1.2.9 Cooling and mechanical construction

TM
The Genesys series is cooled by internal fans. At the installation, care must be taken to allow free
airflow into the power supply via the front panel and out of the power supply via the rear panel. The
TM
Genesys power supplies have a compact and lightweight package, which allows easy installation
and space saving in the application equipment.
Observe all torque guidelines within this manual. Over-torquing may damage
Unit or accessories. Such damage is not covered under manufacturers warranty.

1.3 ACCESSORIES

1.3.1 Included Accessories

The following accessories are delivered with the power supply:
1.3.1.1 Serial Link Cable
Serial link cable for linking power supplies by RS-485 communication.GEN/RJ45.
Cable description: 0.5m Length, shielded, RJ-45 type plugs, eight (8) contacts (P/N 15-507-201)
1.3.1.2 Hardware (delivered with power supply)
• Strain Relief for AC Cord
• Output terminal Shield
• DB25 Programming Plug kit (AMP 749809-9)
• 750W Only - Power Cord
• 1500W Only - No Power Cord is Provided.
• 1500W Only Input Connector plug kit (Phoenix Contact, plug: IMC 1,5/7-ST-3,81, Header: IMC 1, 5/7-G-
3,81))
1.3.2 Optional Communication Cables (See Para. 7.5)
• RS-232 Cables to connect GEN to Serial Port on PC
GEN to PC (DB9)
GEN to PC (DB25)
• RS-485 Cable to connect GEN to Serial Port on PC
GEN to PC (DB9)

1.3.3 AC cables

AC Cables are provided with 750W Model only, according to suffix in Model Number.
TM
For 750W Genesys
Part No. Market
NC301 USA
(GEN/U)
NC302 Europe
(GEN/E)
NC303 General
(GEN/O)
NC305 Japan
(GEN/J)
NC306 UK
(GEN/GB)
TM
For 1500W Genesys power supplies the recommended AC cable (customer supplied) is:
CAUTION
power supplies:
Description
13A 125V, unshielded, 2m typical length, with IEC320 connector on one end and NEMA-
5-15P connector on the other end.
10A 250V, unshielded, 2m typical length, with IEC320 connector on one end and INT'L 7
standard VII, dual earthing.
10A 250V, unshielded, 2m typical length, with IEC320 connector on one end and unter-
minated stripped wires on the other end. Use the cable only with plug approved by the
national safety standards of the country of usage.
13A 125V, unshielded, 2m typical length, with IEC320 connector on one end and Japan
type plug on the other end.
10A 250V unshielded, 2m typical length, with IEC320 connector on one end and UK type
plug on the other end.
25A 250V, 3x12AWG, outer diameter: 9-11mm, rated 60°C min., 3m max. length. Add a
non-locking plug approved by the national safety standards of the country of usage.
GEN 232/9 P/N 15-507-203
GEN 232/25 P/N 15-507-204
GEN/485-9 P/N 15-507-202)
8
83-507-013 Rev. D
