SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
OWNER'S MANUAL
If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life. Installation and
service must be performed by a qualified installer, service agency or the gas supplier.
Do not store or use gasoline or other Flammable vapours and liquids in the vicinity of
Massachusetts installations (Warning): This product must be installed by a licensed
plumber or gas fitter when installed within the Commonwealth of Massachusetts. Other
Massachusetts code requirements: Flexible connector must not be longer than 36in., a
shut off valve must be installed; only direct vent sealed combustion products are approved
for bedrooms/bathrooms. A carbon monoxide detector is required in all rooms containing
gas fired direct vent appliances.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Open windows/Extinguish any open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch or use any phone
in your building.
• Immediately call your gas supplier from a neighbour's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
permanently located, manufactured (mobile) home, where
This appliance is only for use with the type of gas indicated
on the rating plate. This appliance is not convertible for use
WARNING
FOR YOUR SAFETY
this or any other appliance.
EG40 DV
B Y : S H E R W O O D I N D U S T R I E S L T D
WHAT TO DO IF YOU SMELL GAS
This appliance may be installed in an after market
not prohibited by local codes.
with other gases, unless a certified kit is used.
EG40-070

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EG40-070 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Enviro EG40-070

  • Page 1 This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certified kit is used. WARNING FOR YOUR SAFETY this or any other appliance. EG40-070...
  • Page 2: Safety Precautions

    Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed in accordance with their instructions. Carefully read all the instructions in this manual first. Consult the building authority having jurisdiction to determine the need for a permit prior to commencing the installation.
  • Page 3: Table Of Contents

    Table of Contents Safety Precautions...2 Table of Contents...3 Codes And Approvals...4 Specifications...5 Dimensions...5 Rating Label Location...5 Operating Instructions...6 Lighting Instructions...6 Adjusting The Venturies...7 Normal Sounds During Operation...7 Maintenance and Service...8 Opening The Door...8 Cleaning The Glass...8 To Replace Door...8 Cleaning The Firebox...8 Cleaning Plated Surfaces...9 Burner Removal...9 Replacing The Blower...9...
  • Page 4: Codes And Approvals

    After the unit has gone through the first burn turn the unit off including the pilot, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer.
  • Page 5: Specifications

    IMENSIONS " (318 mm) " (117 mm) (635 mm) ATING ABEL OCATION The rating label is found inside the right cabinet side panel. Specifications 21" (533 mm) (740 mm) 25" Shipping Weight 256 lbs (116 kg) Figure 1: EG40 Exterior Dimensions. "...
  • Page 6: Operating Instructions

    Operating Instructions FOR YOUR SAFETY READ COMPLETELY BEFORE OPERATING. IGHTING NSTRUCTIONS CAUTION: Hot while operating. Do not touch, severe burns may result. Keep children, clothing, furniture, gasoline or other flammable vapors away. CAUTION: Do not operate this fireplace with the glass removed, cracked or broken. Replacement of the panel(s) should be done by a licensed or qualified person! This appliance needs fresh air for safe operation and must be installed with provisions for combustion and ventilation air.
  • Page 7: Adjusting The Venturies

    Operating Instructions Thermopile Thermocouple Figure 3: Pilot Burning. DJUSTING ENTURIES • There is a separate venturies for each burner, see Figure 5. • Remove one screw from the cover plate located below the ash shelf and loosen the other screw (do not remove) swing the cover plate out of the way and tighten screw down to hold it in place.
  • Page 8: Maintenance And Service

    Depending upon the amount of use, cleaning should be required no more than two or three times per season. To clean the door, use a mild glass cleaner and a soft cloth or a glass cleaner available from your Enviro dealer. Abrasive cleaners will damage the glass.
  • Page 9: Cleaning Plated Surfaces

    Maintenance and Service 3. Vacuum the bottom of the firebox thoroughly. Carefully clean off any dust on the logs and remove any lint from the main burner and pilot burner. 4. After carefully replacing the log and embers in their correct positions (see Secondary Installation - Installation of Log Set and Embers), and the door has been resealed, re-light the pilot, following the instructions on the lighting label attached to the unit.
  • Page 10: Fuel Conversion

    Maintenance And Service ONVERSION TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY Please read and understand these instructions before installing. Warning: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
  • Page 11: Testing For Leaks

    Maintenance And Service Convert the SIT gas valve: a) Remove the black protection cap from the HI/LO knob by hand shown in Figure 9. b) Insert a c) Check that the screw is clean and if necessary Loosen d) Flip the screw (refer to Figure 11). Tighten e) Using the Allen wrench as shown in Figure 10, f) Verify that if the conversion is from NG to LPG,...
  • Page 12: Initial Installation

    Initial Installation WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. REPARATION NSTALLATION • Remove the packaging from the appliance, and check to make sure there is no damage. If damage is found, please report it to both the carrier and your dealer as soon as possible.
  • Page 13: Planning Your Installation

    Initial Installation QUALIFIED INSTALLERS ONLY LANNING NSTALLATION When planning your installation, it will be necessary to select the proper length of vent pipe for your particular requirements. It is important to note when passing through a wall, the maximum allowable wall thickness is 10 inches (25.4 cm), 11⁄2 inches (3.8 cm) clearance to combustibles must be maintained.
  • Page 14: Corner Installations

    Initial Installation ORNER NSTALLATIONS Do not interfere with the structural integrity of the walls. OBILE NSTALLATION • When the unit is installed in a Mobile Home it must be grounded to the steel chassis or connected to a grounding rod. •...
  • Page 15: Vent Termination Restrictions

    Initial Installation QUALIFIED INSTALLERS ONLY ERMINATION ESTRICTIONS Fixed Closed Openable Termination Cap Figure 18. Vent Termination Restrictions, refer to Table 2. Table 2: Vent termination clearances, refer to Figure 18. Letter Canadian Installation 12 in (30 cm) 12 in (30 cm) 12 in (30 cm)* 24 in (60 cm)* 18 in (45 cm)*...
  • Page 16: Fireplace Horizontal Vent Kit 50-1235

    Initial Installation IREPLACE ORIZONTAL Please read and understand these instructions before installing. Failure to follow these instructions carefully could cause property damage or personal injury. KIT COMPONENTS: Qnty Description Horizontal direct vent termination cap Flue collar adapter Wall thimble 5’ (190 cm) length of Ø4” (10 cm) double walled flex pipe 5’...
  • Page 17: Other Approved Vent Parts

    Initial Installation QUALIFIED INSTALLERS ONLY 10. Apply a bead of Mill-Pac Black sealant to the top section of the Ø4” (10 cm) by 5” (12.5 cm) flue collar adaptor previously installed into the fireplace flue outlet. Slide the Ø4” (10 cm) flex vent over the flue collar and secure with three (3) sheet metal screws evenly spaced.
  • Page 18 Initial Installation EXCEPTION TO WARNING: This product has been evaluated by Intertek for using a Direct Vent GS starting collar in conjunction with Secure Vent, Direct-Temp, and Ameri Vent Direct venting systems. Use of these systems with the Direct Vent GS starting collar is deemed acceptable and does not affect the Intertek WH listing of the appliance.
  • Page 19: Vent Configurations

    Initial Installation QUALIFIED INSTALLERS ONLY ONFIGURATIONS Figures 22 shows the range of venting options, it shows possible vent configurations if the unit is top vented, for vertical and horizontal terminations, any layout that remains within the shaded area is acceptable. Having the fewest number of elbows is ideal, as they tend to disrupt air movement.
  • Page 20: Horizontal Installation

    Initial Installation ORIZONTAL NSTALLATION 1. Set the appliance in the desired location. Check to determine if wall studs or roof rafters are in the way when the venting system is attached. If this is the case, you may want to adjust the location of the appliance.
  • Page 21 Initial Installation QUALIFIED INSTALLERS ONLY 4. Position the horizontal vent termination in the center of the 10” (25.4 cm) x 10” (25.4 cm) hole, and attach to the exterior wall with the four screws provided. Before attaching the vent termination to the exterior wall, run a bead of non-hardening mastic around the edges, so as to make a seal between the termination and the wall.
  • Page 22: Vertical Installation

    Initial Installation ERTICAL NSTALLATION 1. Check the instructions for required clearances (air spaces) to combustibles when passing through ceilings, walls, roofs, enclosures, attic rafters, or other nearby combustible surfaces. Do not pack air spaces with insulation. 2. Set the gas appliance in the desired location. Drop a plumb bob down from the ceiling to the position of the appliance flue exit, and mark the location where the vent will penetrate the...
  • Page 23 Initial Installation QUALIFIED INSTALLERS ONLY support straps to the roof. Seal the nails holes heads with non-hardening mastic. Trim the excess length of the support straps that extend out beyond the edge of the flashing. 7. Slip the flashing over the pipe section protruding through the roof. Secure the base of the flashing to the roof with roofing nails.
  • Page 24: Cathedral Ceiling Installation

    Initial Installation • For multi story installations. A ceiling firestop is required at the second floor, and any subsequent floors (see Figure 33). The opening should be framed to 10” (25.4 cm) x 10” (25.4 cm) inside dimensions, in the same manner as shown in Figure 29. •...
  • Page 25: Venting Into A Class 'A' Chimney

    Initial Installation QUALIFIED INSTALLERS ONLY ‘A’ C ENTING INTO A LASS HIMNEY This model is also certified and tested to vent into CLASS ‘A’ wood stove chimneys. Place the freestanding direct vent appliance in the desired location. Use a conversion kit from Simpson Duravent (931, 932, or 933), or Security Chimney (SV4CCK1, SV4CCK2, or SV4CCK1).
  • Page 26: Electrical Requirements

    LECTRICAL EQUIREMENTS The ENVIRO EG40 will operate without electrical power. This model has a millivolt gas control, which uses the pilot flame to generate enough electricity to operate the main burners. The appliance is equipped with a blower and must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE Part 1, SAFETY...
  • Page 27: Gas Line Connection And Testing

    Initial Installation ONNECTION AND ESTING WARNING: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. GAS LINE CONNECTION This stove is equipped with a certified flexible pipe located on the right side of the unit terminating in •...
  • Page 28: Secondary Installation

    If over time, through cleaning and servicing, these embers require replacement, contact the nearest ENVIRO dealer for replacement embers. The embers can be place before or after the logs are placed. A bag of ceramic fiber embers and rock wool...
  • Page 29 Secondary Installation Place the log set into the firebox. Locate each log by seating it down onto the burner tray support pins. Follow Figures 31 to 34 proper log placement. Upon the first light up, watch for ignition to ALL burner ports. long delay is noted: First, wait for the appliance to cool down.
  • Page 30: Trouble Shooting

    Trouble Shooting Problem Possible Cause The main burner does not The gas valve may not be on. ignite when called for. Thermostat is not calling for heat. Problem with gas valve. Spark will not light the pilot Defective piezo ignitor. after repeatedly pressing the spark ignitor.
  • Page 31: Parts List

    Part Number EC-001 50-1421 EC-009 EC-011 EC-012 EC-015 EC-016 EC-019 EC-020 EC-021 EC-023 EC-024 EC-025 EC-031 EC-032 EC-037 EC-037A EC-037B EC-040 EC-043 EC-045 EC-054 EC-056 EC-057 EC-058 EC-059 EC-060 EC-061 EC-063 EC-066 EC-067 EF-045 EG40-023 EG40-033 EG40-049 EG40-066 EG40-070 EG40-080...
  • Page 32 Reference Number Parts List Part Description Side Panel DV Stove Top Firebox Baffle Stove Top Baffle DV Venturi Cover Plate Front Venturi Bar Set - Painted (3 pieces) Bar Set - Gold (3 pieces) Bar Set - Nickel (3 pieces) Burner Gasket Steel Brick Liner Brick Liner Backing...
  • Page 33: Parts Diagram - Chassis

    Parts Diagram - Chassis �� � � �� �� �� �� �� �� �� �� �� EG 40 Body (Chassis) July 2004...
  • Page 34: Parts Diagram - Gas Tray & Door

    Parts Diagram - Gas Tray & Door...
  • Page 35: Warranty

    Warranty Sherwood Industries Ltd. offers a Limited Lifetime Warranty on this gas product. This limited lifetime warranty covers the appliance for a period of seven years from the date of installation. This warranty applies only to the original owner in the original location Covered under the lifetime warranty are Cabinet Sides, Tops, Pedestals, Surround Panels and Chassis and Heat Exchanger.
  • Page 36: Installation Data Sheet

    Installation Data Sheet The following information must be recorded by the installer for warranty purposes and future reference. NAME OF OWNER: _________________________________________ ADDRESS: _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ MODEL:___________________________________ SERIAL NUMBER:___________________________ DATE OF PURCHASE: _____________ DATE OF INSTALLATION:___________ � NATURAL GAS (NAT) INLET GAS PRESSURE:_________in wc MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam.
