SPECIFICATIONS

• Selectivity
WFM
WFM/FM/AM
FM/AM
FM/AM/SSB/CW
AM/SSB/CW
• IF shift range
• Max. audio output
• Antenna connector
• RS-232C connector
• Ext. speaker connector
• Dimensions
(projections not included)
• Weight
All stated specifications are subject to change without
notice or obligation.
14
: 230 kHz/–6 dB
: 50 kHz/–6 dB
: 15 kHz/–6 dB
: 6 kHz/–6 dB
: 2.8* kHz/–6 dB
*Software indicates 3 kHz.
: More than ±1.2 kHz
: 200 mW
(at 10% distortion with an 8 Ω load)
: BNC (50 Ω)
: D-sub 9-pin (female)
1
: 3-conductor 3.5 (d) mm ( ⁄ ")/
8
4–8 Ω
: 127.5(W) × 30(H) × 199(D) mm
5(W) × 1 (H) × 7
3 27
⁄ ⁄ (D) in
16 32
: approx. 1 kg; 2 lb 3 oz.
