Setting the Picture Size for RGB Input
The PICTURE SIZE option is used to adjust the picture size when the input signal is RGB. Use this feature for graphic arts and checking
photos. In TRUE mode, there is no distortion of the picture. In NORMAL mode, the picture will be scaled vertically but will keep the
correct aspect ratio.
ON – When the picture size option is on and in NORMAL mode, the picture is scaled to fill the screen vertically while horizontally
keeping the correct aspect ratio. In FULL mode, the horizontal will be scaled to fit the screen.
OFF – When the picture size option is off, TRUE mode displays the picture pixel-for-pixel, exactly the size of the image. If FULL
mode, the image is scaled to fit the screen.
Note: When using a DTC100 HD receiver, the only available mode is FULL. The picture will be scaled to fill the screen.

The Setup Menu

The SETUP menu controls the way your monitor communicates with other components.

Confirming the Frequencies, Polarities, Mode and Resolution of Input Signals

The FREQUENCY function is used to confirm the frequencies, polarities, mode and resolution of the signals coming from a computer.
To confirm frequencies, polarities, mode and resolution:
SETUP
FREQUENCY
MENU LANGUAGE
COLOR SYSTEM
SEL. OK
This is the SETUP menu with the FREQUENCY option
highlighted.
FREQUENCY
H. FREQUENCY : 37.5KHz
V. FREQUENCY : 75.0Hz
H. POLARITY : NEG.
V. POLARITY : NEG.
MODE : 8
RESOLUTION
: 640 X 480
This is the FREQUENCY screen.
Chapter 2
1. From the main menu, highlight and select the SETUP option. The SETUP
menu is displayed.
2. Highlight the FREQUENCY option and press OK.
3. The FREQUENCY screen is displayed.
Press GO BACK to return to the SETUP menu, or press CLEAR to exit the
menu system.
RETURN
RETURN
