SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
OWNER'S MANUAL
If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life. Installation and
service must be performed by a qualified installer, service agency or the gas supplier.
Do not store or use gasoline or other Flammable vapours and liquids in the vicinity of
Massachusetts installations (Warning): This product must be installed by a licensed
plumber or gas fitter when installed within the Commonwealth of Massachusetts. Other
Massachusetts code requirements:-Flexible connector must not be longer than 36
inches, shut off valve must be a "T" handle gas cock, only direct vent sealed combustion
products are approved for bedroom/bathrooms, fireplace dampers must be removed or
welded in the open position prior to the installation of a fireplace insert or gas log.
EG40 DV
WHAT TO DO IF YOU SMELL GAS
• Open windows/Extinguish any open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch or use any phone in your
building.
• Immediately call your gas supplier from a neighbour's phone.
Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
This appliance may be installed in an after market permanently
located, manufactured (mobile) home, where not prohibited by
This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other
gases, unless a certified kit is used.
WARNING
FOR YOUR SAFETY
this or any other appliance.
B Y : S H E R W O O D I N D U S T R I E S L T D
local codes.
EG40-070
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Enviro C-10365
Summary of Contents for Enviro C-10365
- Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE OWNER’S MANUAL If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Installation and service must be performed by a qualified installer, service agency or the gas supplier.
-
Page 2: Safety Precautions
Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed in accordance with their instructions. Carefully read all the instructions in this manual first. Consult the building authority having jurisdiction to determine the need for a permit prior to commencing the installation. -
Page 3: Table Of Contents
Table of Contents Safety Precautions...2 Table of Contents...3 Codes And Approvals...4 Specifications...5 Dimensions...5 Clearances to Combustibles...5 Preparation For Installation:...5 Initial Installation...6 Vent Termination Restrictions...6 Vent Configurations...7 Vent Restrictor Ring...7 Vent Parts...8 Planning Your Installation...9 Horizontal Installation...10 Corner Installations...12 Vertical Installation...12 Cathedral Ceiling Installation...15 Freestanding Direct Vent Kit With Coupler...15 Venting into a Class ‘A’... -
Page 4: Codes And Approvals
After the unit has gone through the first burn turn the unit off including the pilot, let the unit get cold then remove the glass door and clean it with a good gas fireplace glass cleaner, available at your local ENVIRO dealer. -
Page 5: Specifications
• Locate the stove in a large and open room that is centrally located in the house. This will optimize heat circulation and comfort. • As the stove is equipped with a convection fan, ensure that an electrical outlet is within 6 feet. (1.8 m) of the stove. -
Page 6: Initial Installation
Initial Installation ERMINATION ESTRICTIONS Fixed Closed Openable Termination Cap Figure 3: Exterior Vent Termination Locations, use in conjunction with Table 1. Table 1: Exterior Vent Termination Locations, use in conjunction with Figure 3. Letter Canadian Installation 12 in (30 cm) 12 in (30 cm) 12 in (30 cm)* 24 in (60 cm)*... -
Page 7: Vent Configurations
A vent restrictor ring is supplied with each direct vent fireplace. This restrictor ring is to be installed when the vertical chimney installation is over 6 feet (1.83 m). Before the chimney is placed onto the stove, place this vent restrictor ring into the 4 inch (10.2 cm) flue pipe (as shown), once the vent restrictor ring has been installed, the vertical sections of chimney can be installed. -
Page 8: Vent Parts
Initial Installation ARTS For horizontal venting installations Sherwood Industries Ltd.’s DV Kit with Coupler (part# EC-061) can be used, refer to “Initial Installation - Freestanding Direct Vent Kit with Coupler.” Simpson Duravent (SD), Selkirk (SEL), and Security Chimneys (SC), must state if galvanized or black wanted, PART NUMBERS: Description 4DT-6 SV4L6... -
Page 9: Planning Your Installation
Initial Installation QUALIFIED INSTALLERS ONLY LANNING NSTALLATION When planning your installation, it will be necessary to select the proper length of vent pipe for your particular requirements. It is important to note when passing through a wall, the maximum allowable wall thickness is 10 inches (25.4 cm), 11⁄2 inches (3.8 cm) clearance to combustibles must be maintained. -
Page 10: Horizontal Installation
11⁄2 inches (3.8 cm) at sides, 11⁄2 inches (3.8 cm) at bottom. STEP 3. With the pipe attached to the stove in the correct location, mark the wall for a 10” (25.4 cm) x 10” (25.4 cm) square hole (refer to Figure 9). The center of the square hole should match the center line of the horizontal pipe. - Page 11 Initial Installation QUALIFIED INSTALLERS ONLY STEP 4. Position the horizontal vent termination in the center of the 10” (25.4 cm) x 10” (25.4 cm) hole, and attach to the exterior wall with the four screws provided. Before attaching the vent termination to the exterior wall, run a bead of non-hardening mastic around the edges, so as to make a seal between the termination and the wall.
-
Page 12: Corner Installations
Initial Installation ORNER NSTALLATIONS Do not interfere with the structural integrity of the walls. ERTICAL NSTALLATION STEP 1. Check the instructions for required clearances (air spaces) to combustibles when passing through ceilings, walls, roofs, enclosures, attic rafters, or other nearby combustible surfaces. Do not pack air spaces with insulation. - Page 13 Initial Installation QUALIFIED INSTALLERS ONLY STEP 5. Cut hole in the roof centered on the small hole placed in the roof from Step 2. The hole should be of sufficient size to meet minimum requirements for Clearance to Combustibles, as specified. Continue to assemble lengths of pipe and elbows necessary to reach from the ceiling support box up through the roof line.
- Page 14 Initial Installation plumber’s tape connected to wall strap Wall strap 45° elbows (x2) Figure 17: Use of Wall Straps. NOTES: (1) For multi story installations. A ceiling firestop is required at the second floor, and any subsequent floors (see Figure 14). The opening should be framed to 10”...
-
Page 15: Cathedral Ceiling Installation
Initial Installation QUALIFIED INSTALLERS ONLY ATHEDRAL EILING NSTALLATION STEP 1. Follow installation steps 1 & 2 under ‘Vertical Installation’. STEP 2. Using the plumb bob, mark the center line of the venting system on the ceiling and drill a small hole through the ceiling and roof at this point. -
Page 16: Installation Instructions
3. Set the appliance in the desired location. Temporarily place a 24” (61 cm) section with the non-crimped end on the unit 4. Install the 90° elbow onto the vertical pipe on the stove pointing in the direction that the vent will exit the structure. - Page 17 Initial Installation QUALIFIED INSTALLERS ONLY 19. Place a bead of high temperature silicone on the flue pipe and slide the flex liner over the collar, secure the flex liner with three (3) sheet metal screws evenly spaced. 20. Align all straight sections of pipe, slipping all joints together and installing with three (3) sheet metal screws evenly spaced.
-
Page 18: Venting Into A Class 'A' Chimney
ENTING INTO A LASS This model is also certified and tested to vent into CLASS ‘A’ wood stove chimneys. Place the freestanding direct vent appliance in the desired location. Use a conversion kit from Simpson Duravent (931, 932, or 933), or Security Chimney (SV4CCK1, SV4CCK2, or SV4CCK1). -
Page 19: Wire Size
LECTRICAL EQUIREMENTS The ENVIRO EG40 will operate without electrical power. This model has a millivolt gas control, which uses the pilot flame to generate enough electricity to operate the main burners. The appliance is equipped with a blower and must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE Part 1, SAFETY STANDARDS FOR ELECTRICAL INSTALLATIONS,... -
Page 20: Replacing The Blower
Initial Installation EPLACING LOWER Figure 28: Blower (Fan) Removal. DJUSTING ENTURIES • There is a separate venturies for each burner, see Figure 29. • Remove one screw from the cover plate located below the ash shelf and loosen the other screw (do not remove) swing the cover plate out of the way and tighten screw down to hold it in place. -
Page 21: Fuel Conversion
STEP 2. Shut the gas off and disconnect the main gas line from the unit. STEP 3. Open the door by unscrewing the 1⁄2” bolt on the right hand side of the stove. Lift door off the hinges mounted on the left-hand side. -
Page 22: Gas Line Connection And Testing
• This stove is equipped with a certified flexible pipe located on the right side of the unit terminating in a 3⁄8” male NPT fitting. Consult your local authorities codes or the CAN/CGA B 149 (1 or 2) installation code in Canada, or in the USA gas installations follow either local codes or the current edition of the National Fuel Gas Code ANSI Z223.1. -
Page 23: Secondary Installation
If over time, through cleaning and servicing, these embers require replacement, contact nearest ENVIRO dealer replacement embers. 1. The embers can be place before or after the logs are placed. A bag of ceramic fiber embers and rock wool embers is provided gently remove the ember material from the plastic bag. - Page 24 ENVIRO dealer. See Routine Maintenance And Service on how to remove door to clean glass.
-
Page 25: Operating Instructions
Operating Instructions FOR YOUR SAFETY READ COMPLETELY BEFORE OPERATING. WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OR LIFE. A) This appliance is equipped with a pilot that must be lit by hand by following these instructions exactly. B) BEFORE LIGHTING smell all around the appliance area for gas, and next to the floor because some gas is heavier than air and will settle on the floor. -
Page 26: Routine Maintenance And Service
Depending upon the amount of use, cleaning should be required no more than two or three times per season. To clean the door, use a mild glass cleaner and a soft cloth or a glass cleaner available from your Enviro dealer. -
Page 27: Trouble Shooting
Trouble Shooting Problem Possible Cause Spark will not light the Defective piezo ignitor. pilot after repeatedly pressing the spark ignitor Broken spark electrode. Misaligned spark electrode. Pilot will not remain lit Problem with thermocouple circuit. Air in gas line (pilot dies while knob is depressed). -
Page 28: Parts List
Reference Part Description Number 120 °F (49 °C) Ceramic Temperature Sensor S.I.T. NOVA Valve NG (50% turn down) S.I.T. NOVA Valve LP (50% turn down) Thermocouple Spark Electrode with Ignitor Cable Thermopile Fully Assembled Pilot NG Fully Assembled Pilot LP Pilot Orifice NG Threaded Pilot Orifice LP Threaded Pilot Gasket... - Page 29 Fan Access Cover Gasket DV Owner’s Manual Pedestal Side Panel DV Stove Top Firebox Baffle Stove Top Baffle DV Venturi Cover Plate Front Venturi Bar Set - Painted (3 pieces) Bar Set - Gold (3 pieces) Bar Set - Nickel (3 pieces)
-
Page 30: Parts Diagram - Chassis
Parts Diagram - Chassis �� � � �� �� �� �� �� �� �� �� �� EG 40 Body (Chassis) July 2004... -
Page 31: Parts Diagram - Gas Tray & Door
Parts Diagram - Gas Tray & Door... -
Page 32: Warranty
Warranty Sherwood Industries Ltd. offers a Limited Lifetime Warranty on this gas product. This limited lifetime warranty covers the appliance for a period of seven years from the date of installation. This warranty applies only to the original owner in the original location Covered under the lifetime warranty are Cabinet Sides, Tops, Pedestals, Surround Panels and Chassis and Heat Exchanger. -
Page 33: Installation Data Sheet
_________________________________________ 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 NAME OF DEALER: _________________________________________ ADDRESS: _________________________________________ _________________________________________ _________________________________________ PHONE:___________________________________ NAME OF INSTALLER: _________________________________________ (dd/mm/yyyy) ADDRESS: (dd/mm/yyyy) _________________________________________ _________________________________________ PROPANE(LPG) _________________________________________ PHONE:___________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. www.envirofire.biz February 21, 2005 C-10365...
