To remove the riser brackets:
Slide the side panels off.
1
Press the tabs to release the riser brackets.
2
Lift the riser bracket out of the MC Control to remove
3
Attaching an MC Control to Additional Units
An MC Control can be physically attached to up to four MC Mixes and one MC Transport to form a larger, stable control surface.
If you are using multiple units, see "Surfaces" on page 32 to use EuControl to arrange the units in the desired order.
To join an MC Control to an MC Mix:
On the MC Control, use a #2 Phillips screwdriver to remove the two silver screws. The screws may be tight, so you may have
1
to use some force.
Removing screws from the bottom panel
6
MC Control User Guide
