User's Manual
4 High Resolution Video and Serial Link
Mini Twisted Pair Transmitter Assembly
MTP 4T 15HD RS
68-1398-01 Rev. A
12 07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A/V Receiver MTP 4T 15HD RS and is the answer not in the manual?

Questions and answers

Related Manuals for Extron electronics A/V Receiver MTP 4T 15HD RS

Summary of Contents for Extron electronics A/V Receiver MTP 4T 15HD RS

  • Page 1 Extron Electronics, USA Extron Electronics, Europe Extron Electronics, Asia 1230 South Lewis Street Beeldschermweg 6C 135 Joo Seng Rd. #04-01 Anaheim, CA 92805 3821 AH Amersfoort, The Netherlands PM Industrial Bldg., Singapore 368363 800.633.9876 714.491.1500 +800.3987.6673 +31.33.453.4040 +800.7339.8766 +65.6383.4400 FAX 714.491.1517 FAX +31.33.453.4050 FAX +65.6383.4664 www.extron.com...

  • Page 2: Extron's Warranty

    Precautions Safety Instructions • English Warning Power sources • This equipment should be operated only from the power source This symbol is intended to alert the user of important indicated on the product. This equipment is intended to be used with a main power operating and maintenance (servicing) instructions in system with a grounded (neutral) conductor.

  • Page 3: Fcc Class A Notice

    安全须知 • 中文 这个符号提示用户该设备用户手册中 有重要的操作和维护说明。 这个符号警告用户该设备机壳内有暴 露的危险电压，有触电危险。 注意 阅读说明书 • 用 户 使 用 该 设 备 前 必 须 阅 读 并 理 解 所 有 安 全 和 使 用 说 明 。 保存说明书 • 用户应保存安全说明书以备将来使 用。 遵守警告 • 用户应遵守产品和用户指南上的所有安 全和操作说明。...

  • Page 4: Table Of Contents

    Table of Contents Chapter One • Introduction ... 1-1 About the MTP 4T 15HD RS ... 1-2 Twisted Pair (TP) Cable Advantages Transmission distance ..1-4 Chapter Two • Installation and Operation Setting the Transmitter Sync Jumpers(Component Video) ...

  • Page 5: Chapter One • Introduction

    Table of Contents, cont’d MTP 4T 15HD RS Chapter One Introduction About.the.MTP.4T.15HD.RS Twisted.Pair.(TP).Cable.Advantages 68-1398-01.Rev. A 11.07 All trademarks mentioned in this manual are the properties of their respective owners. MTP 4T 15HD RS • Table of Contents...

  • Page 6: About The Mtp 4T 15Hd Rs

    Introduction Do not connect this device to a computer data or telecommunications network. About the MTP 4T 15HD RS The Extron MTP 4T 15HD RS consists of four MTP T 15HD RS transmitters in a single enclosure. This set of transmitters and the Extron MTP RL 15HD RS and MTP RL 15HD RS SEQ receivers provide a means to distribute VGA or other high resolution video and RS-232 serial communications across long distances.

  • Page 7: Twisted Pair (Tp) Cable Advantages

    Introduction, cont’d Twisted Pair (TP) Cable Advantages Twisted pair cable is much smaller, lighter, more flexible, and less expensive than coaxial cable. These TP products make cable runs simpler and less cumbersome. Termination of the cable with RJ-45 connectors is simple, quick, and economical. Transmission distance The maximum distance is determined by the frequency and resolution of the signal that is input to the transmitter.
  • Page 8 Introduction, cont’d MTP 4T 15HD RS Chapter Two Installation and Operation Setting.the.Transmitter.Sync.Jumpers.(Component.Video) Installation Connections.and.Settings Front.Panel.Controls.and.Indicators Skew.Delay.Compensation MTP 4T 15HD RS • Introduction...

  • Page 9: Setting The Transmitter Sync Jumpers(Component Video)

    Installation and Operation Setting the Transmitter Sync Jumpers (Component Video) By default, each transmitter in the MTP 4T 15HD RS is configured to send bi-level (normal) sync. For HDTV/component video applications, the transmitter can be configured to send tri-level sync as follows: If applicable, disconnect all power and other cables, remove the transmitter from its installation location, and remove any previously installed mounting brackets.

  • Page 10: Installation Instructions

    Installation and Operation, cont’d Reliable earthing (grounding) — Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuit (such as the use of power strips). Installation instructions Mount the MTP 4T 15HD RS in a rack as follows: If feet were installed on the bottom of the transmitter assembly, remove them.

  • Page 11: Tp Cable Termination

    Installation and Operation, cont’d Monitor connector — Connect a video monitor to this 15-pin HD connector for buffered, high resolution video loop through. RS-232 connector — Connect a serial communications device to this 3.5 mm, 3-pole captive screw connector for bidirectional RS-232 communication. Wire the connector as shown in figure 2-4. Connected RS-232 Device Pins Receive...

  • Page 12: Receiver Considerations

    Installation and Operation, cont’d Receiver considerations Each transmitter in the assembly requires a separate receiver. The receivers' buffered outputs do not provide pre- peaking control. The total recommended distance for an entire daisy chain is the same as for a single transmitter and receiver. The transmitter's Pre-Peak switch has the same affect on the recommended transmission distance for a daisy chain as for a single transmitter and receiver. Up to 8 receivers can be connected in series to a transmitter using the receivers' Buffered Output connectors, provided that the total distance from the transmitter’s TP output to the last receiver in the chain does not exceed the recommended distance for the resolution being used. See the recommended transmission ranges in the table on page 1-4. The recommendations in the table apply equally for a single transmitter and receiver and for a transmission daisy chain. For example, the maximum suggested range for 1024 x 768 video is 300’ with Pre-Peak off and 500’ with Pre-Peak on for either one transmitter and one receiver or a transmitter and three daisy-chained receivers. For daisy-chained units, the first receiver in the chain must be at least 100’ from the transmitter when the Pre- Peak switch is on. For daisy-chained units, any receiver in the chain closer than 350’ may experience some form of over-peaking when the Pre-Peak switch is on. If a receiver is the last receiver in a daisy chain, its end unit DIP switch setting needs to be changed. Refer to the MTP 15HD RS Series manual. MTP 4T 15HD RS •...

  • Page 13: Specifications

    Installation and Operation, cont’d MTP 4T 15HD RS • Installation and Operation 2-10 MTP 4T 15HD RS A ppendix A Reference Information Specifications Part.Numbers...

  • Page 14: Specifications

    Reference Information Specifications Video Gain ... Unity Number/signal type ... 4 sets of proprietary analog signals Connectors ... 4 female RJ-45 Video input and loop through — per transmitter Number/signal type ... 1 analog RGBHV, RGBS, RGsB, RsGsBs, component video (with bi-level or tri-level sync), S-video, or composite video 1 buffered RGBHV, RGBS, RGsB, RsGsBs local monitor loop through...

  • Page 15: Part Numbers

    Reference Information, cont’d Listings... UL, CUL Compliances ... CE, FCC Class A, VCCI, AS/NZS, ICES MTBF ... 30,000 hours Warranty ... 3 years parts and labor All nominal levels are at ±10%. Specifications are subject to change without notice. Part Numbers MTP transmitter and receivers A complete transmission system requires one of the four transmitters built into the MTP 4T 15HD RS and at least one MTP receiver. Transmitter assembly MTP 4T 15HD RS transmitter assembly Compatible receivers RL 15HD RS receiver MTP RL 15HD RS SEQ receiver...
  • Page 16 Reference Information, cont’d MTP 4T 15HD RS • Reference Information...
