Multitech MultiModem II BA-Series User Manual page 15

Receiver Sensitivity
All models:
AGC Dynamic Range
All models:
Interface
All models:
Connectors
All models:
Diagnostics
All models:
Indicators
All models:
Controls
All models:
Speaker
All models:
Operating Temperature
All models:
Power Requirements
All models:
Dimensions
All models:
Weight
All models:
Limited Warranty
All models:
-43 dBm under worst case conditions
43 dB
EIA RS-232C/ITU V.24
One DB-25 RS-232C connector; two RJ11 for phone line/telephone
set; power.
Power-on Self Test, Local Analog Loop, Local Digital Loop, Remote
Digital Loop, Back-to-Back Test.
LEDs for Transmit Data, Receive Data, Carrier Detect, Speed
Indicators, Off Hook, Terminal Ready, Error Correction, Fax, and
Error
Toggle switches for Voice/Data with Originate or Answer, Power On/
Off; and DIP Switches for various modem options.
Speaker for call progress monitoring
0° to 50° C (32° to 120° F)
115 Volts AC, 60Hz, 0.3amp (2-prong outlet-mounted transformer)
240V/50Hz optional (International).
6.150" x 9.00" x 1.375"
15.6 cm x 22.9 cm x 3.5 cm
1.6 pounds/0.72 Kg (without transformer)
2.6 pounds/1.18Kg (with transformer)
Five Years
Chapter 1 - Introduction and Description
15
