Remote Menu Displays
This key will take the
menu system up one
level. In the above
example this key would
switch back to the
Counter Mode as this is
the top level of this
menu.
Menu Heading
Sub Menu
Menu Options
Use the Trim+/- keys
or SpinKnob to scroll
through available
Sub Menus or
Options. In this
example the Trim +
key would move from
the Resolution
options to the Abs/
Rel option then to the
Title Timeline, then
the Format options.
Trim
Trim
-
+
Page 38
Menu Name
Time
Format/Res
Sub Menu Name
In the above example, the
Select key will display the
Sub Menu Options.
Time Display Menu
Format/Res
Timecode sec
Timecode fr
Timecode subfr
Time ms
Time smp
Feet
Feet fr
Samples
Abs/Relative
Absolute
Relative
Title Timeline
Title Time
Free Time

- Time Display -

Shows that other Sub
Menus or Options are
available. Scroll with
the Trim+/Trim- keys
or the SpinKnob.
(select)
(select)
<- ->
(select)
scroll
Trim Trim
- +
Use the Trim+/- keys or
SpinKnob to scroll
through available Sub
Menus or Options.
Scroll to the desired
option and press the
Select key to select an
option.
