QLogic 3000/5000/9000 Series Fibre Channel Switch
QLogic Intelligent Pass-thru Module for IBM BladeCenter
QLogic 20-Port SAN Switch Module for IBM BladeCenter
QLogic Virtual Fabric Extension Module for IBM BladeCenter
Firmware Version 7.x, 8.x, 9.x
59223-03 E
