Settings for Pulse Width Trigger

Pulse trigger occurs according to the width of pulse. The abnormal signals can be
detected through setting up the pulse width condition.
Figure 2- 43 Table 2- 21 The Pulse Trigger menu (page 1/2)
Menu
Source
When
Settings
© 2008 RIGOL Technologies, Inc.
Settings
CH1
CH2
EXT
D15-D0
+Pulse width
(
less than)
(+Pulse width
more than)
(+Pulse width
equal to)
(-Pulse width
less than)
(-Pulse width
more than)
(-Pulse width
equal to)
<Width>
User's Guide for DS1000E, DS1000D Series
Comments
Selects CH1 as trigger signal
Select CH2 as trigger signal
Select EXT TRIG as trigger signal
Select a digital
D15-D0 as trigger source( Only
for DS1000D series)
To select pulse condition
Set required pulse width
RIGOL
channel in
2-39
