  • Page 1 PLEASE CAREFULLY READTHIS ENTIRE MANUAL BEFORE OPERATING YOUR NEW FITNESS BIKE...
  • Page 2 TA LE OF Product Registration Important Safety Instruction_ Important Electrical Information Important Operation Instructions B94 Assembly Instructions R92 Assembly Instructions Fitness Bike Features Operation of Your New Fitness Bike Programmable Features Using Heart Rate Monitor General Maintenance Manufacturer's Limited Warranty ATTENTION THIS FITNESSBIKE IS INTENDED FOR RESIDENTIAL USE ONLY AND ISWARRANTED FOR THE APPLICATION.
  • Page 3 T N E S S CONGRATULATIONS ON YOUR NEW FITNESS BIKE AND WELCOME TO THE SOLE FAMILW Thank you for your purchase of this quality fitness bike from SOLE. Your new fitness bike has been manufactured by one of the leading...
  • Page 4 IMPORTANT TYI ST LICTI WARNING - Read all instructions before using this appliance. Do not operate fitness bike on deeply padded, plush or shag carpet. Damage to both carpet and fitness bike may result. Keep children away from the fitness bike.There are obvious pinch...
  • Page 5 Pushing harder is not going to make the unit go faster or slower. If you feel the buttons are not functioning properly with normal pressure contact your SOLE dealer. B94/Rg2 FITNESS BIKE...
  • Page 6 ASSEM LY PACK C HECKLIST E J)W £. EPJ #50.3/8"x 2" #71.3/8"x 25mm x 2T Hex Head Bolt (4 pcs) Flat Washer (4 pcs) #72.5/16"x 18mm x 1.5T #51.5/16"x 5/8" #99.5/16"x 19x 1.5T Flat Washer (6 pcs) Hex Head Bolt (7 pcs) Curved Washer (1 pc) #51.5/16"...
  • Page 7 #92.13/15mm Wrench #93. PhillipsHeadScrewdriver #100.12/14mm Wrench ASSEM LYINSTRUCTIONS PRE-AS Using a razor knife (Box Cutter) cut the outside, bottom, edge of box along the dotted Line. Lift Box over the unit and unpack. Carefully remove all parts from carton and inspect for any damage or missing parts.
  • Page 8 #50.3/8"x 2" Hex Head Bolt (4 pcs) #71.3/8"x 25 x 2T Flat Washer (4 pcs) Attach the Rear Stabilizer (5) onto the Main Frame (1) with the four Hex Head Bolts (50) and four Flat Washers (71).Tighten using the 12/14mm Wrench (100).
  • Page 9 HANDLEBA #51.5/16"x 5/8" Hex Head Bolt (2 pcs) #72.5/16"x 18x 1.5T Flat Washer (2 pcs) #103.5/16"x 1.5T Split Washer (2 pcs) Remove the plastic tie from the center of the handlebar (3). Insert the two hand pulse cables (26) through the opening of the handlebar mounting...
  • Page 10 B94/R92 FITNESS BIKE...
  • Page 11 ASSEM LY PACK C HECKLIST H6f]DW .$TE #65.3/8" x 2-1/4" #77.3/8"x 19x 1.5T Hex Head Bolt (4 pcs) Flat Washer (6 pcs) #84.3/8"x 25 x 2T #176.3/8" x 3/4" Flat Washer (4 pcs) Hex Head Bolt (6 pcs) #71.3/8"x 1-3/4" #77.3/8"x 19 x 1.5T Hex Head Bolt (2 pcs)
  • Page 12 E DWABE. r 3 #68.5/16"x 5/8" #76.5/16"x 18x 1.5T Hex Head Bolt (8 pcs) Flat Washer (6 pcs) #82.5/16"x 1.5T #83.5/16"x 19 x 1.5T Split Washer (2 pcs) Curved Washer (2 pcs) #98. M5 x 15mm #99. M5 x 12mm #105.4 x 16mm Phillips...
  • Page 13 #132.14/15mm Wrench #114. PhillipsHeadScrewdriver #115.Combination M5 AllenWrench #112.12/14mm Wrench & PhillipsHeadScrewDriver ASSEMBLY INSTRUCTIONS PRE-AS Using a razor knife (Box Cutter) cut the outside, bottom, edge of box along the dotted Line. Lift Box over the unit and unpack. Carefully remove all parts from carton and inspect for any damage or missing parts.
  • Page 14 #65.3/8"x 2-1/4" Hex Head Bolt (4 pcs) #77.3/8"x 19 x 1.ST Flat Washer (6 pcs) #84.3/8"x 25 x 2T Flat Washer (4 pcs) #176. 3/8"x 3/4" Hex Head Bolt (6 pcs) Attach the Rear Stabilizer (7) onto the Main Frame (1) with four Hex Head Bolts (65) and four Flat Washers (84) using the 12/14mm Wrench (112).
  • Page 15 CONSOLE MAS • #68.5/16"x 5/8" Hex Head Bolt (8 pcs) #76.5/16"x 18x 1.5T Flat Washer (6 pcs) #82.5/16"x 1.ST Split Washer (2 pcs) #83.5/16"x 19x 1.5T Curved Washer (2 pcs) Install the Console Mast Cover (31) onto the Console Mast (2). Make sure the plastic cover is in the correct orientation Feed the twist tie that is attached to the Computer Cable (44) and Hand pulse...
  • Page 16 SEAT/PEDAL & PLASTIC PARTS #98. M5 x 15mm Phillips Head Screw (4 pcs) #99. M5 x 12mm Phillips Head Screw (8 pcs) #105.4 x 16ram Sheet Metal Screw (4 pcs) Install the Seat (61) on the Seat Carriage (4) with the four Phillips Head Screws (98) using the Phillips Head Screw Driver (114).

  • Page 17: Foot Pedals

    Since the bike is wider, so is the distance between the pedals; this width between the pedals is called the Q factor. Sole has designed our pedal system so the Q factor is the smallest in the industry, but we did not stop there.
  • Page 18 OPERATION OFYOU IT GETTING FAMILIAR WITH THE CONTROL PANEL COOLING CONSOLE _SPEAKER DATA DISPLAY DOT MATRIX (Program P rofiles) PROGRAM MESSAGEWINDOW (Manual,Hill,FatBurn, (Distance, Watts,Speed, Strength, I nterval, Segment T ime) 2 User, 2 HR) ,FAN POWER S WITCH CONTROL AUDIO INJACI_ (MP3, CD, O R SMARTPHONE) COOLING...

  • Page 19: Console Operation

    POWER UP When power is connected to the fitness bike the console will automatically power up. These models are connected directly to 115VAC and there is a power switch located where the line cord plugs into the unit on the left side near the front.

  • Page 20: Enteringa Program

    Stop button actually has several functions. Pressing the Stopkey once during a program will Pause the program for 5 minutes. If you need to get a drink, answer the phone or any of the many things that could interrupt your workout, this is a great feature.To resume...

  • Page 21: Manual Program

    PROGRAMMA MANUAL PROGRAM The Manual program works as the name implies, manually.This means that you control workload yourself and not the computer. Press the Manual program button then press the Enter key. The Message window will ask you to enter your Age. You may adjust the age setting using the Level Up and Down keys, then press the Enter key to accept...
  • Page 22 PRESET PROGRAMS The fitness bike has five different programs that have been designed for a variety of workouts. These five programs have factory preset work level profiles for achieving different goals. Hill The Hill program simulates going up and down a hill.The resistance in the pedals will steadily increase and then decrease during the program.

  • Page 23: Preset Buttons

    PROGRAMMING PRESET BUTTONS Press the desired program button then press the Enter key. The message window will ask you to enter your Age. You may adjust the weight setting, using the Level Up and Down keys, then press the Enter key to accept the new number and proceed on to the next screen.

  • Page 24: Heart R Ate P Rograms

    Consult your physician before participating in any exercise program. With all SOLE Heart Rate Control fitness bike machines you may use the heart rate monitor feature without using the Heart Rate Control program.This function can be used during...
  • Page 25 RATE OF PERCEIVED EXERTION Heart rate is important but listening to your body also has a lot of advantages.There are more variables involved in how hard you should workout than just heart rate. Your stress level, physical health, emotional health, temperature, humidity, the time of day, the last time you ate and what you ate, all contribute...

  • Page 26: Erratic Operation

    USING How to wear your wireless chest strap transmitter: Attach the transmitter to the elastic strap using the locking parts. Adjust the strap as tightly as possible as long as the strap is not too tight to remain comfortable. Position the transmitter with the logo centered in the middle...

  • Page 27: Heart Rate Control

    HEART RATE CONTROL PROGRAM OPERATION Both programs operate the same, the only difference is that HR1 is set to 60% and HR2 is set to 80% of the maximum heart rate.They both are programmed the same way. To start an HRC program follow the instructions below...

  • Page 28: Maintenance

    GENERAL I T I. Wipe down all areas in the sweat path with a damp cloth after each workout. Ifa squeak, thump, clicking or rough feeling develops the main cause is most likely one of two reasons: The hardware was not sufficiently tightened during assembly.
  • Page 29 Products that do not have a warranty registration card on file at SOLE. SOLE reserves the right to request proof of purchase if no warranty record exists for the product.
