5.3

Result Codes

The Command mode provides you with several responses, or "Result Codes", that can aid you in
Command mode operation. These Result Codes are displayed on your video monitor.
You can choose result codes that closely match those of the standard AT command set, or choose
enhanced function result codes that have been used in Multi-Tech modems ("Multi-Tech" responses).
The &Q command selects which result codes will be used.
You can choose to have these Result Codes displayed in either "verbose" (full words) or "terse"
(digits) format. This is controlled by the ATV0 (terse) or ATV1 (verbose) commands. The modem
defaults to verbose format.
AT&Q0 selects Multi-Tech responses with Reliable/LAPM/Compression modifiers. The terse
response code for CONNECT 2400 is 9. AT&Q1 selects Standard AT command set responses. The
terse result code for CONNECT 2400 is 10.
The following tables define the result codes generated by the &Q command (refer to
Result Code Summary).
"Multi-Tech" Result Codes
2834 Series
TERSE
0
1
2
3
4
5*
6
7
8
9*
1432 Series
TERSE
0
1
2
3
4
5*
932 Series
TERSE
0
1
2
3
4
5*
* With MNP error correction on, RELIABLE (or R) is added to these result codes. With LAP-M error
correction on, LAP-M (or L) is added to these result codes. With data compression on,
COMPRESSED (or C) is added. (Note these "Extended" Result Codes are displayed when your
modem is set up to do so with an X1, X2, X3, or X4 command.)
VERBOSE TERSE
OK 11*
CONNECT 12*
RING 13*
NO CARRIER 19*
ERROR 21*
CONNECT 1200 24*
NO DIALTONE 26*
BUSY 28*
NO ANSWER 31*
CONNECT 2400 33*
VERBOSE TERSE
OK 7
CONNECT 8
RING 9*
NO CARRIER 11*
ERROR 12*
CONNECT 1200 13*
VERBOSE TERSE
OK 6
CONNECT 7
RING 8
NO CARRIER 9*
ERROR 11*
CONNECT 1200 12*
Chapter 5 - Command Mode
Appendix G
VERBOSE
CONNECT 4800
CONNECT 9600
CONNECT 14400
CONNECT 19200
CONNECT 21600
CONNECT 24000
CONNECT 26400
CONNECT 28800
CONNECT 31200
CONNECT 33600
VERBOSE
BUSY
NO ANSWER
CONNECT 2400
CONNECT 4800
CONNECT 9600
CONNECT 14400
VERBOSE
NO DIAL TONE
BUSY
NO ANSWER
CONNECT 2400
CONNECT 4800
CONNECT 9600
for
