Mazda 5 Workshop Manual

MZ5 FRONT SEAT BELT REMOVAL INSTALLATION
WARNING:
Handling the front seat belt (pre-tensioner seat belt) improperly can accidentally deploy the pre-tensioner
seat belt, which may seriously injure you. Read the air bag system service warnings and cautions before
handling the front seat belt. (See
SYSTEM SERVICE CAUTIONS
WARNING:
The side air bag sensor is attached to the lower part of the B-pillar. When working around the B-pillar,
disconnect the negative battery cable avoiding excessive impact to the lower part of the B-pillar.
CAUTION:
The ELR (emergency locking retractor) has a spring that will unwind if the retractor cover is removed.
The spring cannot be rewound by hand. If this occurs, the ELR will not work properly. Therefore, do not
disassemble the retractor.
1. Turn the ignition switch to the LOCK position.
2. Remove the battery cover. (See
3. Disconnect the negative battery cable and wait for 1min or more .
4. Remove the front scuff plate inner. (See
5. Remove the rear scuff plate. (See
6. Remove the B-pillar lower trim. (See
7. Remove the cover.
1 of 2
Mazda5 Workshop Manual - Restraints
AIR BAG SYSTEM SERVICE WARNINGS
.)
BATTERY REMOVAL/INSTALLATION [L3]
FRONT SCUFF PLATE REMOVAL/INSTALLATION
REAR SCUFF PLATE REMOVAL/INSTALLATION
B-PILLAR LOWER TRIM REMOVAL/INSTALLATION
.) (See AIR BAG
.)
.)
.)
.)
