The GUI consists of the following main elements (see
The "Navigation Bar" on the left edge presents you with a menu listing giving access to the various configura-
•
tion and status pages of the SmartNode.
At the top of the page you see the "Current System Path" which displays the location and element currently
•
presented in the main area.
The rest of the page displays the configuration and status information for the different features of
•
the SmartNode.
Navigation
bar
IMPORTANT
6
Configuration and status tabs
Figure 6.
During the whole configuration process, all your changes are only applied—that is,
saved in volatile memory (RAM). To store the settings in non-volatile memory (i.e.
make them survive power failure or manual reload), return to the home page and
press the Save Current Configuration button.
figure 6):
Main GUI elements
Current
system path
SmartWare GUI Quick Start Guide
