Chapter 5: Touchscreen and Controls
MC Control has a wide aspect ratio Touchscreen mounted in its center.
3
2
1 1
5
4
The Touchscreen always shows the following:
1 Knob Displays Show the current knob function for their corresponding knob. There are four on each side of the Touchscreen.
2 Info Area Shows the application and workstation name, the primary and secondary time code displays, or the attentioned track
name. Touch this area to switch between them.
3 Channel Strip Displays Shows the tracks assigned to the channel strips. The attentioned track is underlined in yellow.
4 Soft Key Labels Shows an optional icon followed by a text label for each of the 12 Soft Keys underneath the screen.
5 Menu Bar Displays the Tracks view, Soft Key view, or Setup Screens on the Touchscreen. The center of the screen changes to re-
flect the selected Menu view.
Chapter 5: Touchscreen and Controls 25
