Timer and sleep operation (Remote
control only) (continued)

■ Sleep operation

The radio, compact disc, iPod, USB, Audio In can all be
turned off automatically.
1
Play back the desired sound source.
2
Press the SLEEP button.
3
Within 5 seconds, press the Numeric button to set the
time. (1 minute ~ 99 minutes)
4
"SLEEP" will appear.
5
The unit will enter the power stand-by mode
automatically after the preset time has elapsed. The
volume will be turned down 1 minute before the sleep
operation finishes.
To confirm the remaining sleep time:
While "SLEEP" is indicated, press the SLEEP button.
To cancel the sleep operation:
Press the POWER ON/STAND-BY button while "SLEEP"
is indicated. To cancel the sleep operation without setting
the unit to the stand-by mode, proceed as follows.
1
While "SLEEP" is indicated, press the SLEEP button.
2
Within 5 seconds, press the "0" button twice until
"SLEEP 00" appears.
■ To use timer and sleep operation together
Sleep and timer playback:
For example, you can fall asleep listening to the radio and
wake up to CD in the next morning.
1
Set the sleep time (see above, steps 1 - 5).
2
While the sleep timer is set, set the timer playback
(steps 2 - 9, page 12).
Timer playback
Sleep timer
setting
setting
1-99 minutes
Sleep operation will
automatically stop

Enhancing your system

The connection cord is not included. Purchase a
commercially available cord as shown below.
Portable audio
player, etc.
End
time
Desired time
Timer playback
start time
Audio cord (sold
separately)
E-13
Enhancing your system (continued)
■ Listening to the playback sounds of
portable audio player, etc.
1
Use a connection cord to connect the portable audio
player etc. to the AUDIO IN jack. When using video
equipment, connect the audio output to this unit and the
video output to a television.
2
Press the POWER ON/STAND-BY button to turn the power on.
3
Press the AUDIO IN button on the remote control or
FUNCTION button repeatedly on main unit to select
AUDIO IN function.
4
Play the connected equipment. If volume level of the
connected device is too high, sound distortion may
occur. Should this happen, lower the volume of the
connected device. If volume level is too low, increase the
volume of the connected device.
Note:
To prevent noise interference, place the unit away from the television.
■ Headphones
● Do not turn the volume on to full at switch on and listen to
music at moderate levels. Excessive sound pressure from
earphones and headphones can cause hearing loss.
● Be sure your headphone has a 1/8" (3.5 mm) diameter plug
and impedance between 16 and 50 ohms. The recommended
impedance is 32 ohms.
● Before plugging in or unplugging the headphone, reduce the
volume.
● Plugging in the headphone disconnects the speakers
automatically. Adjust the volume using the VOLUME control.

Troublshooting chart

Many potential problems can be resolved by the owner without
calling a service technician.
If something is wrong with this product, check the following before
calling your authorised SHARP dealer or service centre.
■ General
Symptom
● The clock is not set to
the correct time.
● When a button is
pressed, the unit does
not respond.
● No sound is heard.
■ CD player
Symptom
● Playback does not
start.
● Playback stops in
the middle or is not
performed properly.
● Playback sounds are
skipped, or stopped
in the middle of a
track.
Possible cause
● Did a power failure occur?
Reset the clock. (Refer page
11)
● Set the unit to the power stand-
by mode and then turn it back
on.
● If the unit still malfunctions,
reset it. (Refer page 14)
● Is the volume level set to "Min"?
● Are the headphones
connected?
Possible cause
● Is the disc loaded face
down?
● Does the disc satisfy the
standards?
● Is the disc distorted or
scratched?
● Is the unit located near
excessive vibrations?
● Is the disc very dirty?
● Has condensation formed
inside the unit?
