  • Page 1 E-9722R Server USERGUIDE ®...

  • Page 3: Table Of Contents

    Gateway Systems Manager ........17...
  • Page 4 Telephone support ..........62 Before calling Gateway Customer Care ......62 Telephone support .
  • Page 5 Monitor ........... . 76 Power .
  • Page 6 Contents...

  • Page 7: Chapter 1: Checking Out Your Gateway Server

    CHAPTER Checking Out Your Gateway Server • Front • Back • Back • Interior • System board • Hot-swap backplanes • Getting Help...

  • Page 8: Front

    CHAPTER 1: Checking Out Your Gateway Server Front Hard drive SMIL module Hard drives (as many as 12) tray LEDs Optical drive bay (optional) Control panel Control panel Reset button VGA port USB ports (2) ID button NIC status ID LED...

  • Page 9: Back

    Back PS/2 Keyboard PS/2 Mouse VGA port NIC ports (4) port port Power supply Server management USB ports (2) Serial port port ID LED AC power connector...

  • Page 10: Interior

    CHAPTER 1: Checking Out Your Gateway Server Interior Feature Feature System board Front panel Fan duct Front panel VGA connector System fans SMIL module (optional) SATA II/SAS backplane Slimline DVD/CD-RW combo drive or DVD-RW drive Hard drive bays Riser card assembly...

  • Page 11: System Board

    System board Connectors Feature Feature PCI-X/PCI-E expansion slot (J41) DIMM socket group for processor 0 (J24, J125, J27, J28) PCI-E expansion slot (J35) Processor 0 (CPU0) socket DIMM socket group for processor 1 (J33, J32, IDE connector (J36) J31, J30)
  • Page 12 CHAPTER 1: Checking Out Your Gateway Server Feature Feature Serial port (J12) Main power connector (J48) PS/2 keyboard and mouse ports (J10) Internal USB port for USB floppy (J59) Rear dual USB Port (J6) Power supply I C connector (J55)

  • Page 13: Hot-Swap Backplanes

    Hot-swap backplanes SATA II/SAS backplane Feature Feature SATA II/SAS hard drive connector 0 SATA II/SAS hard drive connector 9 SATA II/SAS hard drive connector 1 SATA II/SAS hard drive connector 10 SATA II/SAS hard drive connector 2 SATA II/SAS hard drive connector 11...

  • Page 14: Led Information

    CHAPTER 1: Checking Out Your Gateway Server LED information See the following table for a description of this server’s LEDs and the information they provide: LED Name Function Location Color Description Aid in server Control panel and Yellow On = Server identification...

  • Page 15: Getting Help

    For instructions, see Using Your Server Companion DVD. Gateway Web site Gateway provides a variety of information on its Web site to help you use your server. Visit the Gateway Web site at support.gateway.com for: •...
  • Page 16 CHAPTER 1: Checking Out Your Gateway Server...

  • Page 17: Chapter 2: Setting Up Your Server

    CHAPTER Setting Up Your Server • Setting up the hardware • Protecting from power source problems • Starting your server • Setting up the operating system • Initial hardware settings...

  • Page 18: Setting Up The Hardware

    CHAPTER 2: Setting Up Your Server Setting up the hardware To make sure that your working environment is safe: • Use a clean, dry, flat, stable surface for your server. Allow at least 6 inches at the back of the server for cabling and air circulation. •...

  • Page 19: Starting Your Server

    A UPS uses a battery to keep your server running temporarily during a power failure and lets you save your work and shut down your server. You cannot run your server for an extended period of time while using only the UPS. To buy a UPS, visit accessories.gateway.com. Starting your server Before you start your server for the first time: •...

  • Page 20: Turning Off Your Server

    Press the reset button to reset the server. Setting up the operating system If you ordered your server with the operating system already installed by Gateway, in most cases it is completely installed and the basic settings are already configured. The Windows Small Business Server operating system may require additional installation, depending on the version you ordered.

  • Page 21: Chapter 3: Maintaining Your Server

    CHAPTER Maintaining Your Server • Caring for your server • Preparing for system recovery • System administration • Identifying your server • Updating the baseboard management controller firmware • Using your Server Companion DVD...

  • Page 22: Caring For Your Server

    CHAPTER 3: Maintaining Your Server Caring for your server To extend the life of your server: • Be careful not to bump or drop your server. • When transporting your server, we recommend that you put it in the original packaging materials.

  • Page 23: Preparing For System Recovery

    To record your BIOS configuration: Print the appendix for “BIOS Settings” on page Restart your server, then press F2 when the Gateway logo screen appears during startup. The BIOS Setup utility opens. Record the BIOS settings on your printout. System administration...

  • Page 24: Server Security

    BIOS Setup utility. To set the BIOS security passwords: Restart your server, then press F2 when the Gateway logo screen appears during startup. The BIOS Setup utility opens. Select the Security menu.

  • Page 25: Identifying Your Server

    • Fault resilient booting (the extent depends on the option selected) You should update the BMC firmware when Gateway Customer Care has instructed you to update To update the BMC firmware: Download the BMC firmware zip file from support.gateway.com.

  • Page 26: Using Your Server Companion Dvd

    The SCDVD’s Gateway Application and Driver Recovery utility works only in Windows operating systems. To install drivers and programs at the server: Insert the SCDVD into your server’s DVD drive. The Gateway Application and Driver Recovery window opens. - OR - If the window does not open automatically, run the file Runmenu.exe on the DVD.

  • Page 27: Booting From The Server Companion Dvd

    With your server turned on, insert the SCDVD into the DVD drive. Restart your server. A message appears asking you to select an option. Press any key to boot from the DVD. The Gateway Options Main Menu appears. Follow any on-screen instructions.
  • Page 28 CHAPTER 3: Maintaining Your Server...

  • Page 29: Chapter 4: Installing Components

    CHAPTER Installing Components • Preparing to install components • Preventing static electricity discharge • Opening the server case • Closing the server case • Installing and removing drives • Installing memory • Installing and removing PCI expansion cards • Replacing system fans •...

  • Page 30: Preparing To Install Components

    Is near a grounded outlet so you can test your server after installation. • Is near a telephone (in case you need help from Gateway Customer Care). The telephone must be directly connected to a telephone jack and cannot be connected to your server.

  • Page 31: Opening The Server Case

    • Avoid static-causing surfaces such as carpeted floors, plastic, and packing foam. • Avoid working on the server when your work area is extremely humid. • Remove components from their antistatic bags only when you are ready to use them. Do not lay components on the outside of antistatic bags because only the inside of the bags provide electrostatic protection.
  • Page 32 CHAPTER 4: Installing Components Remove the screw (1) at the front of the top cover, then press and hold the release button (2). Caution For correct cooling and air flow, always reinstall the top covers before you turn on the server. Operating the server without the covers in place will cause the server to overheat.

  • Page 33: Closing The Server Case

    Closing the server case To close the server case: Make sure that all of the internal cables are arranged inside the case so they will not be pinched when you close the case. Place the front top cover on the server, then slide it forward until it clicks into place.

  • Page 34: Installing And Removing Drives

    CHAPTER 4: Installing Components Installing and removing drives Your server’s basic configuration includes one optical drive and as many as twelve SAS/SATA hot-swap hard drives. As you prepare to install drives, remember: • Before you install a drive, see the drive’s documentation for information on configuring the drive, setting drive jumpers, and attaching cables.

  • Page 35: Removing And Installing A Hard Drive

    Reconnect all power cords and peripheral device cables, then turn on the server. Removing and installing a hard drive Important Gateway tests and verifies the operation and compatibility of the drives it sells. Especially in a hot-swap or mission-critical environment, additional or replacement drives must conform to Gateway standards.
  • Page 36 CHAPTER 4: Installing Components To remove and install a hot-swap hard drive: Caution Before you remove a failed drive, use the appropriate software and utilities installed on the server to stop all activity on the failed drive. Instructions for using the software are provided by the software manufacturer.

  • Page 37: Filling Empty Drive Bays

    Filling empty drive bays Empty drive bays in the server must be filled by empty drive trays. With the bezel removed, install the appropriate carrier, then replace the bezel by snapping it into place on the front of the server. Empty drive carriers for unused drive bays are included with your server.
  • Page 38 CHAPTER 4: Installing Components If you install two processors, refer to the following table: DIMM Processor DIMMA0 DIMMB0 DIMMA1 DIMMB1 Total Memory Processor 0 512 MB 512 MB 2 GB Processor 1 512 MB 512 MB Processor 0 1 GB 1 GB 4 GB Processor 1...
  • Page 39 If you install four processors, refer to the following table: DIMM Processor DIMMA0 DIMMB0 DIMMA1 DIMMB1 Total Memory Processor 0 512 MB 512 MB 4 GB Processor 1 512 MB 512 MB Processor 2 512 MB 512 MB Processor 3...

  • Page 40: Installing And Removing Pci Expansion Cards

    CHAPTER 4: Installing Components To install or replace memory: Follow the instructions in “Preventing static electricity discharge” on page 24. Make sure that you turn off the server, then unplug the power cord(s) and all other cables connected to the server. Follow the instructions in “Opening the server case”...
  • Page 41 If you are replacing a card, disconnect any cables that are attached to the old card. Push the riser card locking tabs (1) in the directions shown in the illustration. Lift the riser card assembly out of the chassis (2) and place it on a clean, static-free surface.
  • Page 42 CHAPTER 4: Installing Components Press down and open the release lever (4) and flip open the card guide tab (5). Remove the expansion card (6). If you are not replacing the card, install a slot cover (7) on the back of the riser card assembly. Caution Do not touch the contacts on the bottom part of the expansion card.
  • Page 43 Press the tab (8) holding the riser card in the riser card assembly, then push the riser card in the direction shown (9) to unlock and remove it from the standoffs. Standoff Insert the new riser card into the riser card assembly, then push it toward the back of the assembly.

  • Page 44: Replacing System Fans

    CHAPTER 4: Installing Components Replacing system fans This server contains five system fan groups seated in the fan cage. The fan cage is located inside the chassis and can hold as many as five groups of hot-swappable fans. When replacing a fan, it is not necessary to power off the server.
  • Page 45 To replace the system fans and the fan cage: Follow the instructions in “Preventing static electricity discharge” on page Follow the instructions in “Opening the server case” on page 25, but do not turn off the server or unplug the power cord(s) or other cables.
  • Page 46 CHAPTER 4: Installing Components Lift one side of the fan cage (2) and disengage the retention tab (3), then disconnect the fan power and fan tach cables from the system board and remove the fan cage from the chassis. Insert the fans into the new fan cage. Important Make sure that the arrows on top of the fans indicating airflow point to the back of the chassis.

  • Page 47: Replacing Or Adding A Processor

    Replacing or adding a processor Warning Processors and heat sinks may be hot if the computer has been running. Before replacing a processor or heat sink, let them cool for several minutes. Caution A heat sink must be installed on the processor. Installing a processor without a heat sink could damage the processor.
  • Page 48 CHAPTER 4: Installing Components Unlock the load lever (1) and lift it up, then open the load plate (2) to release the processor. Lift the processor (3) out of the socket and place it in a static-free bag or case for storage. Insert the new processor into the socket, making sure that the gold triangle on the corner is situated as shown in the following illustration.

  • Page 49: Replacing A Power Supply Module

    Caution The heatsink has Thermal Interface Material (TIM) located on the bottom of it. Use caution when you unpack the heatsink so you do not damage the TIM. If you are reusing the original heatsink, make sure that the TIM on the bottom of the heatsink is not damaged.

  • Page 50: Replacing The Power Distribution Module

    CHAPTER 4: Installing Components Press the retaining clip (1) on the power supply to the left to release the power supply module (2) from the chassis. Using the handle, pull the power supply module straight out of the server. It may take considerable force to remove.
  • Page 51 Loosen the thumbscrew (1), then lift the distribution module slightly and move it toward the front of the case (2) to release it from the three locking tabs. Lift the power distribution board (3) out of the chassis. Insert the new power distribution board into the chassis, then move it toward the back of the chassis to engage the three locking tabs.

  • Page 52: Replacing The Hot-Swap Backplane

    CHAPTER 4: Installing Components Replacing the hot-swap backplane Caution The hot-swap backplane is not hot-swappable. Before removing or replacing the backplane, you must first turn off the server and all peripheral devices attached to the server, and remove the AC power cord(s) from the power supply or wall outlet. To replace the hot-swap backplane: Follow the instructions in “Preventing static electricity discharge”...

  • Page 53: Installing And Removing An Optional Mezzanine Board

    Holding the new backplane by the edges only, align it with the locking tabs on the backplane bracket, then place it on the locking tabs (1) and slide it to the right until it click into place. Insert the backplane assembly into the chassis (2), then press down on the assembly until the locking tabs on the chassis engage the holes on the right and left sides of the bracket.
  • Page 54 CHAPTER 4: Installing Components To install an optional mezzanine board: Follow the instructions in “Preventing static electricity discharge” on page 24. Make sure that you turn off the server, then unplug the power cord(s) and all other cables connected to the server. Follow the instructions in “Opening the server case”...

  • Page 55: Replacing The Cmos Battery

    Follow the instructions in “Closing the server case” on page Turn on your server, then press F2 when the Gateway logo screen appears during startup. The BIOS Setup utility opens. Restore any BIOS settings that you wrote down in Step Save all your settings and close the BIOS Setup utility.

  • Page 56: Replacing The Control Panel

    CHAPTER 4: Installing Components Replacing the control panel Caution Your server must be operated with a control panel in place. To replace the control panel adapter card: Follow the instructions in “Preventing static electricity discharge” on page 24. Make sure that you turn off the server, then unplug the power cord(s) and all other cables connected to the server.
  • Page 57 Follow the instructions in “Closing the server case” on page Turn on your server, then press F2 when the Gateway logo screen appears during startup. The BIOS Setup utility opens. Check BIOS settings to make sure that they detect the server’s new hardware, then save your changes (if any) and close the BIOS Setup utility.
  • Page 58 CHAPTER 4: Installing Components...

  • Page 59: Chapter 5: Using The Bios Setup Utility

    CHAPTER Using the BIOS Setup Utility • Opening the BIOS Setup utility • Updating the BIOS • Recovering the BIOS • Resetting the BIOS • Updating and recovering the BMC...

  • Page 60: Opening The Bios Setup Utility

    To open the BIOS Setup utility: Restart your server, then press F2 when the Gateway logo screen appears during startup. The BIOS Setup utility opens. When you select menu items, the Item Specific Help box on the right side of the screen displays specific information about the selection.

  • Page 61: Recovering The Bios

    Recovering the BIOS If you encounter a problem while you are updating the BIOS, such as a power outage, the BIOS update may not be successful. If the system continues to try to boot from the new, corrupted BIOS, you can manually recover the old BIOS so you can try another update.

  • Page 62: Resetting The Bios

    Print the appendix for “BIOS Settings” on page 87 in this guide. Restart your server, then press F2 when the Gateway logo screen appears during startup. The BIOS Setup utility opens. Record any custom BIOS settings on your printout. Press the reset button and hold it down for four seconds or more, then continuing to hold down the reset button, press the power button.

  • Page 63: Resetting Bios Passwords

    Reconnect the power cords and turn on the server. The BIOS is reset. Turn off the server, then disconnect the power cords and all other cables connected to the server. Follow the instructions in “Opening the server case” on page Place the jumper back onto pins 1-2.

  • Page 64: Updating And Recovering The Bmc

    Updating the BMC firmware To update the BMC firmware: Download the BMC firmware zip file from support.gateway.com. Read the release notes for the firmware update. Follow the instructions on the Web site or in the readme.txt file in the downloaded zip file to update the firmware.
  • Page 65 Follow the instructions in “Closing the server case” on page Plug in the AC power cords and turn on the server for normal use.
  • Page 66 CHAPTER 5: Using the BIOS Setup Utility...

  • Page 67: Chapter 6 Troubleshooting

    CHAPTER Troubleshooting • Telephone support • Tutoring and training • Safety guidelines • Error messages • Troubleshooting...

  • Page 68: Telephone Support

    • Consider using Gateway’s online technical support. Gateway’s Web site has FAQs, tips, and other technical help. You can also use the Web site to e-mail Customer Care. For more information, visit Gateway’s Customer Care Web site at support.gateway.com.

  • Page 69: Tutoring And Training

    Tutoring and training Gateway's Customer Care professionals cannot provide hardware and software training. Instead, Gateway recommends the following training resources. Resource Service description For more information Gateway Learning A variety of courses and tutorials are available on www.gateway.com/training Libraries CD.
  • Page 70 CHAPTER 6: Troubleshooting Drive Not Ready The BIOS was unable to access the drive because it indicated it was not ready for data transfer. This is often reported by drives when no media is present. A: Drive Error The BIOS attempted to configure the A: drive during POST, but was unable to correctly configure the device.
  • Page 71 S.M.A.R.T. Capable but Command Failed The BIOS tried to send a S.M.A.R.T. message to a hard disk, but the command transaction failed. This message can be reported by an ATAPI device using the S.M.A.R.T. error reporting standard. S.M.A.R.T. failure messages may indicate the need to replace the hard disk.
  • Page 72 CHAPTER 6: Troubleshooting PCI I/O conflict A PCI adapter generated an I/O resource conflict when configured by BIOS POST. PCI ROM conflict A PCI adapter generated an I/O resource conflict when configured by BIOS POST. PCI IRQ conflict A PCI adapter generated an I/O resource conflict when configured by BIOS POST. PCI IRQ routing table error BIOS POST (DIM code) found a PCI device in the system but was unable to figure out how to route an IRQ to the device.

  • Page 73: Troubleshooting

    • If an error message appears on the screen, write down the exact message before calling Gateway Customer Care. For instructions, see “Telephone support” on page • Restart your server, then open the BIOS Setup utility by pressing and holding F2 while your server restarts.
  • Page 74 CHAPTER 6: Troubleshooting Beeps Description Troubleshooting steps Memory refresh timer error Reseat the memory modules or replace with modules you know are good. Parity error in the first 64 KB of memory. Same as for 1 beep. Base memory read/write test error Same as for 1 beep.

  • Page 75: Diagnostic Leds

    Diagnostic LEDs This system board provides a set of eight diagnostic (Port 80) LEDs. If you are troubleshooting your system, these LEDs can help you determine where errors are taking place. If you are experiencing problems with your server, open the case and check these LEDs (CR22 to CR29) on the system board, then check the tables on the following pages to determine the problem.
  • Page 76 CHAPTER 6: Troubleshooting In determining the code, Off = 0 and On = 1. Based on this, you can determine the corresponding hex code. Then, by checking “POST code checkpoints” on page “Bootblock initialization code checkpoints” on page “Bootblock recovery code checkpoints” on page “DIM code checkpoints”...
  • Page 77 Check Description point Initialize different devices through DIM. “DIM code checkpoints” on page 74 for more information. Initialize different devices. Detects and initializes the video adapter installed in the system that has optional ROMs. Initialize all the output devices.

  • Page 78: Bootblock Initialization Code Checkpoints

    CHAPTER 6: Troubleshooting Check Description point Take care of runtime image preparation for different BIOS modules. Fill the free ® area in F000h segment with 0FFh. Initializes the Microsoft IRQ Routing Table. Prepares the runtime language module. Disables the system configuration display, if needed.
  • Page 79 Check Description point The Runtime module is uncompressed into memory. CPUID information is stored in memory. Store the Uncompressed pointer for future use in PMM. Copying Main BIOS into memory. Leaves all RAM below 1 MB Read-Write, including E000 and F000 shadow areas, but closing SMRAM.

  • Page 80: Bios

    CHAPTER 6: Troubleshooting DIM code checkpoints The Device Initialization Manager (DIM) gets control at various times during BIOS POST to initialize different system buses. The following table describes the main checkpoints where the DIM module is accessed. Checkpoint Description Initialize different buses and perform the following functions: Reset, Detect, and Disable (function 0) —...

  • Page 81: Optical Drive

    Optical drive Your server does not recognize an optical drive • Restart your server, then open the BIOS Setup utility by pressing and holding F2 while your server restarts. Make sure that the IDE controllers are enabled. For more information, see “Using the BIOS Setup Utility”...

  • Page 82: Internet

    CHAPTER 6: Troubleshooting The master boot record is corrupted • In a Windows network operating system, repair the master boot record using FDISK. To repair the master boot record: • At a DOS command prompt, type fdisk/mbr, then press E NTER Internet See also Modem.

  • Page 83: Power

    A horizontal line or wire is visible across the CRT monitor screen The monitor may use thin damper wires, located approximately 1/3 of the way from the upper and lower screen edges, to stabilize the internal aperture grille. These wires are most obvious when the monitor displays a white background.
  • Page 84 CHAPTER 6: Troubleshooting...

  • Page 85: Appendix A Server Specifications

    APPENDIX Server Specifications • System specifications • System board specifications • Environmental specifications • Electronic specifications • Additional specifications...

  • Page 86: System Specifications

    APPENDIX A: Server Specifications System specifications Case size 5.12 × 17.56 × 27.56 inches (13.0 × 44.6 × 70.0 cm) Weight Minimum - 79.37 lbs (36 Kg) (no bezel, power supplies, hard drives, optical drive, fans, cables, and so on) Maximum - 99.21 lbs (45 Kg) (±0.5 Kg) Fans Five dual-rotor, multi-speed system fans...

  • Page 87: Environmental Specifications

    MCP55 and IO55 ■ Four onboard 10/100/1000 network interface ■ Supports teaming, load-balancing, failover, TOE, and jumbo frame ■ ACPI ACPI 2.0b compliance Supports: ■ ■ ■ Environmental specifications The following specifications identify maximum environmental conditions. At no time should the server run under conditions which violate these specifications.

  • Page 88: Interrupts

    APPENDIX A: Server Specifications Address Range (hex) Amount Function 0E0000h to 0EFFFFh 2 MB Extended system BIOS FC000000h to FFFFFFFFh 64 MB PCI memory space Interrupts Important If you disable an IDE controller to free the interrupt for that controller, you must physically unplug the IDE cable from the system board.
  • Page 89 Signal Name +5 V Ground +5 V Ground Power good Stand by +5 V +12 V +12 V +3.3 V +3.3 V -12 V Ground DC_ON (soft on/off) Ground Ground Ground +5 V +5 V +5 V Ground Processor power connector (J1)

  • Page 90: Vga Connector

    APPENDIX A: Server Specifications VGA connector Signal Name Green Blue No connection +5 V +5 V No connection HSYNC (horizontal sync) VSYNC (vertical sync) Serial port connector Signal Name Description Data Carrier Detect RXDATA Receive Data TXDATA Transmit Data Data Terminal Ready Ground Data Set Ready Request To Send...

  • Page 91: Additional Specifications

    Additional specifications For more information about your server, such as memory size, hard drive size, and processor type, visit Gateway’s Support page at support.gateway.com. The Support page also has links to additional Gateway documentation and detailed specifications for your server.
  • Page 92 APPENDIX A: Server Specifications...

  • Page 93: Appendix B: Bios Settings

    APPENDIX BIOS Settings...
  • Page 94 BIOS settings, run the BIOS Setup utility. To view all BIOS settings: Restart your server Press F2 when the Gateway logo screen appears during startup. The BIOS Setup utility opens. Select menus and submenus to display setting information.
  • Page 95 BIOS menu BIOS submenu Setting Value ACPI 2.0 Object Enable Disable Memory Configuration Total Memory Capacity IOMMU Mode AGP Present Disabled 32MB 64MB 128MB 256MB 512MB Memory Hole Remapping Enabled Disabled CS Sparing Enable Enabled Disabled DIMM Information CPU0...
  • Page 96 APPENDIX B: BIOS Settings BIOS menu BIOS submenu Setting Value MCP55 SATA 0 Secondary (auto-detected) Selects IDE Configuration sub-menu. MCP55 SATA 1 Primary (auto-detected) Selects IDE Configuration sub-menu. MCP55 SATA 1 Secondary (auto-detected) Selects IDE Configuration sub-menu. MCP55 SATA 2 Primary (auto-detected) Selects IDE Configuration...
  • Page 97 BIOS menu BIOS submenu Setting Value USB Configuration USB Devices Enabled (List of USB devices detected by BIOS) Legacy USB Support Disabled Enabled Auto USB 2.0 Controller Mode FullSpeed (12 Mbps) HiSpeed (480 Mbps) BIOS EHCI Hand-Off Disabled Enabled...
  • Page 98 APPENDIX B: BIOS Settings BIOS menu BIOS submenu Setting Value Boot Boot Settings Configuration Quick Boot Disabled Enabled Quiet Boot Disabled Enabled Bootup Num-Lock POST Error Pause Disabled Enabled Security Supervisor Password (Installed/Not installed) User Password (Installed/Not installed) Change Supervisor Password (Set or clear Supervisor password) User Access Level...
  • Page 99 BIOS menu BIOS submenu Setting Value Remote Access Disabled Enabled Serial Port Number (Base COM1 address and IRQ) Serial Port Mode 115200 8,n,1 57600 8,n,1 19200 8,n,1 09600 8,n,1 Flow Control None Hardware Software Redirection After BIOS POST Disabled...
  • Page 100 APPENDIX B: BIOS Settings BIOS submenu BIOS 2nd level Setting Value submenu Configuration Primary IDE Master (Below is shown information (All IDE drives) and options appropriate to drive type) Device Device information Vendor Device vendor Size Device size LBA Mode Device LBA mode Block Mode Device block mode...

  • Page 101: Appendix C Legal Information

    APPENDIX Legal Information...

  • Page 102: Important Safety Information

    Gateway system. Your Gateway system is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that the safety instructions marked on the product and in the documentation are followed.

  • Page 103: Regulatory Compliance Statements

    Operation of this equipment in a residential area is likely to cause harmful interference, in which case you will be required to correct the interference at your own expense. Caution Changes or modifications not expressly approved by Gateway could void the FCC compliance and negate your authority to operate the product. Telecommunications per FCC part 68 (applicable to products fitted with USA modems) Your modem complies with Part 68 of the Federal Communications Commission (FCC) rules.
  • Page 104 Laser safety statement All Gateway systems equipped with CD and DVD drives comply with the appropriate safety standards, including IEC 825. The laser devices in these components are classified as “Class 1 Laser Products” under a US Department of Health and Human Services (DHHS) Radiation Performance Standard. Should the unit ever need servicing, contact an authorized service location.

  • Page 105: Environmental Information

    When your electrical or electronic equipment is no longer useful to you, “take it back” to your local or regional waste collection administration for recycling. ■ In some cases, your “end of life” product may be “traded in” for credit towards the purchase of new Gateway equipment. Call Gateway to see if this program is available in your area.
  • Page 106 APPENDIX C: Legal Information...
  • Page 107 Index Numerics opening documentation Gateway Web site checkpoints 5.25-inch drive Server Companion DVD ACPI runtime location bootblock initialization code drive bays location bootblock recovery code drivers accessories DIM code installing safety precautions POST code drives ACPI runtime checkpoints cleaning configuring...
  • Page 108 Gateway Systems Manager uninterruptible power supply hard drive (UPS) heat sink general guidelines power distribution module hot-swap drive recording BIOS configuration replacing memory...
  • Page 109 Customer Care Server Companion DVD resources tips before contacting Server menu BIOS Setup utility telephone support setting up training hardware operating system Gateway Learning Libraries...
  • Page 110 Contents...
  • Page 112 A MAN E-9722R USR R0 02/07...
