MultiModemBA User Guide
#11 Internal*/External Clocking
(Synchronous)
#12 Sync/Async Mode*
* Factory Default Setting
DIP Switches #13-14
Note: The modem baud rate command ($MBn) overrides the setting of these speed selection
switches (DIP switches #13 and #14).
2834 Series:
SWITCH CONDITION
#13/#14 UP/UP*
#13/#14 DOWN/UP
#13/#14 UP/DOWN
#13/#14 DOWN/DOWN 9600 bps Operation
1432 Series:
SWITCH CONDITION
#13/#14 UP/UP*
#13/#14 DOWN/UP
#13/#14 UP/DOWN
#13/#14 DOWN/DOWN 2400 bps Operation
932 Series:
SWITCH CONDITION
#13/#14 UP/UP*
#13/#14 DOWN/UP
#13/#14 UP/DOWN
#13/#14 DOWN/DOWN 1200 bps Operation
DIP Switches #15-16
SWITCH CONDITION
#15 UP*
#15 DOWN
#16 UP
#16 DOWN*
*Standard Factory Default Setting
116
UP
DOWN*
UP
DOWN*
EFFECT
28.8 K bps Operation
19.2 K bps Operation
14.4 K bps Operation
EFFECT
14.4 K bps Operation
9600 bps Operation
4800 bps Operation
EFFECT
9600 bps Operation
4800 bps Operation
2400 bps Operation
EFFECT
CD/DSR from Interface
CD/DSR Forced On
Not Used
Not Used
