Specifications - Icom IC-PCR1000 Instruction Manual

• Frequency coverage (MHz)
U.S.A. : 0.010000–823.999999*
849.000001–868.999999
894.000001–1300.000000
Europe : 0.010000–1300.000000*
* Specifications guaranteed 0.5–1300 MHz only.
• Receive system : Triple superheterodyne
• Mode : WFM, FM, AM, SSB, CW
• Frequency stability : ±3 ppm at 1300 MHz
(0°C to +50°C; 32°F to +122°F)
• Frequency resolution : 1 Hz (minimum)
• Power supply requirement : 13.8 V DC ±15 % for receiver unit;
or, supplied AC adapter
(negative ground)
• Current drain (at 13.8 V DC)
Power ON (PC power OFF) : 0.1 A
Max. audio : 0.7 A
Standby (squelched) : 0.6 A
• Usable temp. range : 0°C to +50°C; +32°F to +122°F
• Intermediate frequencies
1st : 266.7 MHz
2nd : 10.7 MHz
3rd : 450 kHz (except WFM)

SPECIFICATIONS

• Receive sensitivity (typical)*:
Frequency
SSB/CW
(MHz)
(10 dB S/N)
0.5–1.799999 0.56 µV
1.8–27.99999
0.28 µV
28–29.99999
30–49.99999 0.35 µV
50–699.99999 0.2 µV
700–1300 0.25 µV
* When 230 kHz (for WFM), 15 kHz (for FM), 6 kHz (for AM) and 2.8
kHz (for SSB/CW) passband widths are selected.
• Squelch sensitivity (threshold):
Frequency
SSB/CW
(MHz)
0.5–1.799999 14 µV
1.8–27.99999
28–29.99999 7.1 µV
30–49.99999
50–699.99999 5.6 µV
700–1300 7.1 µV
3
AM FM WFM
(10 dB S/N) (12 dB SINAD) (12 dB SINAD)
2.5 µV
—
1.4 µV —
0.5 µV
1.8 µV
1.0 µV 0.32 µV 0.79 µV
1.3 µV 0.4 µV 1.0 µV
AM FM WFM
1.8 µV
—
—
0.89 µV
0.63 µV
0.71 µV 0.5 µV 5.6 µV
0.89 µV 0.63 µV 7.1 µV
13
