Settingthe
Picture Size for ROB input
The PICTURE SIZEoption is usedto adjust the picture size when the input signal is ROB.Usethis feature for graphic arts and checking
photos. In TRUEmode, there is no distortion of the picture. In NORMALmode, the picture will be sealedvertically but will keep the
correct aspect ratio.
ON - When the picture size option is on and in NORMALmode, the picture is scaled to fill the screen vertically while horizontally
keeping the correct aspect ratio. In FULLmode, the horizontal will be scaled to fit the screen.
OFF- When the picture size option is off, TRUEmode displays the picture pixel-for-pixel, exactly the size of the image. If FULL
mode, the image is scaled to fit the screen.
Note: Whenusing a DTC 100HDreceivre,% _ -he o nly avrei_eNe m ode is FULL. T he picture will bescored_ofil_H;escr_er;.
The Setup Menu
TheSETUPmenu controls theway yourmonitor communicates w ithother components.
Confirming the Frequencies, Polarities, Mode and Resolution of Input Signals
The FREQUENCY f unction is usedto confirm the frequencies, polarities, mode and resolution of the signals coming from a computer.
To confirm frequencies, polarities, mode and resolution:
1. From the main menu, highlight and select the SETUP option. The SETUP
menu is displayed.
2. Highlight the FREQUENCYoption and pressOK.
3. The FREQUENCYSereen isdisplayed.
PressO0 BACKto return to the SETUP menu, or pressCLEAR to exit the
menu system.
This is {:heSETUPmenu with the FREQUENCY" op{:ion
higfdighLe&
This is t:he F REQUENCY screen.
33
