SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY
THIS MANUAL IS PRINTED ON RECYCLED PAPER
EG 40 B Vented
O W N E R S M A N U A L
WHAT TO DO IF YOU SMELL GAS
• Open windows
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone
in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
Do not store or use gasoline or other Flammable vapors and liquids in the
Massachusetts installations (WARNING): This product must be installed by a licensed plumber or gas fitter when installed within the
Commonwealth of Massachusetts. Other Massachusetts code requirements: Flexible connector must not be longer than 36", shutoff
valve must be a "T" handle gas cock, only direct vent sealed combustion products are approved for bedroom/bathrooms, fireplace
dampers must be removed or welded in the open position prior to the installation of a fireplace insert or gas log.
FOR YOUR SAFETY
vicinity of this or any other appliance.
B y S H E R W O O D I N D U S T R I E S L T D .
WARNING
If the information in this manual is
not followed exactly, a fire or
explosion may result causing
property damage, personal injury
or loss of life installation and
service must be performed by a
qualified installer, service agency
or the gas supplier.
EG40-071
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Enviro EG 40 B Vented
Summary of Contents for Enviro EG 40 B Vented
- Page 1 SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY THIS MANUAL IS PRINTED ON RECYCLED PAPER EG 40 B Vented B y S H E R W O O D I N D U S T R I E S L T D .
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS FOR SAFE INSTALLATION AND OPERATION OF YOUR "ENVIRO" STOVE, PLEASE, CAREFULLY READ THE FOLLOWING INFORMATION: GENERAL • • Always keep the appliance area clear Installation and repair should be done by a qualified service person. The appliance should be... -
Page 3: Table Of Contents
TESTED TO: ANSI Z21.11.1b-1995 GAS FIRED ROOM HEATERS. ANSI Z21.50-1996/CGA-2.22-M96, VENTED GAS FIREPLACES.CAN 1-2.1-M86 GAS FIRED VENTED ROOM HEATERS. SPECS: ENVIRO EG 40 B VENT UNITS; • Have all been certified for use with either natural or propane gases. (See control panel and rating label.) •... -
Page 4: Deciding Where To Locate Your Stove
DECIDING WHERE TO LOCATE YOUR STOVE DIMENSIONS: Front Width: 25" (63 cm) Rear Width: 25" (63 cm) Height: 29-1/8" (74 cm*) Depth 21" (53 cm) (*not including vent coupling ) Shipping Weight: 256lbs (116 kg) CLEARANCES: FIG. 1 A. Side wall to stove 12"... -
Page 5: Vent Terminal Clearances
VENT TERMINAL CLEARANCES A= Clearance above grade, verandah, porch, deck, H= *Not to be installed above a meter/regulator or [balcony (*12 inches (30cm) minimum] assembly within 3 feet (90cm) horizontally B= Clearance to window or door that may be opened from the center-line of the regulator [*12 inches (30cm) minimum] I= Clearance to service regulator vent outlet... -
Page 6: Venting
The ENVIRO incorporates its own internal draft hood, so no additional external draft hood is required. Check periodically that the vent is unrestricted and an adequate draft is present when the unit is in operation. - Page 7 A. USING AN EXISTING CHIMNEY • Measure the height of the chimney beforehand and purchase the appropriate kit. Never attempt to over stretch a flexible liner to accommodate the height of the chimney. • Any flue damper must be removed or locked permanently in the open position.
-
Page 8: Installation Of Log Sets And Embers
Use only a single layer. Do not pile embers. The use of other foreign materials on the burners may create dangerous conditions. If over time, through cleaning and servicing, these embers require replacement, contact the nearest ENVIRO dealer for replacement embers. -
Page 9: Operating Instructions
OPERATING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE OPERATING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. A) This appliance is equipped with a pilot, which must •... -
Page 10: Maintenance And Technical
TO REPLACE DOOR AND GLASS ASSEMBLY The glass in this appliance is an integral part of the door assembly. If the glass is damaged or broken it must be replaced by a complete inner door, can be ordered through your local ENVIRO dealer. -
Page 11: Trouble Shooting
TROUBLE SHOOTING Problem Possible Cause Solution Spark will not light the pilot after Defective piezo Ignitor Check connections to ignitor. repeated pressing of spark -If Ignitor connections are good but Ignitor there is no spark-replace ignitor. Broken spark electrode -Check for broken ceramic insulation. Replace, electrode if broken. -
Page 12: Gas Line Connection
GAS LINE CONNECTION ORIFICE SIZES, PRESSURE AND BTU’S NATURAL GAS PROPANE GAS FRONT BURNER #48 (1.93mm) #56 (1.32mm) REAR BURNER #43 (2.49 mm) #54 (1.40 mm) Manifold pressure. 3.8”w.c (.95kPa) 11”w.c (2.74kPa) Min. Manifold Pressure. 1.1”w.c (.27kPa) 2.7”w.c (.67kPa) Supply Pressure. 7.0”w.c (1.74kPa) 12”w.c (2.98kPa) Min. -
Page 13: Electrical
ELECTRICAL The ENVIRO EG 40.FS.BV. Will operate with no external power supply. These models have a Milli volt gas control valve that uses the pilot flame to generate enough electricity to operate the main burner. The appliance when installed must be electrically connected and grounded in accordance with local codes or in the absence of local codes, with the current CSA C22.1 CANADIAN ELECTRICAL CODE Part 1, SAFETY... -
Page 14: Parts And Accessories
PARTS AND ACCESSORIES Service Parts available from your local Enviro Dealer Burner Control Assembly Convection Blower Natural Gas Pilot Assembly Light Bulb Holder Propane Pilot Assembly Light Switch (momentary) Door Bolt Fan Controller Relief Door Gasket Log Set (with Embers) -
Page 15: Fuel Type Conversion
Excessive blue is to lean and dark orange with soot is to rich FUEL TYPE CONVERSION This is a guide to assist you in converting an ENVIRO EG-40 gas unit. If after following our guidelines you cannot properly convert this unit please call our technical department for assistance. -
Page 16: Warranty
WARRANTY Sherwood Industries Ltd. offers a *Lifetime Warranty on this gas product. The lifetime warranty covers the appliance for a period of seven years from the date of installation. This warranty applies only to the original owner in the original location Covered under the lifetime warranty are Cabinet Sides, Tops, Pedestals, Surround Panels and Chassis and Heat Exchanger. -
Page 17: Parts List
PARTS LIST 120 ° F (49 °C) Ceramic Temperature EC-001 EG40-086 Freestanding Side Panel Sensor 220 °F (104 °C) Ceramic Spill Switch EC-002 EG40-087 BV Stove Top EC-006 S.I.T. NOVA Valve NG EG40-087A DV Stove Top EC-007 S.I.T. NOVA Valve LP EG40-088 Firebox Baffle EC-009... -
Page 20: Installation Data Sheet
INSTALLATION DATA SHEET The following information must be recorded by the installer for warranty purposes and future reference. Model: EG 40 Name of Dealer: Name of Owner: __________________________________________ ___________________________________________ Address: Address: __________________________________________ ___________________________________________ ___________________________________________ __________________________________________ ___________________________________________ __________________________________________ Phone: ___________________________________ Phone: _____________________________________ Name of Installer: •...
