Maintenance

■ Cleaning the cabinet
Periodically wipe the cabinet with a soft cloth and a diluted
soap solution, then with a dry cloth.

Specifications

As part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for
product improvement without prior notice. The performance specification figures indicated are nominal values of
production units. There may be some deviations from these values in individual units.
■ General
Power source
AC 120 ~ 60 Hz
Power
Power on: 22 W
consumption
Speaker
1-way speaker system
Speaker: 2-1/2" (6.5 cm)
Speaker
50 W/channel
maximum input
power
Speaker rated
25 W/channel
input power
Dimensions
Width: 18 - 11/16" (475 mm)
Height: 7 - 1/2" (191 mm)
Depth: 3 - 1/4" (83 mm)
Weight
5.5 lbs. (2.5 kg)
■ Amplifier
Output power
RMS: Total 50 W (25 W per channel
FTC: 22 W minimum RMS per
Output terminals Headphones: 16 ohms
(recommended: 32 ohms)
Input terminals
Audio In (audio signal):
500 mV/47 k ohms
■ CD player
Type
Single disc multi-play compact disc
player
Signal readout
Non-contact, 3-beam
semiconductor laser pickup
D/A converter
Multi bit D/A converter
Frequency
20 - 20,000 Hz
response
Dynamic range
90 dB (1 kHz)
into 6 ohms at 1 kHz, 10%
T.H.D.)
channel into 6 ohms from
100 Hz to 20 kHz, 10% T.H.D.
Caution:
● Do not use chemicals for cleaning (gasoline, paint
thinner, etc.). It may damage the cabinet.
● Do not apply oil to the inside of the unit. It may cause
malfunctions.
■ USB (MP3 / WMA)
USB host interface ● Complies with USB 1.1 (Full
Support file
Bitrate support
Other
File system
support
■ Tuner
Frequency range
Preset
E-15
Speed)/2.0 Mass Storage
Class.
● Support Bulk only and CBI
protocol.
● MPEG 1 Layer 3
● WMA (Non DRM)
● MP3 (32 ~ 320 kbps)
● WMA (64 ~ 160 kbps)
● Maximum total number of
MP3/WMA files is 65025.
● Maximum total number of
folders is 999 INCLUSIVE of
root directory.
● The ID3TAG information
supported are TITLE, ARTIST
and ALBUM only.
● Supports ID3TAG version 1
and version 2.
● Support USB devices with
Microsoft Windows/DOS/FAT
12/FAT 16/ FAT 32.
● 2 kbyte block length for sector.
FM: 87.5 - 108 MHz
AM: 530 - 1,710 kHz
40 (FM and AM station)
