SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
OWNER'S MANUAL
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury or loss of life. Installation and
service must be performed by a qualified installer, service agency or the gas supplier.
FOR YOUR SAFETY: Do not store or use gasoline or other Flammable vapours and
liquids in the vicinity of this or any other appliance.
Massachusetts installations (Warning): This product must be installed by a licensed
plumber or gas fitter when installed within the Commonwealth of Massachusetts. Other
Massachusetts code requirements: Flexible connector must not be longer than 36in., a
shut off valve must be installed; only direct vent sealed combustion products are approved
for bedrooms/bathrooms. A carbon monoxide detector is required in all rooms containing
gas fired direct vent appliances.
EG40 BV
B Y : S H E R W O O D I N D U S T R I E S L T D
WHAT TO DO IF YOU SMELL GAS
• Open windows/Extinguish any open flame.
• Do not try to light any appliance.
• Do not touch any electrical switch or use any
phone in your building.
• Immediately call your gas supplier from a
neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
This appliance may be installed in an after market
permanently located, manufactured (mobile)
home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
WARNING
certified kit is used.
EG40-071

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EG40 BV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Enviro EG40 BV

  • Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER. EG40 BV B Y : S H E R W O O D I N D U S T R I E S L T D OWNER’S MANUAL...
  • Page 2: Safety Precautions

    Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed • To prevent injury, do not allow anyone who is in accordance with their instructions. Carefully read all unfamiliar with the stove to operate it.
  • Page 3: Table Of Contents

    Table of Contents Safety Precautions..................2 Table of Contents....................3 Codes And Approvals..................4 Specifications....................5 Dimensions..................5 Rating Label Location................5 Operating Instructions..................6 Lighting Instructions................6 Adjusting The Venturies................7 Normal Sounds During Operation............7 Maintenance and Service.................8 Opening The Door................8 Cleaning The Glass................8 To Replace Door...................8 Cleaning The Firebox................8 Cleaning Plated Surfaces..............9 Burner Removal...................9 Replacing The Blower................9...
  • Page 4: Codes And Approvals

    This appliance has been tested by INTERTEK (Warnock Hersey) and found to comply with the established VENTED GAS FIREPLACE HEATER standards in CANADA and the USA as follows: VENTED GAS FIREPLACE HEATER (EG40 BV NG/LPG) TESTED TO: ANSI Z21.88a-2003/CSA 2.33a-2003 VENTED GAS FIREPLACE HEATERS CAN/CGA 2.17-M91 GAS FIRED APPLIANCES FOR HIGH ALTITUDES...
  • Page 5: Specifications

    Specifications imensions " (318 mm) " (117 mm) 21" (533 mm) " (740 mm) 25" (635 mm) Shipping Weight 256 lbs (116 kg) Figure 1: EG40 Exterior Dimensions. ating abeL ocation The rating label is found inside the right cabinet side panel.
  • Page 6: Operating Instructions

    Operating Instructions FOR YOUR SAFETY READ COMPLETELY BEFORE OPERATING. ighting nstRuctions CAUTION: Hot while operating. Do not touch, severe burns may result. Keep children, clothing, furniture, gasoline or other flammable vapors away. CAUTION: Do not operate this fireplace with the glass removed, cracked or broken. Replacement of the panel(s) should be done by a licensed or qualified person! This appliance needs fresh air for safe operation and must be installed with provisions for combustion and ventilation air.
  • Page 7: Adjusting The Venturies

    Operating Instructions Thermopile Thermocouple Figure 3: Pilot Burning. Figure 4: Gas Valve. Djusting entuRies • There is a separate venturies for each burner, Rear log holder see Figure 4. Front log holder • Remove one screw from the cover plate located Ember tray &...
  • Page 8: Maintenance And Service

    Depending upon the amount of use, cleaning should be required no more than two or three times per season. To clean the door, use a mild glass cleaner and a soft cloth or a glass cleaner available from your Enviro dealer. Abrasive cleaners will damage the glass.
  • Page 9: Cleaning Plated Surfaces

    Maintenance and Service 3. Vacuum the bottom of the firebox thoroughly. Carefully clean off any dust on the logs and remove any lint from the main burner and pilot burner. 4. After carefully replacing the log and embers in their correct positions (see Secondary Installation - Installation of Log Set and Embers), and the door has been resealed, re-light the pilot, following the instructions on the lighting label attached to the unit.
  • Page 10: Fuel Conversion

    Maintenance And Service onVeRsion TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY Please read and understand these instructions before installing. Warning: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
  • Page 11 Maintenance And Service Convert the SIT gas valve: a) Remove the black protection cap from the HI/LO knob by hand shown in Figure 8. b) Insert a ” or 4 mm Allen wrench into the hexagonal key-way of the screw (see Figure 9), rotate it counter-clockwise until it is free and extract it.
  • Page 12: Initial Installation

    Initial Installation QUALIFIED INSTALLERS ONLY WARNING: Operation of this heater when not connected to a properly installed and maintained venting system can result in carbon monoxide (CO) poisoning and possible death. RepaRation nstaLLation • Remove the packaging from the appliance, and check to make sure there is no damage. If damage is found, please report it to both the carrier and your dealer as soon as possible.
  • Page 13: Venting

    The ENVIRO incorporates its own internal draft hood, so no additional external draft hood is required. Check periodically that the vent is unrestricted and an adequate draught is present when the unit is in...
  • Page 14: Installation Into An Existing Chimney

    Initial Installation QUALIFIED INSTALLERS ONLY eRmination 10 ft (3050 mm) The bottom of the vent cap shall extend at least 2 ft (61 cm) above the highest point Height above roof surface within 10ft of the roof where it passes through and at horizontally 2 ft (610 mm) least 2 ft (61 cm) higher than any portion...
  • Page 15: Straight Vertical Installation

    Initial Installation QUALIFIED INSTALLERS ONLY tRaight eRticaL nstaLLation This basic venting configuration shown are rough guidelines only. Follow national and local codes for other installation options. For the best venting performance, we recommend a total vent height in the range of 10 ft (3.0 m) to 30 ft (9.1 m).
  • Page 16: Electrical Requirements

    LectRicaL equiRements The ENVIRO EG40 will operate without electrical power. This model has a millivolt gas control, which uses the pilot flame to generate enough electricity to operate the main burners. The appliance is equipped with a blower and must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE Part 1, SAFETY...
  • Page 17: Gas Line Connection And Testing

    Initial Installation onnection anD esting WARNING: Only persons licensed to work with gas piping may make the necessary gas connections to this appliance. GAS LINE CONNECTION • This stove is equipped with a certified flexible pipe located on the right side of the unit terminating in a ⅜”...
  • Page 18: Secondary Installation

    If over time, through cleaning and servicing, these embers require replacement, contact the nearest ENVIRO dealer for replacement Figure 19: Step 1 of Log Placement. embers. Pins for Rear Log The embers can be place before or after the logs are placed.
  • Page 19 Secondary Installation Ledge for Right Log Place the log set into the firebox. Locate each log by seating it down onto the burner tray support pins. Follow Figures 20 to 23 proper log placement. Upon the first light up, watch for Pin for Right Log ignition to ALL burner ports.
  • Page 20: Trouble Shooting

    Trouble Shooting Problem Possible Cause Solution The main burner The gas valve may not be on. • Check that the gas control knob is in the “ON” position. does not ignite Thermostat is not calling for • Adjust the thermostat several degrees above ambient temperature. when called for.
  • Page 21: Parts List

    Parts List Reference Part Description Part Number Number 120 °F (49 °C) Ceramic Temperature Sensor EC-001 220 °F (104 °C) Ceramic Spill Switch EC-002 S.I.T. NOVA Valve Convertible 50-1421 Thermocouple EC-009 Spark Electrode with Ignitor Cable EC-011 Thermopile EC-012 Fully Assembled Pilot NG EC-015 Fully Assembled Pilot LP EC-016...
  • Page 22 Parts List Reference Part Description Part Number Number Side Panel EG40-086 BV Stove Top EG40-087 Firebox Baffle EG40-088 Stove Top Baffle BV EG40-091 Venturi Cover Plate EG40-097 Front Venturi EG40-098 Bar Set - Painted (3 pieces) EG40-114 Bar Set - Gold (3 pieces) EG40-115 Bar Set - Nickel (3 pieces) 50-478...
  • Page 23: Parts Diagram - Chassis

    Parts Diagram - Chassis EG 40 Body (Chassis) July 2004...
  • Page 24: Parts Diagram - Gas Tray & Door

    Parts Diagram - Gas Tray & Door...
  • Page 25: Warranty

    Exclusions conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail. This warranty does not cover: In the event of a defect of material or workmanship during the specified warranty period, ƒ...
  • Page 26: Installation Data Sheet

    � NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in wc PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com January 20, 2012 C-13831...
