazda parts. Form No.8CN3-EA-12I...
Page 334: Scheduled Maintenance
Mazda5_8CN3-EA-12I_Edition1 Page334 Tuesday, September 4 2012 1:25 PM Black plate (334,1) Maintenance and Care Scheduled Maintenance Scheduled Maintenance (USA, Canada, and Puerto Rico) Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes Driving in areas where salt or other corrosive materials are used...
Page 335: Scheduled Maintenance (Mexico)
Engine oil filter COOLING SYSTEM Replace at first 192,000 km (120,000 miles) or 10 years; after FL22 type that, every 96,000 km (60,000 miles) or 5 years Engine coolant Replace at first 96,000 km (60,000 miles) or 4 years; after that, Others...
Page 336 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 337 Audibly inspect every 120,000 km (75,000 miles), if noisy, Engine valve clearance adjust Drive belts Puerto Rico Replace every 5,000 km (3,000 miles) or 3 months Engine oil Others Engine oil filter COOLING SYSTEM Replace at first 192,000 km (120,000 miles) or 10 years ; after...
Page 338 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 339 Mazda5_8CN3-EA-12I_Edition1 Page339 Tuesday, September 4 2012 1:25 PM Black plate (339,1) Maintenance and Care Scheduled Maintenance Scheduled Maintenance (Mexico) Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes Driving in areas where salt or other corrosive materials are used Driving on rough or muddy roads...
Page 340 Engine oil Engine oil filter COOLING SYSTEM Cooling system Replace at first 200,000 km or 10 years; after that, every FL22 type 100,000 km or 5 years Engine coolant Others FUEL SYSTEM Air filter Fuel lines and hoses Hoses and tubes for emission...
Page 341 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 342 Engine oil Engine oil filter COOLING SYSTEM Cooling system Replace at first 200,000 km or 10 years; after that, every FL22 type 100,000 km or 5 years Engine coolant Others Engine coolant level FUEL SYSTEM Air filter Fuel lines and hoses...
Page 343 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 344 Engine oil Engine oil filter COOLING SYSTEM Cooling system Replace at first 200,000 km or 10 years; after that, every FL22 type 100,000 km or 5 years Engine coolant Others Engine coolant level FUEL SYSTEM Air filter Fuel lines and hoses...
Page 345 *2 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or kilometer period to ensure long-term reliability.
Page 346: Owner Maintenance
The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an Authorized Mazda Dealer or qualified service technician as soon as possible.
Page 347: Owner Maintenance Precautions
Refer to Introduction (page 8-2) for owner's responsibility in protecting your investment. For details, read the separate Mazda Warranty statement provided with the vehicle. If you are unsure about any servicing or maintenance procedure, have it done by an Authorized Mazda Dealer.
Page 348 Mazda5_8CN3-EA-12I_Edition1 Page348 Tuesday, September 4 2012 1:25 PM Black plate (348,1) Maintenance and Care Owner Maintenance WARNING Do not perform maintenance work if you lack sufficient knowledge and experience or the proper tools and equipment to do the work. Have maintenance work done by a qualified technician: Performing maintenance work on a vehicle is dangerous if not done properly.
Page 349: Engine Compartment Overview
Mazda5_8CN3-EA-12I_Edition1 Page349 Tuesday, September 4 2012 1:25 PM Black plate (349,1) Maintenance and Care Owner Maintenance Engine Compartment Overview Automatic transaxle fluid-level dipstick (Only for automatic transaxle) Engine oil-filler cap Battery Engine coolant reservoir Engine oil dipstick Brake/Clutch fluid reservoir Cooling system cap Power steering fluid reservoir Windscreen washer fluid reservoir...
Page 350: Engine Oil
Lubricant Standardization and Approval Committee (ILSAC), comprised of U.S. qRecommended Oil and Japanese automobile manufacturers. U.S.A. and CANADA Use SAE 0W-20 engine oil. Mazda Genuine Oil is used in your Mazda –40 –20 –30 –10 vehicle. Mazda Genuine 0W-20 Oil is required to achieve optimum fuel –40 –20...
Page 351 6. Make sure the O-ring on the dipstick is 2. Warm up the engine to normal positioned properly before reinserting operating temperature. the dipstick. 3. Turn it off and wait at least 5 minutes for the oil to return to the oil pan. 8-21 Form No.8CN3-EA-12I...
Page 352: Engine Coolant
When the engine and radiator are hot, scalding coolant and steam may shoot out under pressure and cause serious injury. NOTE Changing the coolant should be done by an Authorized Mazda Dealer. 8-22 Form No.8CN3-EA-12I...
Page 353: Brake/Clutch Fluid
If it is excessively low, have the Ø The engine has aluminum parts brake/clutch system inspected by an and must be protected by an Authorized Mazda Dealer. ethylene-glycol-based coolant to prevent corrosion and freezing. Ø DO NOT USE coolants Containing Alcohol, methanol, Borate or Silicate.
Page 354: Power Steering Fluid
Mixing leaks and damage. different fluids will also damage them. If new fluid is required frequently, consult If the brake/clutch system an Authorized Mazda Dealer. frequently requires new fluid, consult an Authorized Mazda Dealer. 8-24 Form No.8CN3-EA-12I...
Page 355: Automatic Transaxle Fluid (Atf) Í
Automatic Transaxle Fluid the dipstick and wipe it clean, and then í (ATF) put it back. 5. Check the ATF level. If there is no ATF qInspecting Automatic Transaxle adhering 5 mm from the end of the Fluid Level dipstick, add ATF.
Page 356: Washer Fluid
Mazda5_8CN3-EA-12I_Edition1 Page356 Tuesday, September 4 2012 1:25 PM Black plate (356,1) Maintenance and Care Owner Maintenance CAUTION Washer Fluid Ø Use the cold scale only as a qInspecting Washer Fluid Level reference. Ø If outside temperature is lower WARNING than about 20 °C (70 °F), start the Use only windshield washer fluid or engine and inspect the fluid level plain water in the reservoir:...
Page 357: Body Lubrication
Mazda5_8CN3-EA-12I_Edition1 Page357 Tuesday, September 4 2012 1:25 PM Black plate (357,1) Maintenance and Care Owner Maintenance Inspect fluid level in the washer fluid Body Lubrication reservoir; add fluid if necessary. All moving points of the body, such as door and hood hinges and locks, should be lubricated each time the engine oil is changed.
Page 358: Wiper Blades
Be careful not to pinch hands or fingers as it may cause injury, or damage the wipers. When washing or servicing your Mazda, make sure the wiper lever is in the OFF position. Contamination of either the windshield or...
Page 359 Mazda5_8CN3-EA-12I_Edition1 Page359 Tuesday, September 4 2012 1:25 PM Black plate (359,1) Maintenance and Care Owner Maintenance 2. Hold the end of the rubber and pull CAUTION until the tabs are free of the metal Ø Don't bend or discard the support.
Page 360 Mazda5_8CN3-EA-12I_Edition1 Page360 Tuesday, September 4 2012 1:25 PM Black plate (360,1) Maintenance and Care Owner Maintenance 3. Pull down the blade rubber and slide it CAUTION out of the blade holder. To prevent damage to the wiper arm and other components, don't try to sweep the wiper arm by hand.
Page 361 Mazda5_8CN3-EA-12I_Edition1 Page361 Tuesday, September 4 2012 1:25 PM Black plate (361,1) Maintenance and Care Owner Maintenance 5. Carefully insert the new blade rubber. Then install the blade assembly in the reverse order of removal. 8-31 Form No.8CN3-EA-12I...
Page 362: Battery
Mazda5_8CN3-EA-12I_Edition1 Page362 Tuesday, September 4 2012 1:25 PM Black plate (362,1) Maintenance and Care Owner Maintenance Battery WARNING Wash hands after handling the battery and related accessories: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Read the following precautions carefully before using the battery or inspecting to ensure safe and correct handling: Always wear eye protection when working near the battery:...
Page 363 Mazda5_8CN3-EA-12I_Edition1 Page363 Tuesday, September 4 2012 1:25 PM Black plate (363,1) Maintenance and Care Owner Maintenance Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode.
Page 364 Mazda5_8CN3-EA-12I_Edition1 Page364 Tuesday, September 4 2012 1:25 PM Black plate (364,1) Maintenance and Care Owner Maintenance 2 Detach the clip facing the vehicle NOTE interior first and pull it outward Remove the battery cover before performing with your finger approx. 4 mm (0.2 battery maintenance.
Page 365 Mazda5_8CN3-EA-12I_Edition1 Page365 Tuesday, September 4 2012 1:25 PM Black plate (365,1) Maintenance and Care Owner Maintenance 3 Pull out the battery cover being 2 Attach the clips on both sides of careful not to allow it to contact the battery cover. the cowl grille.
Page 366: Tires
Using Wrong-Sized Tires: between the upper and lower level Using any other tire size than what is (illustration). specified for your Mazda (page 10-6) is dangerous. It could seriously affect Don't overfill. ride, handling, ground clearance, tire Examine the specific gravity of the...
Page 367 Do not use any part for the tire valve cap that is not a Mazda- genuine part. Refer to the specification charts (page 10-6).
Page 368 Mazda5_8CN3-EA-12I_Edition1 Page368 Tuesday, September 4 2012 1:25 PM Black plate (368,1) Maintenance and Care Owner Maintenance During rotation, inspect them for correct NOTE balance. Always check tire pressure when tires are cold. Warm tires normally exceed recommended pressures. Don't release air from warm tires to adjust the pressure.
Page 369 Be sure to install the tire pressure sensors Inspect the temporary spare tire at least whenever tires or wheels are replaced. monthly to make sure it's properly inflated Refer to Tires and Wheels on page 5-30. and stored. NOTE The temporary spare tire condition gradually deteriorates even if it has not been used.
Page 370 Ø Headlight aim Ø The temporary spare tire has a Ø Bumper height tread life of less than 5,000 km Ø Tire Pressure Monitoring (3,000 miles). The tread life may System be shorter depending on driving Ø...
Page 371 Mazda5_8CN3-EA-12I_Edition1 Page371 Tuesday, September 4 2012 1:25 PM Black plate (371,1) Maintenance and Care Owner Maintenance When replacing a wheel, make sure the new one is the same as the original factory wheel in diameter, rim width, and offset (inset/outset). Proper tire balancing provides the best riding comfort and helps reduce tread wear.
Page 372: Light Bulbs
Mazda5_8CN3-EA-12I_Edition1 Page372 Tuesday, September 4 2012 1:25 PM Black plate (372,1) Maintenance and Care Owner Maintenance Light Bulbs Overhead light/Map lights (Front) Side turn signal lights Fog lights Front turn signal lights/Front side-marker Headlights (High beam) lights/Parking lights Headlights (Low beam) Overhead light (Rear) High-mount brake light License plate lights...
Page 373 Wire shock if the bulbs are handled incorrectly. Consult an Authorized Mazda Dealer when the replacement is necessary. Guide Never touch the glass portion of a halogen bulb with your bare hands and 4.
Page 374 Low-beam bulbs (Xenon fusion bulb) You cannot replace the low beam bulbs by yourself. The bulbs must be replaced at an 5. Install the new bulb in the reverse order Authorized Mazda Dealer. of the removal procedure. (Halogen bulb) 1. Make sure the ignition is switched off, and the headlight switch is off.
Page 375 Carefully remove the bulb from its socket in the reflector by gently pulling it straight backward out of the socket. 5. Install the new bulb in the reverse order of the removal procedure. í 8-45 Some models.
Page 376 3. Pull the upper part of the cover around the clip outward to detach the clip. Clip 5. Install the new bulb in the reverse order of the removal procedure. í Side turn signal lights Due to the complexity and difficulty of the procedure, the LED bulbs must be replaced by an Authorized Mazda Dealer.
Page 377 Maintenance and Care Owner Maintenance 4. Pull the unit rearward to remove it. Rear turn signal lights 5. Turn the socket and bulb assembly 7. Install the new bulb in the reverse order counterclockwise and remove it. of the removal procedure.
Page 378 4. Disconnect the bulb from the socket. 3. Disconnect the bulb by pulling it out. 5. Install the new bulb in the reverse order of the removal procedure. High-mount brake light 4. Install the new bulb in the reverse order Due to the complexity and difficulty of of the removal procedure.
Page 379 Mazda5_8CN3-EA-12I_Edition1 Page379 Tuesday, September 4 2012 1:25 PM Black plate (379,1) Maintenance and Care Owner Maintenance qReplacing Interior Light Bulbs Overhead light (Rear) 1. Wrap a small flathead screwdriver with Overhead light (Front)/Map lights a soft cloth to prevent damage to the 1.
Page 380: Fuses
If a fuse has blown, the inside element will be melted. If the same fuse blows again, avoid using that system and consult an Authorized Mazda Dealer as soon as possible. qFuse Replacement Replacing the fuses on the vehicle's left side...
Page 381 If a fuse is blown, it must be replaced. Follow these steps: 1. Make sure the ignition is switched off, and other switches are off. 2. Remove the fuse block cover. 5. Inspect the fuse and replace it if it's blown. Fuse block Blown Normal 6.
Page 382 Normal Blown WARNING Do not replace the main fuse by yourself. Have an Authorized Mazda Dealer perform the replacement: Replacing the fuse by yourself is dangerous because the MAIN fuse is a high current fuse. Incorrect replacement could cause an electrical shock or a short circuit resulting in a fire.
Page 383 Mazda5_8CN3-EA-12I_Edition1 Page383 Tuesday, September 4 2012 1:25 PM Black plate (383,1) Maintenance and Care Owner Maintenance qFuse Panel Description Fuse block (Engine compartment) FUSE DESCRIPTION PROTECTED COMPONENT RATING IG KEY1 50 A For protection of various circuits AD FAN 30 A Cooling fan GLOW2 30 A...
Page 384 ABS V 20 A ABS, DSC í SUN ROOF 20 A Moonroof H/CLEAN HORN 15 A Horn ILLUMI 7.5 A Illumination ENG INJ 25 A Engine control system ENG BAR 15 A Engine control system í M.DEF 7.5 A Mirror defroster...
Page 385 Engine control system P.OUTLET 15 A Accessory sockets (Cargo compartment) SHIFT/L CIGAR 15 A Accessory sockets (Dashboard) MIRROR 7.5 A Power control mirror 10 A Air conditioner F.WIP 25 A Windshield wipers and washer R.WIP 15 A Rear window wiper...
Page 386: Appearance Care
Prevention Industrial pollutants and vehicle emissions drift into the air and mix with rain or dew It is necessary to have your Mazda to form acids. These acids can settle on a washed and waxed to preserve its finish according to the instructions in this vehicle's finish.
Page 387 The rings Chipped paint can lead to rust forming on can damage your vehicle's finish. your Mazda. Before this happens, repair the damage by using Mazda touch-up paint Prevention according to the instructions in this section.
Page 388: Exterior Care
NOTE Keep hands and scrapers clear of Mazda is not responsible for scratches the windshield when the wiper caused by automatic car washes or lever is in the AUTO position and improper washing.
Page 389 Mazda5_8CN3-EA-12I_Edition1 Page389 Tuesday, September 4 2012 1:25 PM Black plate (389,1) Maintenance and Care Appearance Care WARNING CAUTION Ø Do not use steel wool, abrasive Dry off brakes that have become wet by driving slowly, releasing the cleaners, or strong detergents accelerator pedal and lightly applying containing highly alkaline or the brakes several times until the brake...
Page 390 CAUTION coated with anti-corrosive material. If your Mazda is damaged and needs metal parts repaired or replaced, Thoroughly flush the underbody and make sure the body shop applies...
Page 391 Check special requirements for Tire Pressure Monitoring System. CAUTION Refer to Tires and Wheels on page 5-30. Do not use any detergent other than qPlastic Part Maintenance mild detergent. Before using any detergent, verify the ingredients.
Page 392: Interior Care
Mazda5_8CN3-EA-12I_Edition1 Page392 Tuesday, September 4 2012 1:25 PM Black plate (392,1) Maintenance and Care Appearance Care High water temperature and high water Interior Care pressure car washers are available depending on the type of high pressure WARNING car washer device. If the car washer Do not spray water in the cabin: nozzle is put too close to the vehicle or Splashing water on electrical parts...
Page 393 Mazda5_8CN3-EA-12I_Edition1 Page393 Tuesday, September 4 2012 1:25 PM Black plate (393,1) Maintenance and Care Appearance Care í Leather NOTE Because genuine leather is a natural Remove dust and sand first using a material, its surface is not uniform and it vacuum cleaner or other means, then wipe may have natural scars, scratches, and dirt off using a soft cloth with a leather...
Page 394 Floor Mats them. WARNING Rubber floor mats should be cleaned with mild soap and water only. Have an Authorized Mazda Dealer WARNING replace damaged seat belts immediately: Do not use rubber cleaners, such as tire Using damaged seat belts is cleaner or tire shine, when cleaning dangerous.
Page 395: Customer Information
Reporting Safety Defects ....... 9-43 Reporting Safety Defects (U.S.A.) ..9-43 Warranty ..........9-15 Reporting Safety Defects (Canada) ... 9-44 Warranties for Your Mazda ....9-15 Outside the United States ....9-16 Service Publications ......9-45 Outside Canada ......... 9-17 Service Publications ......
Page 396: Customer Assistance
Answers to many questions, including how to locate or contact a local Mazda dealership in the U.S., can be found here. E-mail: click on Contact Us located on the Inside Mazda tab, or at the bottom of the page at www.mazdaUSA.com By phone at: 1 (800) 222-5500 Form No.8CN3-EA-12I...
Page 397: Customer Assistance (Puerto Rico)
Mazda North American Operations realizes that mutual agreement on some issues may not be possible. As a final step to ensure that your concerns are being fairly considered, Mazda North American Operations has agreed to participate in a dispute settlement program administered by the Better Business Bureau (BBB) system, at no cost to you the consumer.
Page 398: Customer Assistance (Mexico)
Mazda or one of our dealers, and a statement of the relief you are seeking. 5. BBB AUTO LINE staff may try to help resolve your dispute through mediation. If...
Page 399 AND the nonconformity has been subject to repair two or more times by Mazda or its agents AND the buyer or lessee has directly notified Mazda of the need for the repair of the nonconformity; OR...
Page 400 11. If you accept the arbitrator's decision, Mazda will be bound by the decision, and will comply with the decision within a reasonable time not to exceed 30 days after we receive notice of your acceptance of the decision.
Page 401 Your complete and permanent satisfaction is of primary concern to Mazda. All Authorized Mazda Dealers have both the knowledge and tools to keep your Mazda in top condition. In our experience, any questions, problems, or complaints regarding the operation of your Mazda or any other general service transactions are most effectively resolved by your dealer.
Page 402 If a specific item of concern arises, where a solution cannot be reached between an owner, Mazda, and/or one of its dealers (that all parties cannot agree upon), the owner may wish to use the services offered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 403 1 (800) 207-0685 Ontario 1 (800) 207-0685 Atlantic Canada 1 (800) 207-0685 Quebec 1 (800) 207-0685 qRegional Offices REGIONAL OFFICES AREAS COVERED MAZDA CANADA INC. WESTERN REGION ALBERTA, 8171 ACKROYD ROAD BRITISH COLUMBIA, SUITE 2000 MANITOBA, RICHMOND B.C. SASKATCHEWAN, V6X 3K1...
Page 404 1 Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 405 Mazda vehicle or servicing by Mazda Dealer personnel, we recommend that you take the following steps: qContact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 406 3. Vehicle Identification Number (17 digits, noted on your registration or title or located on the upper driver's side corner of the dash) 4. Purchase date and current mileage 5. Your dealer's name and location 6. Your question(s) 9-12 Form No.8CN3-EA-12I...
Page 407: Mazda Importer/Distributors
Irvine, CA 92623-9734 U.S.A. (905) 787-7000 (outside Canada) TEL: 1 (800) 222-5500 (in U.S.A.) qPUERTO RICO/U.S. Virgin Island (949) 727-1990 (outside U.S.A.) Plaza Motors Corp. (Mazda de Puerto Rico) P.O. Box 362722, San Juan, Puerto Rico 00936-2722 TEL: (787) 641-9300...
Page 408 Mazda5_8CN3-EA-12I_Edition1 Page408 Tuesday, September 4 2012 1:25 PM Black plate (408,1) Customer Information Mazda Importer/Distributors Triple J Saipan, Inc. (d.b.a. Triple J Motors) P.O. Box 500487 Saipan, MP 96950-0487 TEL: (670) 234-7133/3051 qAMERICAN SAMOA Polynesia Motors, Inc. P.O. Box 1120, Pago Pago, American...
Page 409: Warranty
Mazda5_8CN3-EA-12I_Edition1 Page409 Tuesday, September 4 2012 1:25 PM Black plate (409,1) Customer Information Warranty Warranties for Your Mazda New Vehicle Limited Warranty Powertrain Limited Warranty Safety Restraint System Limited Warranty Anti-perforation Limited Warranty Federal Emission Control Warranty/California Emission Control Warranty...
Page 410: Outside The United States
We strongly recommend that you NOT take your Mazda outside the United States. However, in the event that you are moving to Canada permanently, Mazda vehicles built for use in the United States could be eligible for exportation to Canada with specific vehicle modifications to comply with the Canadian Motor Vehicle Safety Standards (CMVSS).
Page 411: Outside Canada
We strongly recommend that you NOT take your Mazda outside Canada. However, in the event that you are moving to the United States permanently, Mazda vehicles built for use in Canada could be eligible for exportation to the United States with specific vehicle modifications to comply with the United States Federal Motor Vehicle Safety Standards (FMVSS).
Page 412: Registering Your Vehicle In A Foreign Country (Except United States And Canada)
Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorized Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.
Page 413: Add-On Non-Genuine Parts And Accessories
Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may fit your vehicle, but they are not approved by Mazda for use with Mazda vehicles. When you install non-genuine parts or accessories, they could affect your vehicle's performance or safety systems;...
Page 414: Cell Phones
Mazda5_8CN3-EA-12I_Edition1 Page414 Tuesday, September 4 2012 1:26 PM Black plate (414,1) Customer Information Cell Phones Cell Phones Warning WARNING Please comply with the legal regulations concerning the use of communication equipment in vehicles in your State or Province: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous.
Page 415: Event Data Recorder
EDR. Mazda will not disclose any of the data recorded in an EDR to a third party unless: A written agreement from the vehicle owner or the lessee is obtained...
Page 416: Uniform Tire Quality Grading System (Utqgs)
Mazda5_8CN3-EA-12I_Edition1 Page416 Tuesday, September 4 2012 1:26 PM Black plate (416,1) Customer Information Uniform Tire Quality Grading System (UTQGS) Uniform Tire Quality Grading System (UTQGS) This information relates to the tire grading system developed by the U.S. National Highway Traffic Safety Administration for grading tires by tread wear, traction, and temperature performance.
Page 417 These grades will be added to the sidewalls of passenger vehicle tires over the next several years according to a schedule established by the NHTSA and the tire manufacturers. The grade of tires available as standard or optional equipment on Mazda vehicles may vary with respect to grade.
Page 418: Tire Information (U.s.a.)
1. TIN: U.S. DOT tire identification number 2. Passenger car tire 3. Nominal width of tire in millimeters 4. Ratio of height to width (aspect ratio) 5. Radial 6. Run-flat tire 7. Rim diameter code 8. Load index & speed symbol 9.
Page 419 Mazda5_8CN3-EA-12I_Edition1 Page419 Tuesday, September 4 2012 1:26 PM Black plate (419,1) Customer Information Tire Information (U.S.A.) 11. Max. load rating 12. Tread wear, traction and temperature grades 13. Max. permissible inflation pressure 14. SAFETY WARNING P215/65R15 95H is an example of a tire size and load index rating. Here is an explanation of the various components of that tire size and load index rating.
Page 420 Mazda5_8CN3-EA-12I_Edition1 Page420 Tuesday, September 4 2012 1:26 PM Black plate (420,1) Customer Information Tire Information (U.S.A.) H is the speed rating. The speed rating denotes the maximum speed for which the use of the tire is rated. Letter Rating Speed Rating 99 mph 106 mph 112 mph...
Page 421 Mazda5_8CN3-EA-12I_Edition1 Page421 Tuesday, September 4 2012 1:26 PM Black plate (421,1) Customer Information Tire Information (U.S.A.) Tread Wear, Traction and Temperature Grades Tread wear: The tread wear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course.
Page 422 2. Nominal width of tire in millimeters 3. Ratio of height to width (aspect ratio) 4. Diagonal 5. Rim diameter code 6. Load index & speed symbol T115/70D 16 90M is an example of a tire size and load index rating. Here is an explanation of the various components of that tire size and load index rating.
Page 423 Mazda5_8CN3-EA-12I_Edition1 Page423 Tuesday, September 4 2012 1:26 PM Black plate (423,1) Customer Information Tire Information (U.S.A.) 70 is the aspect ratio. This two-digit number indicates the tire's ratio of height to width. D is the tire construction symbol. D indicates diagonal ply construction . 16 is the wheel rim diameter in inches.
Page 424: Location Of The Tire Label (Placard)
Mazda5_8CN3-EA-12I_Edition1 Page424 Tuesday, September 4 2012 1:26 PM Black plate (424,1) Customer Information Tire Information (U.S.A.) Location of the Tire Label (Placard) You will find the tire label containing tire inflation pressure by tire size and other important information on the driver's side B-pillar or on the edge of the driver's door frame. SAMPLE qRecommended Tire Inflation Pressure On the tire label you will find the recommended tire inflation pressure in both kPa and psi...
Page 425 3. Firmly press a tire gauge onto the valve. 4. Add air to achieve recommended air pressure. 5. If you overfill the tire, release air by pushing on the metal stem in the center of the valve. Then recheck the pressure with your tire gauge.
Page 426 Mazda5_8CN3-EA-12I_Edition1 Page426 Tuesday, September 4 2012 1:26 PM Black plate (426,1) Customer Information Tire Information (U.S.A.) qGlossary of Terms Tire Placard: A label indicating the OE tire sizes, recommended inflation pressure, and the maximum weight the vehicle can carry. Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size, and date of manufacture.
Page 427: Tire Maintenance
Mazda5_8CN3-EA-12I_Edition1 Page427 Tuesday, September 4 2012 1:26 PM Black plate (427,1) Customer Information Tire Information (U.S.A.) Tire Maintenance Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Here are some important maintenance points: qTire Inflation Pressure Inspect all tire pressure monthly (including the spare) when the tires are cold. Maintain recommended pressures for the best ride, top handling, and minimum tire wear.
Page 428 Mazda5_8CN3-EA-12I_Edition1 Page428 Tuesday, September 4 2012 1:26 PM Black plate (428,1) Customer Information Tire Information (U.S.A.) CAUTION Rotate unidirectional tires and radial tires that have an asymmetrical tread pattern or studs only from front to rear, not from side to side. Tire performance will be weakened if rotated from side to side.
Page 429 Mazda5_8CN3-EA-12I_Edition1 Page429 Tuesday, September 4 2012 1:26 PM Black plate (429,1) Customer Information Tire Information (U.S.A.) NOTE Tires degrade over time, even when they are not being used on the road. It is recommended that tires generally be replaced when they are 6 years or older. Heat caused by hot climates or frequent high loading conditions can accelerate the aging process.
Page 430: Vehicle Loading
Mazda5_8CN3-EA-12I_Edition1 Page430 Tuesday, September 4 2012 1:26 PM Black plate (430,1) Customer Information Tire Information (U.S.A.) Vehicle Loading WARNING Do not tow a trailer with this vehicle: Towing a trailer with this vehicle is dangerous because it has not been designed to tow a trailer and doing so will affect the drive system which could result in vehicle damage.
Page 431 Mazda5_8CN3-EA-12I_Edition1 Page431 Tuesday, September 4 2012 1:26 PM Black plate (431,1) Customer Information Tire Information (U.S.A.) Base Curb Weight is the weight of the vehicle including a full tank of fuel and all standard equipment. It does not include passengers, cargo, or optional equipment. Vehicle Curb Weight is the weight of your new vehicle when you picked it up from your dealer plus any aftermarket equipment.
Page 432 Mazda5_8CN3-EA-12I_Edition1 Page432 Tuesday, September 4 2012 1:26 PM Black plate (432,1) Customer Information Tire Information (U.S.A.) SAMPLE CARGO Cargo Weight includes all weight added to the Base Curb Weight, including cargo and optional equipment. The cargo weight limit decreases depending on the number of vehicle occupants. The cargo weight limit can be calculated by subtracting the total weight of the vehicle occupants from the combination weight of occupants and cargo should never exceed value on the tire label.
Page 433 Mazda5_8CN3-EA-12I_Edition1 Page433 Tuesday, September 4 2012 1:26 PM Black plate (433,1) Customer Information Tire Information (U.S.A.) Examples: Based on a single occupant weight of 68 kg (150 lbs), and a value of 385 kg (849 lbs) for the combination weight of occupants and cargo should never exceed : The cargo weight limit with one occupant is 385 kg (849 lbs) _ 68 kg (150 lbs) = 317 kg (699 lbs) The cargo weight limit with two occupants is 385 kg (849 lbs) _ (68 ×...
Page 434 Mazda5_8CN3-EA-12I_Edition1 Page434 Tuesday, September 4 2012 1:26 PM Black plate (434,1) Customer Information Tire Information (U.S.A.) SAMPLE WARNING Exceeding Axle Weight Rating Limits: Exceeding the Safety Certification Label axle weight rating limits is dangerous and could result in death or serious injury as a result of substandard vehicle handling, performance, engine, transmission and/or structural damage, serious damage to the vehicle, or loss of control.
Page 435 Mazda5_8CN3-EA-12I_Edition1 Page435 Tuesday, September 4 2012 1:26 PM Black plate (435,1) Customer Information Tire Information (U.S.A.) GCW (Gross Combination Weight) is the weight of the loaded vehicle (GVW). GCWR (Gross Combination Weight Rating) is the maximum allowable weight of the vehicle - including all cargo and passengers - that the vehicle can handle without risking damage.
Page 436: Steps For Determining The Correct Load Limit
For example, if the XXX amount equals 1400 lbs. and there will be five 150 lb passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs. (1400 _ 750 (5 × 150) = 650 lbs.) (5) Determine the combined weight of luggage and cargo being loaded on the vehicle.
Page 437: Reporting Safety Defects
Irvine, California 92618-2922 P.O. Box 19734 Irvine, CA 92623-9734 Customer Assistance Center or toll free at 1 (800) 222-5500 If you live outside of the U.S.A., please contact the nearest Mazda Distributor shown (page 9-13) in this booklet. 9-43 Form No.8CN3-EA-12I...
Page 438: Reporting Safety Defects (Canada)
Mazda5_8CN3-EA-12I_Edition1 Page438 Tuesday, September 4 2012 1:26 PM Black plate (438,1) Customer Information Reporting Safety Defects Reporting Safety Defects (Canada) Canadian customers who wish to report a safety-related defect to Transport Canada, Defect Investigations and Recalls, may telephone the toll free hotline 1-800-333-0510, or contact Transport Canada by mail at: Transport Canada, ASFAD, Place de Ville Tower C, 330 Sparks Street, Ottawa ON K1A 0N5.
Page 439: Service Publications
Factory-authorized Mazda service publications are available for owners who wish to do some of their own maintenance and repair. When requesting any of our publications through an Authorized Mazda Dealer, refer to the chart below. If they do not have what you need in stock, they can order it for you.
Page 440 Mazda5_8CN3-EA-12I_Edition1 Page440 Tuesday, September 4 2012 1:26 PM Black plate (440,1) 9-46 Form No.8CN3-EA-12I...
Page 441 Mazda5_8CN3-EA-12I_Edition1 Page441 Tuesday, September 4 2012 1:26 PM Black plate (441,1) Specifications Technical information about your Mazda. Identification Numbers ............... 10-2 Vehicle Information Labels ............. 10-2 Specifications ................10-4 Specifications ................10-4 Personalization Features ............10-8 Personalization Features ............10-8 10-1 Form No.8CN3-EA-12I...
Page 442: Identification Numbers
Mazda5_8CN3-EA-12I_Edition1 Page442 Tuesday, September 4 2012 1:26 PM Black plate (442,1) Identification Numbers qChassis Number Vehicle Information Labels qVehicle Identification Number The vehicle identification number legally identifies your vehicle. The number is on a plate attached to the cowl panel located on the left corner of the dashboard.
Page 443 Mazda5_8CN3-EA-12I_Edition1 Page443 Tuesday, September 4 2012 1:26 PM Black plate (443,1) Identification Numbers qEngine Number Forward 10-3 Form No.8CN3-EA-12I...
Page 444: Specifications
API Service GL-4 Manual transaxle oil 75W-80 Automatic transaxle fluid Mazda Genuine ATF M-V Mazda Genuine ATF M-III , M-V, or equivalent Power steering fluid (e.g. Dexron® II) Brake/Clutch fluid SAE J1703 or FMVSS116 DOT-3 NOTE Refer to Introduction on (page 8-2) for owner's responsibility in protecting your investment.
Page 445 (Approximate Quantities) Item Capacity With oil filter replacement 5.0 L (5.3 US qt, 4.4 Imp qt) Engine oil Without oil filter replacement 4.6 L (4.9 US qt, 4.0 Imp qt) Manual transaxle 6.7 L (7.1 US qt, 5.9 Imp qt) U.S.A.
Page 446 NOTE The tires have been optimally matched with the chassis of your vehicle. When replacing tires, Mazda recommends that you replace tires of the same type originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer. í...
Page 447 Mazda5_8CN3-EA-12I_Edition1 Page447 Tuesday, September 4 2012 1:26 PM Black plate (447,1) Specifications Check the tire pressure label for tire size and inflation pressure. Refer to Tire Inflation Pressure on page 8-37. Standard tire Inflation pressure Tire size Front Rear P205/55R16 89H 240 kPa (35 psi) 240 kPa (35 psi) 205/50R17 89V...
Page 448: Personalization Features
Low/Deactivated The time required for the interior lamp to turn off automatically after all the doors are closed 15 seconds 7.5/30/60 seconds can be changed The time required for the interior lamp to illuminate after unlocking any door can be 30 seconds 7.5/15/60 seconds...
Page 449: Index
Mazda5_8CN3-EA-12I_Edition1 Page449 Tuesday, September 4 2012 1:26 PM Black plate (449,1) Index 11-1 Form No.8CN3-EA-12I...
Page 450 ........6-76 Ambient Temperature Display ..6-98 Convenient use of the hands-free Antenna ..........6-11 system ........6-81 Anti-Lock Brake System (ABS) ..5-8 Hands-free setting ...... 6-87 Warning light ....... 5-8 Mazda Bluetooth® Hands-Free Appearance Care ....... 8-56 customer service ......
Page 451 Mazda5_8CN3-EA-12I_Edition1 Page451 Tuesday, September 4 2012 1:26 PM Black plate (451,1) Index Child Restraint Dynamic Stability Control (DSC) ..5-24 Child restraint precautions ..2-30 DSC OFF indicator light .... 5-25 Child-restraint system installation DSC OFF switch ......5-25 position ........2-35 TCS/DSC indicator light ....
Page 452 Headlight high-beam ....5-51 Gauge ......... 5-39 Low engine coolant Requirements ....... 4-2 temperature ........ 5-52 Tank capacity ......10-5 Power steering malfunction ..5-53 Fuses ..........8-50 Security ........5-51 Panel description ......8-53 Shift position ......5-51 Replacement ....... 8-50 TCS/DSC ........
Page 453 Parking in an Emergency ....7-2 Replacement ....... 8-42 Parking Sensor System ..... 5-32 Specifications ......10-6 Park assist sensor switch .... 5-34 Lighting Control ....... 5-56 Parking sensor warning beep ..5-35 Lubricant Quality ......10-4 Sensor detection range ....5-34 Luggage Compartment Light ....
Page 454 Specifications ........10-4 Hook .......... 7-23 Speedometer ........5-38 Tire Information ........ 9-24 SRS Air Bags Tire Pressure Monitoring System ..5-26 Driver and front passenger occupant System error activation ....5-30 classification system ....2-59 Tire pressure monitoring system How the SRS air bags work ..
Page 455 High engine coolant Towing temperature ........ 5-46 Description ......... 7-22 Low fuel ........5-47 Emergency towing ..... 7-22 Low washer fluid level ....5-48 Hook .......... 7-23 Malfunction ........ 5-44 Recreational towing ....7-25 Seat belt ........5-48 Trailer towing ......4-12 Tire pressure monitoring Traction Control System (TCS) ..
Page 456 Mazda5_8CN3-EA-12I_Edition1 Page456 Tuesday, September 4 2012 1:26 PM Black plate (456,1) 11-8 Form No.8CN3-EA-12I...

Mazda 5 Manual

Quick Links

Chapters

Related Manuals for Mazda 5

Summary of Contents for Mazda 5
