Settings for Edge Trigger

An edge trigger determines whether the oscilloscope finds the trigger point on the
rising or the falling edge of a signal. Select Edge trigger Mode to trigger on Rising
edge, falling edge or rising & falling edge.
Figure 2- 42 Table 2- 20 The Edge Trigger menu
2-38
Menu Settings
CH1
CH2
EXT
Source
AC Line
D15-D0
Rising
Falling
Slope
Rising &
Falling
Auto
Sweep Normal
Single
Set up
User's Guide for DS1000E, DS1000D Series
Comments
Select CH1 as trigger signal
Select CH2 as trigger signal
Select EXT TRIG as trigger signal
Select power line as trigger signal
Select a digital channel in D15-D0 as
trigger source (for DS1000D series)
Trigger on rising edge
Trigger on falling edge
Trigger on both ring & falling edge
Acquire waveform
occurred
Acquire waveform when trigger occurred.
When trigger
waveform then stop
To go to Set Up menu, see table 2-38
© 2008 RIGOL Technologies, Inc.
even no trigger
occurs, acquire one
