Various Settings

Making changes with Display Adjustment Mode

Various Settings
This mode lets you adjust the display brightness, change the display type, etc.
Switching the Display
Adjustment Mode
Press the [ /MENU] button for
1
more than one second.
The Menu selection mode is activated.
Press the [SELECT] (Up/Down)
2
button to select DISP.
3
Press the [ENTER] button.
The display adjustment mode is
activated.
Press the [SELECT] (Up/Down)
4
button to select a setting item.
When the button is pressed, the
setting item changes in the following
order.
Bright ↔ Illumination ↔ DISP Type ↔
DISP Data ↔ Scroll Type↔
Bright ↔
5
Press the [ENTER] button.
Switches among
modes.

Switching the brightness (Bright)

Default setting is maximum brightness (5).
Press the [SELECT] (Up/Down)
1
button to select Bright.
2
Press the [ENTER] button.
The bright setting mode is activated.
72
the adjustment
Press the [SELECT] (Right/Left)
3
button to adjust the brightness.
Right:
Increases the brightness level.
Left:
Decreases the brightness level.
4
Press the [ENTER] button.
The selected settings will take effect.

Changing illumination color

You can change the button illumination color in
the following way.
Press the [SELECT] (Up/Down)
1
button to select Illumination.
2
Press the [ENTER] button.
The illumination
activated.
Press the [SELECT] (Up/Down)
3
button.
Press the [SELECT] (Up/Down) button
to set illumination color as follows:
Blue/Red ↔ Blue/Green ↔ Blue/Amber
↔ All Red ↔ All Green ↔ All Amber ↔
Blue/Red ↔
4
Press the [ENTER] button.
The selected settings will take effect.
setting mode is
