Introduction
About the P/2 DA2 WM/EC and P/2 DA2
WM/EC AAP
The P/2 DA2 WM/EC and P/2 DA2 WM/EC AAP are a one
input, two output, high resolution VGA/XGA distribution
amplifier with audio. With a video bandwidth of 300 MHz, this
distribution amplifier is compatible with VGA, SVGA, VESA,
XGA, and SXGA graphics cards, monitors, projectors, and LCD
panels.
For audio, the P/2 DA2 WM/EC features a 3.5 mm female jack
for input and a 3.5 mm captive screw connector for balanced or
unbalanced output.
The P/2 DA2 WM is the wallmount version and the P/2 DA2
EC is the Euro Channel version. The P/2 DA2 WM AAP and
the P/2 DA2 EC AAP are the same base products, but with
AAP faceplates added. These plates are a convenient method of
providing various connectors for most audio and video
applications.
Features
2-color power/signal LED — When the interface is On, the
power/signal LED will light amber. When the
interface is On and a signal is present, the LED will
light green.
Gain/peak control— Compensates for signal degradation
caused by long cable lengths.
Stereo audio — Front panel audio input jack and a 3.5 mm
captive screw output connector on the rear panel.
Buffered local monitor output — 15-pin HD female
connector
Computer video input — 15-pin HD female connector
Wall mountable (WM model) — Self-contained enclosure
provides for convenient wall mounting.
Euro Channel mountable (EC model) — This model
mounts easily in the Euro Channel raceway
Optional Architectural Adapter Plates — The P/2 DA2
WM may be user-configured with up to 4
Architectural Adapter Plates (3 for the EC version).
These adapter plates provide a selection of pass-
through signal connectors for various audio and
video requirements.
1-2
P/2 DA2 WM/EC Introduction

P/2 DA2 WM/EC

2
Chapter Two
Controls and Installation
Installing the P/2 DA2 WM/EC
P/2 DA2 WM/EC Introduction
Front and Rear Panels
